T107 Weather Station 1. Preparation and Siting 1.1 Siting and Exposure CAUTION If any part of the weather station comes in contact with power lines, you could be killed. Contact local utilities for the location of buried utility lines before digging or driving ground rods. Selecting an appropriate site for the weather station is critical in order to obtain accurate meteorological data.
T107 Weather Station 1.1.2 Temperature and Relative Humidity Sensors should be located over an open level area at least 9 m (29.5 ft) (EPA) in diameter. The surface should be covered by short grass, or where grass does not grow, the natural earth surface. Sensors should be located at a distance of at least four times the height of any nearby obstruction and at least 30 m (98.43 ft) (EPA) from large paved areas. Sensors should be protected from thermal radiation, and adequately ventilated.
T107 Weather Station Cut Lower Flap Edge First FIGURE 1-2. Cut Flap Packing Tape Top Packing Foam Layer Middle Packing Foam Layer T107, Top Layer T107, Bottom Layer Bottom Packing Foam Layer FIGURE 1-3.
T107 Weather Station Crossarm with Rain, Solar, and Temp/%RH Sensors Enclosure Wind Set Instruction Manual Cardboard Containing Wind Vane FIGURE 1-4. T107 with the Met One 034B-ETM Wind Sensor, Top Layer Mounting Template Grounding Wire and Enclosure Desiccant Packs Mounting Bolts and Hardware Enclosure Battery 2-Piece Pole Grounding and Lightning Rod Temp/%RH Gill Radiation Shield FIGURE 1-5.
T107 Weather Station ⇒ Securely tape box shut if transporting entire station to another site. If at the main site, remove any communication components that are installed at the calling computer. Repackage remaining components for transport to field site. Solar panel and RF items (if any) will be packed in a separate box. • Several days prior to the planned installation date… ⇒ Collect tools and site information (Section 1.3, Tools Required, and Section 1.
T107 Weather Station 1.3.
T107 Weather Station 1.5 Determining True North for Wind Vane Orientation Magnetic declination, or other methods to find True North, should be determined prior to installing the weather station. True North is usually found by reading a magnetic compass and applying the correction for magnetic declination*; where magnetic declination is the number of degrees between True North and Magnetic North.
T107 Weather Station FIGURE 1-7. Declination Angles East of True North Are Subtracted From 0 to Get True North FIGURE 1-8. Declination Angles West of True North Are Added to 0 to Get True North 1.5.1 Web Calculator Since magnetic declination fluctuates with time, it should be determined each time the wind sensor orientation is adjusted. It can be accessed at: www.ngdc.noaa.gov/geomag-web Below is an example for Logan, UT.
T107 Weather Station A positive declination is east, while a negative declination is west. The declination in this example is 12º 24′ or 12.4º. As shown in FIGURE 1-6, the declination for Logan, UT is east, so True North for this site is 360 – 12.4, or 347.6 degrees. References EPA, (1987). On-Site Meteorological Program Guidance for Regulatory Modeling Applications, EPA-450/4-87-013. Office of Air Quality Planning and Standards, Research Triangle Park, North Carolina 27711. 1 WMO, (1983).
T107 Weather Station 2. Hardware Installation DANGER Do not install near power lines. If any part of the tower comes in contact with power lines you could be KILLED. Contact local utilities for the location of buried utility lines before digging or driving grounding rods. CAUTION Do not fit the 3 meter ET Tower sections together until the appropriate time. Once attached, they cannot be detached. The ET Tower provides a support structure for mounting the T107 weather station components.
T107 Weather Station 2.1 NOTE User supplies valve box at base of station and weatherproof enclosure for transformer. See FIGURE 2-1. NOTE The AC power supply option at one time included a step-down transformer instead of the power supply. Appendix E provides information about using the step-down transformer. Base Foundation 2.1.
T107 Weather Station FIGURE 2-2. ET Tower Base Installation Anchor Bolt FIGURE 2-3.
T107 Weather Station 2.1.3 AC Power Installation a) The currently-available AC power option includes a 100 to 240 Vac to 24 Vdc power supply (see note below). The power supply should be mounted inside a user-supplied junction box according to local electrical codes. Dangerous electrical accidents may be avoided by locating the transformer remotely and burying a low voltage line to the station. The low voltage will carry up to 500 feet on an 18 AWG power cable.
