153
Using the Camera to Record and Analyze a Golf Swing
4. Move a golf club or something else near the (start self-timer) icon.
When the camera detects subject movement near the icon, it will automatically
start a countdown from the Handsfree timer start time. The camera will start
shooting the movie when the countdown reaches zero. After five seconds,
recording will stop automatically and the (preview) icon will appear on the
monitor screen.
• Camera response to movement may become poor when the background is
close to the same color as the subject (your golf club), or when the subject is
too far away from the camera.
• The camera will focus the image automatically before shooting starts, but the
focus setting will remain fixed while recording is in progress.
• To stop movie recording part way through, press [0] (Movie) again.
5. To view the movie you just shot, move your hand in the vicinity of the
(preview) icon.
• When the camera detects your movement, it will play back the movie in real
time. Use this feature when you want to check your swing immediately after
recording it.
. To self-shoot from behind with the self-timer
1. Press [SET].
2. Use [8] and [2] to select the (Self-timer) Control Panel option, and
then press [SET].
3. Use [8] and [2] to select „ (10 seconds) or ‚ (2 seconds) and then
press [SET].
4. Get the golfer’s body aligned with the guide
that appears on the camera monitor screen.
• You can ask someone to assist you to make the
above adjustments. If you are alone, set up the
camera the best you can according to the above
general guidelines.
• You can tilt the monitor screen 180 degrees so it
faces in the same direction as the lens for easier composition of self-portraits.
5. Press [0] (Movie).
This will start a countdown of the duration you selected in step 3, above. The
camera will start shooting the movie when the countdown reaches zero.
Recording will stop automatically after five seconds.
• The front lamp flashes while the Self-timer countdown is in progress.
• You can interrupt an ongoing self-timer countdown by pressing [SET].
• The camera will focus the image automatically before shooting starts, but the
focus setting will remain fixed while recording is in progress.
• To stop movie recording part way through, press [0] (Movie) again.
