EN INTRODUCTION Read this manual carefully as it offers practical advice to help you get the most from your washing machine. This Instruction Manual contains everything you need to know about the everyday running of your machine. Keep it for future reference. An Installation and Maintenance Manual is also provided which you should consult during the installation and routine maintenance of your washing machine.
INDEX page GUARANTEE .............................................................................. 29 TECHNICAL DATA ....................................................................... 30 OPENING THE LID – LOADING ................................................ 31 DETERGENT DISPENSER ........................................................ 32 AUTOMATIC VARIABLE CAPACITY - FUZZY LOGIC ELECTRONICS ........................................................................... 33 PROGRAMME SELECTION ........
GUARANTEE 1. The appliance comes with a guarantee certificate. A 2. Complete part A and keep it in a safe place. It should be presented to the Technical Assistance Centre in the event of a repair being necessary along with the legal receipt issued by the dealer on purchase.
TECHNICAL DATA CTE 101 Load capacity ........................................................................ kg. Voltage ..................................................................................... V. Wash motor power rating ........................................................ W. Spin motor power rating .......................................................... W. Electropump power rating ....................................................... W. Heating element power rating ................
OPENING THE DRUM 1. Lift the lid (A) and open it completely. Next, open the drum door following these instructions: E T OF TH HINE FRON AC ING M WASH E T OF TH HINE FRON AC ING M WASH E T OF TH HINE FRON AC ING M WASH 3. Open the rear door (D). Open the front door (C). Place the washing in the drum. 4. Close the front door (C). Close the rear door (D) so that the front door (C) fasteners fit perfectly into the slots. 5. Ensure that the doors fit together perfectly and are properly closed.
DETERGENT DISPENSER The detergent dispenser is divided into 4 compartments: • Compartment I, is for prewash powder detergent. The recommended quantity is 60 gm of detergent (for 5 kg of laundry). • Compartment II, is for wash powder detergent. The recommended quantity is 120 gm of detergent (for 5 kg of laundry). • The compartment is for bleach. The recommended quantity is 7 cl. • The compartment is for fabric conditioners, scenting agents and special additives. The recommended quantity is 5 cl.
AUTOMATIC VARIABLE CAPACITY – FUZZY LOGIC ELECTRONICS This machine has electronics that automatically process all stages of the wash to ensure exceptional results and at the same time save you time and money.
CONTROL DESCRIPTION CTE 101 Programme selector knob ........................................................... A Temperature selector knob ......................................................... B Spin selector ............................................................................... C Easy-iron button ......................................................................... D Super rinse button ......................................................................
USE OF THE SELECTION CONTROLS A. PROGRAMME SELECTOR KNOB This control allows you to select the washing programmes. Turn the selector so that the number or symbol of the desired programme is opposite the reference indicator (p). ALWAYS ROTATE the control in a clockwise direction, never in an anticlockwise direction. Do not press the “on” button (H) before selecting the programme.
USE OF THE SELECTION CONTROLS D. EASY IRON BUTTON This function helps reduce creasing, depending on the programme selected and the type of fabric washed. MIXED FABRICS: - the water is cooled gradually to prevent heat shock - the drum is not moved mechanically during emptying - a mild spin is used to ensure that fibres are smoothed out as much as possible. DELICATE FABRICS (OTHER THAN WOOLLENS): - The machine operates as indicated above and stops with the drum full of water after the last rinse.
TABLE OF PROGRAMMES APRROX. TIME (min) 32 INTENSIVE WITH PREWASH 5 170 1 NORMAL SOILING 5 140 2 Rapid 32 minute super cycle EXTREM. DELIC, FABRICS SEL. TEMP.
NOTE: 1. If the wash load is very dirty it is best to reduce the load weight to 3 kg. 2. Programmes 1-2have an automatic bleaching option. Simply place the bleaching agent in the compartment. 3. The washing machine is designed to incorporate fabric softener automatically in the last rinse of each washing cycle. 32’ FAST PROGRAMME This programme runs through a full wash cycle for a maximum of 2 kg of washing at 50 ºC in just 32 minutes. Put the detergent in dispenser I.