T107 Weather Station horizontally. Place a piece of scrap wood over the very end of the top section of the pole and gently hammer on the scrap wood to fit the two halves together. A 1.27 cm (1/2 in) gap between the top and bottom pole sections is acceptable. Lay the assembled pole on the ground next to the concrete foundation. NOTE 3. Cut and save a 9 inch piece of 12 AWG ground wire from the 12 foot length provided.
T107 Weather Station 4 AWG Wire Ground Rod FIGURE 2-5. Close up of Ground Rod and 4 AWG Cable 2.2.3 Tower Grounding 2.2.3.1 Supplied Components (1) 5 foot 4 AWG Ground Cable (1) Copper Ground Lug, Bolt (1) Ground Rod, Clamp 2.2.3.2 Grounding Procedure Ground the tower as shown in FIGURE 2-4 and FIGURE 2-5. 1. Place the ground rod clamp on the ground rod. Secure it about 3 inches from the top. Do this before the rod is driven into the ground. Be careful not to damage the clamp with the hammer 2.
T107 Weather Station 2.3 Enclosure The weather station datalogger, power supply, sensor connection panel, communications devices, and data retrieval peripherals are mounted in the ET enclosure. Refer to Appendix C.1, Enclosure, for a labeled, exploded view of the enclosure. Crossarm Lightning Rod Pyranometer Tipping Bucket Rain Gage Met One 034B Wind Set ET Enclosure Radiation Shield Ground Rod FIGURE 2-6. T107 Instrumentation Mounted on the ET Tower 2.3.1 Enclosure Installation 1.
T107 Weather Station 2 – 2.5 cm Power Cable (if using AC transformer) Ground Wire COM Cable (if using phone or short-haul modem) FIGURE 2-7. Enclosure Spacing Above Pole 2.4 Crossarm and Sensor Installation Refer to Appendix C.2, Crossarm, for a labeled, exploded view of the crossarm. 2.4.1 Components (1) T107 Crossarm with Sensors (see FIGURE 2-6) (1) Met One 034B or Gill WindSonic Wind Sensor (1) White Mounting Shaft for 034B or Gill WindSonic (1) Gill Radiation Shield 2.4.
T107 Weather Station FIGURE 2-8. T107 Sensor Arm Mounting 1) Remove the front lid and the protective connector cover from the back of the ET enclosure by loosening the one Phillips screw at the bottom of the cover. 2) Place the sensor arm on top of the enclosure, lining up the four threaded holes on the under side of the arm with the four holes in the top of the enclosure. Attach the arm to the enclosure by inserting and tightening four Phillips head screws.
T107 Weather Station 2.4.3 RH and Temperature Radiation Shield 1. Remove the two knurled thumb screws taped underneath the crossarm. 2. Remove the yellow shipping cap from off the end of the temperature/relative humidity sensor. See FIGURE 2-9 and FIGURE 2-10. Adapter Temperature and RH Sensor Yellow Cap (remove) Radiation Shield FIGURE 2-9.
T107 Weather Station Temperature and RH Sensor without Cap FIGURE 2-10. Temperature/Relative Humidity Sensor without Yellow Protective Cap 3. Insert the temperature/relative humidity into the gill radiation shield until it stops. 4. Attach the gill radiation shield to the underside of the crossarm using the two knurled thumb screws from step 1. 2.4.4 034B Wind Sensor (Wind Sensor Option –MW) 1.
T107 Weather Station Temp/% RH Gill Radiation Shield Knurled Thumb Mounting Screws FIGURE 2-11. Wind and RH/Temperature Sensor Installation Wind Vane Counter Weight Shoulder Screw South Alignment Sticker Alignment Screw Mounting Pipe FIGURE 2-12.
T107 Weather Station WARNING The wind vane can be easily damaged if dropped or bent. Leave the wind vane in the protective cardboard sleeve until it’s ready to be installed. 2. Remove the alignment screw at the base of the 034B-ET (FIGURE 2-12). Insert the 034B into the 034B Mounting Shaft. Align the hole in the shaft with that in the 034B base and replace the screw. Do not overtighten the alignment screw. Do not remove the shoulder screw at this time. 3.
T107 Weather Station Loosen Screws FIGURE 2-13. Screws that Secure the Electronics Cover 4. Remove the electronics cover to expose the PCB (see FIGURE 2-14). Lift Here FIGURE 2-14.
