User manual

Handling rolls
6. Advance the roll to insert the leading edge in the Paper Feed Slot (a) until you hear a tone.
Important
• Be careful not to soil the printing surface of roll paper as you insert it in the slot. This may af fect
the printing quality . W e recommend wearing clean cloth gloves when handling rolls to protect the
printing surface.
• If the paper is wrinkled or warped, straighten it out before loading it.
• Load paper straight so it is not fed askew .
7. Once paper feeding starts, you will need to do the following, based on the ManageRemainRoll
setting and the barcode printed on rolls. ( → P .126)
ManageRemainRoll
Barcodes
Printer Operation After the Paper is Fed
PrintedOff
Not printed
A menu for selection of the type of paper is automatically
shown on the Display Screen .
Press ▲ or ▼ to select the type of paper , and then press
the OK button.
Printed The type and amount of paper left is automatically
detected based on the barcode printed on the roll.
There is no need to specify the type and length of the
paper .
On
Not printed A menu for selection of the paper type and length is
automatically shown on the Display Screen .
Press ▲ or ▼ to select the type and length of paper
loaded, and then press the OK button.
Note
• For details on types of paper to select, see the Paper Reference Guide . ( → P .95)
108 Handling Paper
