User guide

1. Specifications
1.5 Exterior
Dimension
Width 150.4mm
Length 99.4mm
Height 2.3.2mm
⑧
⑨⑩⑪⑫
① MODE
② IR
③
POWER
-5-
① ⑥ ⑦② ③ ④ ⑤
③
POWER
④ REAR CAMERA
⑤ RGB-IN(HDMI)
⑥ RGB-IN(NAVI)
⑦ AV IN/OUT
⑧ TO NAVI T/S-OUT
⑨ LVDS OUT
⑪ LED
⑩ TEST
⑫ DIP S/W
