Model 1202 Chassis Interconnect Module User Manual
EdgeAccess Universal Chassis System NOTICE! This device contains static sensitive components. It should be handled only with proper Electrostatic Discharge (ESD) grounding procedures. NOTE! Cet équipement contient des composants sensibles aux décharges électro-statiques. Il doit absolument être manipulé en respectant les règles de mise à la terre afin de prévenir de telles décharges.
EdgeAccess Universal Chassis System Table of Contents Chapter 1 Introduction ........................................................................................... 1-1 1.1 1.2 Overview................................................................................................................................. 1-1 External Features .................................................................................................................... 1-1 Chapter 2 Installing the CIM ..................
EdgeAccess Universal Chassis System iv Model 1202 CIM User Manual
EdgeAccess Universal Chassis System Chapter 1 Introduction 1.1 Overview The Chassis Interconnect Module (CIM), used in a Universal Chassis System (UCS) 1002 chassis, links up to eight chassis in a domain to provide management and alarm status. This domain can include both UCS 1000 and 1002. Link the chassis in a cascade through the Chassis Link Up and Down ports on the front panel. Figure 1 shows the CIM in its dedicated slot 0 in the chassis.
EdgeAccess Universal Chassis System Figure 2.
EdgeAccess Universal Chassis System Chapter 2 Installing the CIM The CIM is installed in the UCS 1002 chassis in slot 0 at the factory. Occasionally, you may need to install a CIM in a UCS 1002, if ordered separately. 2.1 Install a CIM To install the CIM, follow these steps: 1. If multiple chassis will be linked, set up the chassis ID numbers. For details on setting the Chassis ID switch on each backplane, see the User Manual for the UCS 1002. 2.
EdgeAccess Universal Chassis System All modules in the chassis supply their alarm status to the alarm relay contacts on the CIM. You can connect an external device to the terminal to provide alarm information to a person or an environment away from the chassis. 6. Connect devices to collect alarm information for Major and Minor alarms. The alarm contacts are located on the front panel; see Figure 2. The relay alarm contacts provide both normally open and normally closed contacts for each port: • • • 2.
EdgeAccess Universal Chassis System 2.3.2 Alarm Acknowledgment Pushbutton The Alarm Acknowledgement (ALM ACK) reset pushbutton on the front panel resets the latch for the alarm relay, which can reset the external device connected to the alarm relay terminal block. ALM ACK does not reset or correct the alarm condition and the LED(s) will remain on until the problem is resolved. See Figure 2.
EdgeAccess Universal Chassis System 2-4 Model 1202 CIM User Manual
EdgeAccess Universal Chassis System Chapter 3 Management - VT-100 To connect to and manage the CIM, use either the serial or Ethernet port on an optional DMM and an application such as HyperTerminal. For details about accessing the DMM and using the management software, see the User Manual for the 1500 or 1502 Domain Management Module for your system. 3.1 The CIM Management Screen If the domain includes an optional DMM, you can access the CIM Management screen to view the current status of the chassis.
EdgeAccess Universal Chassis System Field Definition Backplane Alarm Inputs Shows fault conditions in a module in this chassis or in a linked CIM CIM Major Alarms CIM Minor Alarms Shows detected Major or Minor alarm conditions Up Link Installed Down Link Installed Shows connections to other CIMs Lists configuration data CIM Model CIM Firmware CIM Serial Number CIM Hardware Version Note: If Alarm Relay Status is Major or Minor and Alarm Latch Status is off, the alarm condition occurred on a linked ch
EdgeAccess Universal Chassis System Chapter 4 CIM Specifications Physical Specifications Dimensions 3.0"H x 1.0"W x 9.0"D (76.2mm x 25.4mm x 228.6mm) Weight 0.3 lb (0.1 kg) Environment 0° to 50° C Up to 95% Humidity (noncondensing) Power +5.15 VDC, 400 mA maximum Regulatory Compliance • • • • • • • • • • ETL, cETL (CAN/CSA-C22.2 No.
EdgeAccess Universal Chassis System 4-2 Model 1202 CIM User Manual
EdgeAccess Universal Chassis System Appendix A Warranty Limited Lifetime Warranty Effective July 1, 2005 and After, Canoga Perkins warrants that, at the time of sale, and, for its lifetime, with certain exceptions noted below, every Canoga Perkins' labeled product purchased will be free from defects in material and workmanship for its lifetime, if properly installed and used in conformity to Canoga Perkins' published specifications. This warranty covers the original user only and is not transferable.
EdgeAccess Universal Chassis System Limitations Canoga Perkins may at its sole discretion modify its Limited Warranty at any time and from time to time. Other than those expressly stated herein, THERE ARE NO OTHER WARRANTIES OF ANY KIND, EXPRESSED OR IMPLIED, AND SPECIFICALLY EXCLUDED BUT NOT BY WAY OF LIMITATION, ARE THE IMPLIED WARRANTIES FOR FITNESS FOR A PARTICULAR PURPOSE AND MERCHANTABILITY.
EdgeAccess Universal Chassis System Appendix B Glossary These definitions apply to the 1202 CIM.
CANOGA PERKINS CORPORATION 20600 Prairie Street Chatsworth, California 91311-6008 USA Phone: (818) 718-6300 FAX: (818) 718-6312 Web Site: www.canoga.com Email: fiber@canoga.
