152
Using the Camera to Record and Analyze a Golf Swing
5. Use [8] and [2] to select the movie quality setting you want and then
press [SET].
6. Perform the operation required for the type of image you want to shoot.
• To self-shoot from behind with the Handsfree Mode (page 152).
• To self-shoot from behind with the self-timer (page 153).
• To shoot from behind with normal movie recording (page 154).
. To self-shoot from behind with the Handsfree Mode
1. Tilt the camera’s monitor screen
upwards 180 degrees.
This will cause the (REC standby icon) to
appear on the monitor screen, which
indicates the Handsfree Mode.
• If the camera does not enter the
Handsfree Mode at this time, change its
“Handsfree” setting to “Always” or “180º
only”.
• Note that the camera also will not enter
the Handsfree Mode if the self-timer is
operating. Make sure the self-timer setting is “Off” when you want to use the
Handsfree Mode.
• You can specify the amount of time that should elapse before recording starts
after the camera detects movement. See page 65 for information about how to
change the setting.
2. Get the golfer’s body aligned with the guide
that appears on the camera monitor screen.
• You can ask someone to assist you to make the
above adjustments. If you are alone, set up the
camera the best you can according to the above
general guidelines.
3. Press [0] (Movie).
This will cause the (REC standby) icon to change to the (start self-timer)
icon, and put the camera into movie standby.
Movie
Quality
REC Screen
Icon Display
Frame Rate Image Size (Pixels)
HS120 120fps 640
x
480
HS240 240fps 512
x
384
