IRTS-P Precision Infrared Temperature Sensor

00558.059237.09092.49 SBSBP

⋅+⋅+=

00077.04248.02828.4 SBSBH

⋅−⋅+=

387.03816.50705.52 SBSBK

⋅+⋅−=

and

=SB

Sensor Body Temperature

The three example programs measure the sensor once a second and output

average sensor and target temperatures once an hour. In an actual installation

the measurement and output intervals, and channels used may be changed to

accommodate the other measurements and outputs.

TABLE 5-1. Wiring for Example Programs

Sensor/Lead Description CR10X CR23X CR1000

CR10XTCR

Reference Temp:

Not

Used

Not

Used

Black Excitation E3

Red Signal SE1

Clear Ground AG

IRTS-P – Target/Black Band

Detector Temp

Yellow TC + 2H 1H 1H

Red TC - 2L 1L 1L

IRTS-P – Body/No Band

Sensor Temp

Yellow TC + 3H 2H 2H

Red TC - 3L 2L 2L

Bare wire Shield G

CR10X Example Program

;{CR10X}

;

*Table 1 Program

01: 1 Execution Interval (seconds)

;Measure CR10XTCR Reference Temperature

1: Temp (107) (P11)

1: 1 Reps

2: 1 SE Channel

3: 3 Excite all reps w/E3

4: 1 Loc [ RefTemp ]

5: 1.0 Mult

6: 0.0 Offset

;Measure IRt/c apparent target temperature
