234
Appendix
Exposure Control Program AE, Aperture Priority AE, Shutter Speed Priority AE,
Manual Exposure
Exposure
Compensation
–2.0 EV to +2.0 EV (in 1/3EV steps)
Shutter CMOS electronic shutter, mechanical shutter
Shutter Speed Snapshot (Program Auto): 1/4 to 1/2000 second
Snapshot (Premium Auto PRO): 4 to 1/4000 second
Snapshot (Aperture Priority AE): 1 to 1/2000 second
Snapshot (Shutter Speed Priority AE): 15 to 1/2000 second
Snapshot (Manual Exposure): 15 to 1/2000 second
• 1/25000-second shutter speed is possible only with High
speed Continuous Shutter, shutter speed priority AE or
manual exposure.
• May differ due to the camera setup.
Aperture Value F3.0 (W) to F7.9 (W) (With ND filter)
• Using optical zoom changes the aperture value.
White Balance Auto, Daylight, Overcast, Shade, Day White Fluorescent,
Daylight Fluorescent, Tungsten, Manual WB
Sensitivity
(Standard Output
Sensitivity)
Snapshots:
Auto, ISO 80, ISO 100, ISO 200, ISO 400, ISO 800,
ISO 1600, ISO 3200 equivalent
Snapshots (High Speed Night Shot):
ISO 25600 equivalent maximum
Movies: Auto
Flash Modes Auto, Off, On, Red-eye reduction
Flash Range
(ISO Sensitivity: Auto)
0.4 m to 4.7 m (1.3' to 15.4') (Wide Angle)
0.9 m to 2.4 m (3.0' to 7.9') (Telephoto)
• Range is affected by optical zoom.
Flash Intensity
Adjustment
–2, –1, 0, +1, +2
Flash Charging Time Approximately 5 seconds
Monitor Screen 3.0-inch TFT color LCD (Super Clear LCD)
921,600 dots, tiltable (180 degrees)
External connection
terminal
USB port (Hi-Speed USB standard, USB charging),
AV output terminal (NTSC/PAL)
HDMI output (Mini)
Microphones Stereo
Speaker Monaural
Power Requirements Rechargeable lithium ion battery (NP-130/NP-130A)
x
1
