HOSPITALITY SERIES

SELF-LEVELING PLATE DISPENSER CARTS

OWNERS / OPERATORS MANUAL

Part Number: 18400-0005 Printed in The United States of America Rev: KBA010814

TABLE OF CONTENTS

UNPACKING, INSPECTION & FREIGHT DAMAGE…………………. 2

OPERATION & THERMOSTAT ADJUSTMENT……………………… 3

DAILY CLEANING…….………………………………………………….. 4

TIPS FOR CLEANING STAINLESS STEEL…………………………… 4

PLATE LOADING AND SPRING ADJUSTMENT...………………….. 5

REPLACEMENT PARTS………………………………………………… 6

WIRING DIAGRAMS………………………………….………………….. 6-7

MAINTENANCE…………………………………………………………... 8

WARRANTY……………………………………………………………….. 8

MANUFACTURED BY:

CARTER-HOFFMANN

1551 McCormick Avenue

Mundelein, IL 60060 U.S.A.

Phone: 847-362-5500

Fax: 847-367-8981

Toll Free: 800-323-9793

Email: technicalservice@carter-hoffmann.com

EPD

Enclosed Plate Dispenser

2-silo

EPD

Enclosed Plate Dispenser

3-silo

EPD

Enclosed Plate Dispenser

4-silo

Summary of content (8 pages)

PAGE 1
HOSPITALITY SERIES SELF-LEVELING PLATE DISPENSER CARTS OWNERS / OPERATORS MANUAL MANUFACTURED BY: CARTER-HOFFMANN 1551 McCormick Avenue Mundelein, IL 60060 U.S.A. Phone: 847-362-5500 Fax: 847-367-8981 Toll Free: 800-323-9793 Email: technicalservice@carter-hoffmann.com EPD Enclosed Plate Dispenser 2-silo EPD Enclosed Plate Dispenser 3-silo EPD Enclosed Plate Dispenser 4-silo TABLE OF CONTENTS UNPACKING, INSPECTION & FREIGHT DAMAGE…………………. OPERATION & THERMOSTAT ADJUSTMENT……………………… DAILY CLEANING…….
PAGE 2
UNPACKING AND INSPECTION This appliance should be thoroughly cleaned prior to use. See the CLEANING INSTRUCTIONS in this manual. 1. Remove the cabinet from shipping carton, ensuring that all packing materials and protective plastic has been removed from the unit. 2. Inspect all components for completeness and condition. 3. If any freight damage is present, a freight claim must be filed immediately with the shipping company. 4. Freight damage is not covered under warranty.
PAGE 3
OPERATION CAUTION: If you have a heated dispenser, exposed surfaces of the dispenser can be hot and may cause burns ON/OFF switch (heated carts only) CAUTION: PINCH HAZARD Hold dinnerware by the sides when loading the dispenser Holding dinnerware by the bottom can allow fingers to become trapped between the plates and dispenser wall 1) Load the dispenser with the appropriate sized dinnerware Dinnerware which is way too large may be broken or may jam the carriage Dinnerware which is too small cannot b
PAGE 4
DAILY CLEANING PROCEDURES CAUTION: Beware of sharp edges with sheet metal during cleaning process. CAUTION: Do not use steel wool pads as they will result in rusting from the ferrous metal in the pads. CAUTION: If you have a heated dispenser, be sure the dispenser tubes are turned OFF and the cabinet is unplugged from the power source prior to cleaning. The heating element and electrical components must not be exposed to direct contact with water or other cleaning sprays.
PAGE 5
PLATE LOADING AND SPRING ADJUSTMENT CAUTION: If you have a heated dispenser, unplug cabinet and allow to cool before adjusting spring tension. The tension on the self-leveling carriage is adjustable for differing types of dinnerware, by connecting or disconnecting the tension springs. As you are loading plates, observe the plate level. The top of the stack should be maintained at a comfortable height.
PAGE 6
REPLACEMENT PARTS HEATED DISPENSERS ONLY ALL DISPENSERS DESCRIPTION PART NUMBER DESCRIPTION PART NUMBER Dish guide, black 18617-0488 Fine tension spring 18400-2011 Fine tension spring 18400-2011 Coarse tension spring 18400-2012 Coarse tension spring 18400-2012 9” Top collar w/ switch holes 18406-0115 9” Top collar 18406-0052 10” Top collar w/ switch holes 18406-0116 10” Top collar 18406-0053 12” Top collar w/ switch holes 18406-0117 12” Top collar 18406-0054 Element, 120V, 300W 1
PAGE 7
WIRING DIAGRAM—3-Silo Heated Carts 120v, 1500 watts, 12.5A, 1 Ph, 5-20P plug WIRING DIAGRAM—3-Silo Heated Carts 120v, 2000 watts, 16.
PAGE 8
MAINTENANCE CAUTION: CASTERS Do not move cabinet unless door is securely closed. Serious damage to hinges and door may result if bumped into tables, walls, or other equipment when the doors are open. CAUTION: Use only OEM original equipment manufacturer replacement parts. Using unauthorized parts may cause serious injury. Replacement parts should be installed by a qualified service technician.