T107 Weather Station 5. Move the jumper at the top of connector PC board so that it is placed over the center and right pins (see FIGURE 2-15). New Jumper Position FIGURE 2-15. Jumper Set for WindSonic1 6. Replace electronics cover. 7. Tighten screws. 8. Reattach 10588 ribbon cable to the CS I/O port. 9. Replace enclosure cover. 2.4.5.2 Attachment to Sensor Arm 24 1. Remove the three Phillips screws from the end of the white mounting shaft.
T107 Weather Station FIGURE 2-16. Gill WindSonic Mounting Shaft 3. Slide the connector and cable up through the center of the mounting shaft. Plug the cable into the Gill WindSonic sensor. The connector has a key and needs to be pushed in then rotated clockwise to lock it in place. See FIGURE 2-17. FIGURE 2-17.
T107 Weather Station 4. Center the Gill WindSonic over the three threaded screw holes on the mounting shaft and screw it in place using the three Phillips screws taken off the shaft in step 1. 5. Slide the shaft and sensor back through the U-bolt. Align the sensor with north by pointing the small colored dot on outer edge of the bottom of the sensor so it faces true north. Space the sensor about 25.4 cm (10 in) above the crossarm and tighten down the U-bolt. 2.4.
T107 Weather Station 2.4.7 Pyranometer Level the pyranometer as indicated in FIGURE 2-19. Adjust the three leveling screws until the bubble level indicates plumb. Remove the red or green shipping cap from the pyranometer. See FIGURE 2-20. Leveling Screws FIGURE 2-19. Pyranometer Leveling Remove Cap FIGURE 2-20.
T107 Weather Station 2.4.8 Sensor Connections Sensor schematics are provided in Section 4.3.1, Sensor Schematics. 1. WARNING Each sensor cable plug attaches to a unique bulkhead connector as shown in FIGURE 2-21. The sensor cables are individually marked to match up with the sensor labeling on the back of the enclosure. The 034B Wind Sensor plugs into the connector labeled WS/WD. Plugging this sensor in the connector labeled SDI-12 may damage the sensor and/or the main enclosure connector board.
T107 Weather Station NOTE It’s very important that each plug is completely seated on to the connector and the locking ring turned 1/4 revolution clockwise. Failure to seat the plug completely could cause corrosion and water damage to both the enclosure and the sensor cable. NOTE Notice how the sensor caps are slid between the connector and the one above in FIGURE 2-22. This will keep the caps out of the way of the connector cover. FIGURE 2-22.
T107 Weather Station 2.4.9 Sensor Verification and Clock Set NOTE The T107 comes with a default program (see Appendix D). NOTE Use standard time in the station if calculating evapotranspiration (ETsz). Do not use daylight savings time. Additional Station Communication Options: a) The station can be accessed directly using a CR1000KD keypad display at the weather station. Plug the keypad into the extra plug coming off the 9-pin connector marked “CS I/O”.
T107 Weather Station NOTE Connects with phone modem’s RJ-11 patch cord Connects with Rad modem’s 4-wire patch cable It’s best to use Device Configuration Utility (DevConfig) and connect directly to the station to change the CR1000 configuration. DevConfig is included with LoggerNet and can be obtained, at no charge, from our website. Connects with a phone modem, Rad modem, or RF450 radio via the 10588 ribbon cable Connects with a laptop via an RS-232 serial cable FIGURE 2-23.
T107 Weather Station 2.5.2 Phone Modem Phone modems enable communications between the ET Enclosure and a Hayes compatible modem at your PC over a dedicated phone line. Phone line surge protection is built into the ET Enclosure. By default, the COM220 phone modem is configured for SDC7. RJ-11 Patch Cord Connects with RJ-11 Jack Ground Wire 10588 Ribbon Cable FIGURE 2-24. Phone Modem Mounting and Connections (battery not shown) 2.5.2.
T107 Weather Station 2. Connect the modem 9-pin port to the ET Enclosure CS I/O port with the pn 10588 ribbon cable supplied with the ET Enclosure (see FIGURE 2-23 and FIGURE 2-24). 3. Connect the modem RJ-11 jack to the ET Enclosure RJ-11 jack with the RJ-11 patch cord (see FIGURE 2-24). 4. Connect the modem ground terminal block (GND) to the ET Enclosure ground with the 14 AWG ground wire. 2.5.2.
