User manual

Free Layout
Prints using Folded Duplex
Allows you to produce duplex printing by combining two pages and folding them.
“Folded Duplex”
Any two pages can be arranged and printed in a layout that becomes duplex on folding.
This can be used such as for advertising posters that are suspended from the ceiling.
1. Select two objects from the layout area of Free Layout.
2. Select Folded Duplex from the “Edit” menu of Free Layout.
Open the Folded Duplex window and arrange the selected objects in the layout area.
3. Open the “Finished Size Settings” dialog box from the “Edit” menu.
4. Select “Fit Roll Paper Width” or “Specify Folded Size” in “Finished Size” .
Note
• “Rotate Page 90 degrees (Conserve Paper)” is also available when “Specify Folded Size” is selected.
5. Click “OK” to save the settings.
6. Open the “Binding Settings” dialog box from the “Edit” menu.
7. Select “Bottom” or “T op” in “Binding Edge” .
8. Specify the “Binding” width in “Binding” .
9. Congure the Fold Line Color and Fold Line T ype from Print Fold Lines .
Note
• When the Only Print Center and Edges checkbox is selected, fold lines are only printed at the
three locations of the center and both edges.
10. Click “OK” to save the settings.
1 1. Conrm the print setting and begin printing.
418 Windows Software
