Messages regarding printing or adjustment
Messages regarding printing or adjustment
Cannot adjust printhead.
Cause Corrective Action
The Printhead nozzles are clogged. Execute Head Posi. Adj. again, as follows.
1. Press the OK button to clear the error .
2. Print a test pattern to check the nozzles.
( → P .630)
3. Clean the Printhead if the nozzles are clogged.
( → P .632)
4. Execute Head Posi. Adj. again.
( → P .604)
The Printhead cannot be aligned; highly transparent
lm is loaded.
Press the OK button to clear the error .
W e recommend using a type of paper that you often
use, other than lm, for Printhead adjustment.
( → P .604)
The Printhead is installed crooked. Straighten the Printhead as follows, and then execute
Head Posi. Adj. again.
1. Press the OK button to clear the error .
2. Use Head Inc. Adj. to adjust the angle of
inclination of the Printhead .
( → P .608)
3. Execute Head Posi. Adj. again.
( → P .604)
Cannot adjust paper feed.
Cause Corrective Action
The Printhead nozzles are clogged. Execute Adj. Quality again, as follows.
1. Press the OK button to clear the error .
2. Print a test pattern to check the nozzles.
( → P .630)
3. Clean the Printhead if the nozzles are clogged.
( → P .632)
4. Execute Adj. Quality again.
( → P .614)
Highly transparent lm is loaded that cannot be used
for automatic feed amount adjustment.
Press the OK button to clear the error , and then
adjust the feed amount manually .
( → P .616)
Error Message 705