T107 Weather Station Rad Short Haul Modem SC932C 10588 Ribbon Cable (see Figure 2.5-4 for wiring) 12” 4-Wire Patch Cable (see Figure 2.5-4 for wiring) FIGURE 2-25. Short-haul modem mounting and connection 2.5.3.1 Internal Installation NOTE If the short haul modem was ordered with the T107, you can skip this section and go directly to Section 2.5.3.2, External Installation.
T107 Weather Station Install the short-haul modems as shown in FIGURE 2-25 and FIGURE 2-26. WARNING 1. Mount the Rad / SC932C mounting bracket into the ET Enclosure with the three pre-threaded screws provided. 2. Connect the Rad Modem and SC932C. Strap them into the mounting bracket under the Velcro strap. 3. Connect the SC932C 9-pin port to the internal ET Enclosure CS I/O port with the pn 10588 Ribbon Cable supplied with the ET Enclosure (see FIGURE 2-25). 4.
T107 Weather Station 2) Mount the surge protector box to a flat surface within 5 feet of the PC’s serial port. Ground the center terminal to an earth (or building) ground using the 14 AWG wire. 3) Connect the 5-foot patch cable from the surge box to the Rad Modem. Fasten the cable to the strain relief tab with a cable tie. Connect the Rad to the PC’s serial port with the 9-to-25 pin serial cable. 4) Route the user-supplied cable from the remote splice to the surge protector.
T107 Weather Station amp-hour battery to 80% capacity (5.6 amp-hours). Discharging the battery past this value could result in damaging the battery. Polling the station once every 10 minutes and staying on line with the station for one minute consumes approximately 1.276 amps over a 24 hour period. If the station were to lose power it could run for around 4.3 days (105 hours) before damaging the battery.
T107 Weather Station NOTE Power the station down by flipping the PS100 power switch to “Off” before installing any communication option. Remember to flip the switch back to “On” after enclosure installation is completed. 1. Mount the RF450 bracket and radio into the ET enclosure using the three existing screws. See FIGURE 2-27. 2. Thread the smaller SMA connector end of the enclosure antenna cable underneath the battery cables and screw it to the RF antenna connector on the RF450 radio.
T107 Weather Station 2.5.4.4 External Installation The following components are provided with the RF450 radio kit for antenna installation on the ET pole: (1) 14241 Antenna Cable – 59 inch (1) 18290 ET Antenna Adjustable Angle Mounting Bracket (1) 17492 5/16-18 X 2.125 Stainless Steel U-bolt (1) 17851 CM230 Saddle Bracket (4) Silicon Bronze 5/16-18 Nuts (4) 4365 5/16 Stainless Steel Washers (4) 4366 5/16 Stainless Steel Lock Washers (4) 17592 14.
T107 Weather Station FIGURE 2-30. Loosely Drape Antenna Cable over Back of Enclosure 3. Use the 2.125 stainless steel U-bolt to attach the adjustable angle mounting bracket to the pole. Depending on the size of the antenna position the bracket directly below, or above, the enclosure top mounting bracket. The top of an omni directional antenna should not be higher than the top of the lightning rod.
T107 Weather Station FIGURE 2-31.
T107 Weather Station FIGURE 2-32. Antenna Bracket Mounted to Pole 4. Mount the saddle bracket to the adjustable angle mount bracket by inserting the ends of the bracket through the quarter circle notches. Put a flat washer, lock washer, and a silicon bronze nut, in that order, on the ends of the saddle bracket. Do NOT tighten down the nuts at this time. FIGURE 2-33.
T107 Weather Station NOTE Only rotate enclosure if needed to allow aiming of the Yagi antenna to the base antenna. Keep solar radiation sensor towards the South as much as possible. Rotate wind sensor to realign as needed. 5. NOTE Use the following procedure to install the 14205 Yagi antenna for the RF450. Installation of the 14221 Omni antenna is similar. See FIGURE 2-36. Mounting hardware that comes in the box with the Yagi antenna will not be used. i.
