Instruction Manual

IRTS-P Precision Infrared Temperature Sensor
6
;Calculate correction factor (SEC)
7: Z=1/X (P42) ; {1/Psb}
1: 4 X Loc [ Psb ]
2: 4 Z Loc [ Psb ]
8: Z=X*F (P37) ; {.25/Psb}
1: 4 X Loc [ Psb ]
2: 0.25 F
3: 4 Z Loc [ Psb ]
9: Z=X-Y (P35) ; {ATT - Hsb}
1: 2 X Loc [ AppTargT ]
2: 5 Y Loc [ Hsb ]
3: 5 Z Loc [ Hsb ]
10: Z=X*Y (P36) ; {ATT - Hsb}^2
1: 5 X Loc [ Hsb ]
2: 5 Y Loc [ Hsb ]
3: 5 Z Loc [ Hsb ]
11: Z=X-Y (P35) ; {subtract Ksb}
1: 5 X Loc [ Hsb ]
2: 6 Y Loc [ Ksb ]
3: 6 Z Loc [ Ksb ]
12: Z=X*Y (P36) ; {calculate SEC}
1: 4 X Loc [ Psb ]
2: 6 Y Loc [ Ksb ]
3: 7 Z Loc [ SEC ]
;Calculate corrected target temperature (CTT)
13: Z=X-Y (P35) ;
1: 2 X Loc [ AppTargT ]
2: 7 Y Loc [ SEC ]
3: 8 Z Loc [ CTT ]
14: If time is (P92)
1: 0 Minutes (Seconds --) into a
2: 60 Interval (same units as above)
3: 10 Set Output Flag High (Flag 0)
15: Real Time (P77)
1: 1220 Year,Day,Hour/Minute (midnight = 2400)
16: Average (P71)
1: 3 Reps
2: 1 Loc [ RefTemp ]
17: Average (P71)
1: 1 Reps
2: 8 Loc [ CTT ]
