C155L Larder Fridge & C165R 3* Star Fridge INSTRUCTIONS FOR USE Caple Quality Products Consumer Help Line 0870 2411142 Page 1 of 9 C155L C165R user manual.
Thank you for purchasing this Caple appliance which, if these instructions are followed, will give you many years trouble free service. Please keep these instructions for use close at hand and available to anyone other than yourself who may use the appliance. By following all the recommendations made in the instructions you will be able to make the best possible use of your new appliance's facilities.
• Don't put glass bottles or other containers in the freezer compartment as they might crack or break when the contents are frozen. • Avoid flames or sparks inside the equipment. • Do not consume food of which the storage deadline has expired, as this may cause food poisoning. • Do not obstruct the equipment's ventilation openings/grills. • During defrosting, never use metallic objects to accelerate the process.
INSTALLATION • In order to avoid damage to persons or property, the equipment should be installed by two persons. • In the event of damage to the equipment during transport, immediately inform the supplier before proceeding to installation. The equipment must be placed in a dry, well ventilated position. • The equipment must be installed on a flat, stable surface, using the adjustable feet if necessary and following the instructions provided inside the product.
GETTING TO KNOW YOUR REFRIGERATOR The refrigerator you've chosen allows you to preserve fresh food and if it has a freezer compartment (depending on the model) you can also keep frozen food and freeze fresh food (see section on freezing). Temperature regulation The temperature can be regulated in steps by means of the thermostat. Position 0 means equipment operation suspended (off internal light not working) Position 1 means equipment operation at minimum. Position 7 means equipment operation at maximum.
TIPS ON FREEZING • Prevent products to be frozen coming into contact with products that are already frozen. Make sure packets are dry, as this will prevent a number of packets from freezing into a solid block. • Always prepare food in individual portions for faster freezing. • To freeze the maximum quantity of food indicated on the technical data plate, proceed as follows: - set the thermostat to 4-5, 24 hours before freezing.
• • • • Olive oil, seed oil; Butter or other animals fats; Lemon or orange juice Detergents containing acetic acid Prolonged disuse. If you go away for long periods, disconnect the equipment from the mains supply, empty, clean the inside and leave the door open (to prevent bad smells forming). Assistance Malfunction is not always caused by defects in the equipment but may also be due to improper installation or use.
If not necessary, proceed with equipment installation. • • • Unscrew hinges and remove plugs. Invert the parts diametrically. Screw in hinges and insert plugs. REVERSING THE FREEZER COMPARTMENT DOOR (Only C165R) • • • • • • • Unscrew fastening hook and lower hinge. Rotate door and remove from top hole. Remove plugs. Invert parts laterally. Put the pin in the upper hinge. Screw in the lower hinge. Screw in the fastening hook. Page 8 of 9 C155L C165R user manual.
CAPLE "Built-in" Service Should you require service at any time, please contact the Caple Help line on 0870 2411142. Caple have a nationwide service network of engineers who will respond quickly to your call. Always replace spare parts with genuine Caple spares. These are available from authorized Caple Service Centers or by mail order from our National Service Stores, simply telephone 0870 2411142. When ordering parts always quote the model number and serial number of your appliance.