T107 Weather Station iii. Adjust the antenna cable at the BNC connector so the cable cover fits over all the sensor cables as well as the antenna cable. You may have to gently bend the antenna cable to put a 90° bend by the BNC connector end of the cable. Take the cover off when you’re done. iv. Use one of the black wire ties to strap the antenna cable to the bundle of sensor cables. v. Tighten up the wire ties holding the antenna cable to the wire tie mount at the top of the enclosure. vi.
T107 Weather Station Wire Tie Wire Tie FIGURE 2-36. Wire Tie Locations for Omni Antenna Installation 2.5.4.5 Base Radio Installation The base radio kit comes with the following items. (1) 10873 RS-232 Serial Data Cable with 6 feet of cable (1) 15966 Wall Adapter: 100 to 240 Vac, 50-60 Hz Input to 12 Vdc 80 0mA Output with 6 feet of cable. (1) 18327 RF450 900 MHz, 1 W Spread Spectrum Radio (1) 20617 900 MHz 0 dBd Omnidirectional Window Mount Antenna with 79 inches (6.
T107 Weather Station Attach the serial cable from the calling computer’s serial port to the port marked “RS-232” on the RF450. Plug the wall adapter into a wall outlet and plug the barrel connector into the RF450 connector marked “DC POWER 728V”. You should see the lights on the radio come on. FIGURE 2-37. Base RF450 Installation FIGURE 2-38.
T107 Weather Station 2.6 Lightning Rod Installation Install lightning rod as shown in FIGURE 2-39 and FIGURE 2-40. 1. Carefully mount the lightning rod clamp to the top of the pole (see FIGURE 2-39). Position the clamp so it won’t interfere with the connector cover. FIGURE 2-39. Lightning Rod Bracket Installation 2. Strip 2.54 cm (1 in) from the top of the main green 10 AWG tower ground wire. Insert the exposed wire into the empty clamp opening. Do not tighten the screw at this time (see FIGURE 2-40).
T107 Weather Station FIGURE 2-40. Grounding to Lightning Rod Clamp 48 3. Strip 2.54 cm (1 in) from both ends of the 23 cm (9 in) piece of 10 AWG green ground wire. Insert one end into the enclosure ground lug located at the top back of the enclosure. Put the other end in the same clamp opening as the main grounding wire and tighten down the screw (see FIGURE 2-40). 4. Insert the lightning rod into the empty clamp opening. The milled flat side of the lightning rod should face the clamping screw.
T107 Weather Station 2.7 Solar Panel Installation FIGURE 2-41. Solar Panel Mounting and Cabling a) Mount the solar panel to the tower using the mounting brackets as shown in FIGURE 2-42. Mount the solar panel to the tower so it faces south (northern hemisphere). Position it as high off the ground as practical, ensuring it cannot interfere with air flow or sunlight around the sensors. The solar panel should be oriented to receive maximum insolation over the course of the year.
T107 Weather Station α FIGURE 2-42. Side View of Solar Panel Shows Tilt Angle b) After determining the tilt angle, loosen the two bolts that attach the mounting bracket to the panel. Adjust the angle, then tighten the bolts. Secure the lead wire to the mast using wire ties as show in FIGURE 2-42. Connect the plug at the end of the solar panel cable to the connector marked “Power”. Make sure the plug is fully seated and the locking ring turned clockwise until it stops.
T107 Weather Station 2.8 Battery Installation Power Switch FIGURE 2-43. PS100 Battery Installation The PS100 power switch should be in the “OFF” position. To install the battery, remove the cover from the PS100 by sliding the latch up at one end of the cover and sliding the cover down and out. Install the battery as shown in FIGURE 2-43. Plug the battery lead into the connector labeled “BATTERY – Internal 12V 7 Amp-Hour”. Put the cover back on the PS100 and latch it in place.
T107 Weather Station 2.9 Restraining Cables and Sealing/Desiccating Enclosure 2.9.1 Restraining Cables 1. Loosely wire tie power, communication, and grounding cable to the wire tie harness at the top of the back of the station. Do NOT clip back the wire tie at this time. See FIGURE 2-45. Wire Tie Harness FIGURE 2-45. Cabling Strapped to Wire Tie Harness 2. 52 Replace the connector cover. The tab at the top of the connector cover slides into the opening on the back of the cross arm.
T107 Weather Station FIGURE 2-46. Connector Cover in Place 6. Tighten down the wire ties holding cabling to the wire tie harness and clip off any excess. See FIGURE 2-46. 2.9.2 Sealing and Desiccating the Enclosure The ET Enclosure is supplied with two desiccant packs. The desiccant maintains a low humidity in the enclosure to minimize the chance of condensation on the instrumentation. Desiccant should be changed when the internal ET Enclosure humidity sensor measures 50% or higher.
T107 Weather Station Desiccant FIGURE 2-47. Desiccant Installation 3. ET Software NOTE The T107 comes with a default program, and typically does not require additional programming (see Appendix D). A variety of different software packages are available to work with the T107 station. This section introduces software packages that can be used with the T107 station. It is not the goal to fully explain capabilities of each package. All software packages mentioned below come with extensive help files.
T107 Weather Station VisualWeather version 3.0 or higher is designed to work with the T107 station and can be used to create programs, monitor present conditions, collect data, and create reports and graphs. VisualWeather is designed to be a very user friendly program. No datalogger experience is needed to use it. VisualWeather will communicate with a direct connect, short-haul modem, RF radio, or phone modem station. Call Campbell Scientific for pricing.
T107 Weather Station 4.1.3 Desiccant Humidity is monitored inside the T107’s enclosure using the Elan HM2000 (pn 10070) RH sensor that is incorporated in the enclosure. Change the desiccant packs when the enclosure RH exceeds 50%. The enclosure RH sensor should be changed every 5+ years. The enclosure RH is displayed in Toro T.Weather software. Desiccant packs may be ordered in quantity of 20 individually sealed packs at a time (pn 6714) or by the individual pack (pn 4905).
T107 Weather Station filter in the cup of water. Remove the filter and allow to air dry before putting it back on the end of the sensor. 6 months • Replace 034B-ET’s anemometer bearings and reed switch if operating under harsh conditions, such as constant high winds, blowing dust, and/or salt spray contamination. 1 year NOTE • Replace 034B-ET wind speed (anemometer) bearings (pn 3648). Contact your local Toro distributor for service.
T107 Weather Station 2 years • Replace 034B-ET’s vane potentiometer if needed (call for part number and price). Contact your local Toro distributor. • Replace enclosure gasket if necessary. Contact your local Toro distributor. 3 years • Send the solar radiation sensor (pyranometer) for calibration. Contact your local Toro distributor. Sensor cannot be calibrated in the field. (Some users recommend calibrating this sensor on a yearly basis.
T107 Weather Station Replace the battery when voltage is approximately 2.7 V. If the lithium cell is removed or allowed to discharge below the safe level, the T107 will still operate correctly while powered. Without the lithium battery, the clock will reset and data will be lost when power is removed. Contact your local Toro distributor. CAUTION Toro recommends factory replacement of the lithium battery. Misuse of the lithium battery or installing it improperly can cause severe injury.
T107 Weather Station 4.2.2 No Response from Datalogger through SC32B, RAD Modem, or Phone Modem At the datalogger: A. Make sure the battery has been installed and the power switch set to “ON” (Section 2.8, Battery Installation). B. Use a voltmeter to measure the voltage on the 12V and G terminals (see FIGURE 2-44); the voltage must be between 9.6 and 16 Vdc. Use a voltmeter to measure the voltage on the 5V and G terminals (see FIGURE 2-44); the voltage must be between 4.9 – 5.1 Vdc. C.
T107 Weather Station C. If Short Cut or VisualWeather is used to create the station program double check the wiring diagram to see if it matches the physical wiring on the sensor connectors on the back of the enclosure. If CRBasic is used to create the station program verify channel assignments and multipliers. 4.2.4 Unreasonable Results Displayed in a Variable A. Inspect the sensor for damage and/or contamination. B.
T107 Weather Station TABLE 4-2.
T107 Weather Station Radios not networked together, not communicating: 1. Check the baud rate of all RF450s; they should be the same. 2. Check Network IDs of all RF450s; they should be the same. 3. Check Frequency Key Number of all RF450s; they should be the same unless two branches of the network are operating in a parallel manner. 4. Check the “Repeaters Used” box for all RF450s. 5. Check the PakBus address of dataloggers connected to RF450s and in LoggerNet. 6.
T107 Weather Station TABLE 4-3. Gill WindSonic Diagnostic Codes 4.
T107 Weather Station FIGURE 4-4. Schematic of 034B-LC Wind Speed and Direction Probe and Connector WS/WD *Jumper P19 must be jumpered across pins 2 (center) and 3 (right). FIGURE 4-5.
T107 Weather Station Apogee Solar Radiation Sensor 10 to 20 OHMS FIGURE 4-6. Schematic of CS305-ET Solar Radiation Sensor and Connector Solar Radiation NOTE 66 The T106 used a Licor LI200X-ET Solar Radiation Sensor with OHM readings of 450 to 650.
T107 Weather Station Rain (Precip) FIGURE 4-7.
T107 Weather Station FIGURE 4-8. Schematic of 107-LC or 108-LC Temperature Probe or CS616-LC Soil Volumetric Water Content Sensor and Connector Temp/CS616 FIGURE 4-9.
T107 Weather Station 4.3.2 Power Schematics FIGURE 4-10. Schematic of Solar Panel and Connector Power 4.3.3 Communication Modems Schematics FIGURE 4-11.
T107 Weather Station 70
Appendix A.
Appendix A.
Appendix B. PS24 24 Ahr Power Supply and 10 x 12 inch Enclosure The PS24 Power Supply is typically used when the T107 transmits data via RF450 Spread Spectrum Radios. However, the PS24 can be used for any situation where a larger capacity battery is desirable. B.1 S24 Components The PS24 consists of a 24 Ahr rechargeable battery, CH100 regulator, and a 10 inch x 12 inch environmental enclosure (see FIGURE B-1 through FIGURE B-3). The battery should be recharged via ac power or solar power.
Appendix B. PS24 24 Ahr Power Supply and 10 x 12 inch Enclosure FIGURE B-2.
Appendix B. PS24 24 Ahr Power Supply and 10 x 12 inch Enclosure FIGURE B-3.
Appendix B. PS24 24 Ahr Power Supply and 10 x 12 inch Enclosure B.2 Installation CAUTION CAUTION The PS24 is purposely shipped without the battery mounted in its bracket. Do not install the battery until instructed to do so. 1. Place the top enclosure bracket on the pole at approximately 40 inches above the bottom of the pole. The bracket should be installed with the hook side up, and facing north. 2. Slide the strut clamps into the bracket as shown in FIGURE B-4.
Appendix B. PS24 24 Ahr Power Supply and 10 x 12 inch Enclosure 3. Place the bottom strut clamp and bracket approximately 12 inches below the top clamp. This clamp is installed with the hook side down. The bracket might have to be moved a little to accept the enclosure bracketing, so don’t tighten the bracket yet. FIGURE B-5 shows the top and bottom brackets correctly positioned on the T107 pole. FIGURE B-5.
Appendix B. PS24 24 Ahr Power Supply and 10 x 12 inch Enclosure 4. Hook the enclosure on the top bracket as shown in FIGURE B-6. FIGURE B-6.
Appendix B. PS24 24 Ahr Power Supply and 10 x 12 inch Enclosure 5. CAUTION The bottom enclosure bracket should slide between the top lip of the bottom strut mount bracket and the notch directly below. Move the bottom bracket if necessary, then bolt the bottom bracket down (see FIGURE B-7). Do NOT over tighten the bottom bracket. FIGURE B-7.
Appendix B. PS24 24 Ahr Power Supply and 10 x 12 inch Enclosure 6. NOTE The bottom enclosure bracket has a small metal locking mechanism. Push up on the small Phillips screw underneath the mechanism and slide it to the left. Once in place, put a small wire tie in the hole to the right of the locking mechanism (see FIGURE B-8). To remove the enclosure from the bracketing, cut off the wire tie, slide the lock to the right, and lift the entire enclosure off the bracketing. FIGURE B-8.
Appendix B. PS24 24 Ahr Power Supply and 10 x 12 inch Enclosure 7. Install the solar panel above the 10 x 12 enclosure, and face the solar panel south. See FIGURE B-9 for fully mounted solar. FIGURE B-9. Mounted Solar Panel IMPORTANT 8. Throw a blanket or box over the solar panel to prevent any voltage output. 9. Route the solar panel cable and power cable coming from the main T107 enclosure into the conduit at the bottom of the 10 x 12 enclosure.
Appendix B. PS24 24 Ahr Power Supply and 10 x 12 inch Enclosure 10. Wire the solar panel to the CH100 terminal blocks as follows. Solar Panel to CH100 Red: CHG Black: CHG NOTE Polarity makes no difference. Connect one wire per CHG terminal block. 11. Remove the blanket or box from the solar panel once it’s wired in place. 12. Wire the power cable coming from the T107 station as follows.
Appendix B. PS24 24 Ahr Power Supply and 10 x 12 inch Enclosure 13. Follow the Installation of Battery procedure provided in FIGURE B-10. Plug the battery into the connector on the CH100 marked “INT”. FIGURE B-10. Procedure for installing and connecting battery 14. An extra loop of ground wire was sent with the station. Use it to ground the enclosure to the grounding rod system. The external ground lug is mounted on the bottom left hand corner of the 10 x 12 enclosure. 15.
Appendix B. PS24 24 Ahr Power Supply and 10 x 12 inch Enclosure CAUTION The enclosure needs to be sealed up tight so don’t be stingy with the putty. 17. Put both bags of desiccant inside of the enclosure. 18. Stick the humidity indicator card on a wall inside of the enclosure. CAUTION Pink on the humidity indicator card means it’s time to change the desiccant. Change the desiccant at least every year. However, it’s often wise to change the desiccant every six months. 19. Close the enclosure lid.
Appendix C. Exploded Views C.
Appendix C. Exploded Views C.
Appendix D. Default Programs D.1 Program for T107 with 034B 'Program name: C:\TORO\T107_034B.CR1 'Programmer: Bart Nef - CSI 'Date: 4.Nov.2010 'Ver: C 'Notes: Toro T107_034B program to work with both the Toro software and Eicon. 'Changes from A (22.Jan.2007) to B: Corrected multiplier to convert wind speed in m/s to mph. 'Changes from B (25.Jan.
Appendix D.
Appendix D. Default Programs PortSet(9, 0) AirTempF = AirTempC * 1.
Appendix D. Default Programs D.2 Program for T107 with Gill WindSonic 'Program name: C:\TORO\T107_GILL.CR1 'Programmer: Bart Nef - CSI 'Date: 7.April.2011 'Ver: D 'Notes: Toro T107_GILL program To work with both the Toro software AND Eicon. 'Changes from version A to B: Corrected the method used to read the Gill wind sonic. 'Customer must have version 13 OS in their CR1000 to use this program! 'Changes from version B to C: Updated the method used to read the Gill wind sonic.
Appendix D.
Appendix D. Default Programs Battery (BattVolt) 'Micrologger temperature PanelTemp (LgrTmpC,250) 'Save Site Values If SaveSite = 1 Then CallTable SiteVal SaveSite=0 EndIf 'Query Site Values from data table and use if needed. If Latitude = 0.00001 AND SiteVal.Latitude(1,1)<> NAN Then Latitude=SiteVal.Latitude(1,1) Longitude=SiteVal.Longitude(1,1) Altitude_m=SiteVal.Altitude_m(1,1) EndIf 'Enclosure humidity VoltSe(Encl_RH, 1, mV2500, 10, False, 0, _60Hz, 0.
Appendix D. Default Programs If (ToroStatus.Output(1,1)) Then Rain24 = RainRun RainRun = 0 ETos24 = ETos_Run ETos_Run = 0 Max24Air = MaxAirC Min24Air = MinAirC MaxAirC = AirTempC MinAirC = AirTempC 'Watchdog counts WatchDog = Status.WatchdogErrors(1,1) 'Skipped scan counts Overruns = Status.SkippedScan(1,1) 'Low voltage counts LowVolts = Status.Low12VCount(1,1) 'Lithium battery voltage LiBattV = Status.
Appendix D.
Appendix E. Step-down Transformer Installation This appendix is for users who have a step-down transformer instead of the 100 to 240 Vac to 24 Vdc power supply. User-Supplied Valve Box Swept Elbow Conduit FIGURE E-1. ET tower installation with step-down transformer NOTE User supplies valve box at base of station and weatherproof enclosure for transformer. See FIGURE E-1. 1. The AC power option at one time included a 120 Vac to 16 Vac step-down transformer.
Appendix E. Step-down Transformer Installation 4. CAUTION E-2 Connect the power plug to the connector marked “Power” on the back of the enclosure. See FIGURE 2-21. The splice and wire nut must be completely immersed into the silicon gel inside the splice tube to be waterproof.
