235
Appendix
Approximate Battery Life
All of the values provided below represent the approximate amount of time under
normal temperature (23°C (73°F)) before the camera turns off. These values are not
guaranteed. Low temperatures shorten battery life.
• Temperature: 23°C (73°F)
• Battery: NP-130A (Rated Capacity: 1800 mAh)
• Recording Medium: 16GB SDHC memory card (SanDisk Corporation)
*1 In accordance with CIPA (Camera and Imaging Products Association) standards
*2 In accordance with CASIO standards
*3 Other settings
Time Lapse scene: Standard, Recording interval: 1/2 seconds, Total time: Off,
Sleep: 1 minute
*4 One-image scroll approximately every 10 seconds
• The above values are based a new battery, starting from a full charge. Repeated
charging shortens battery life.
• The above values are for reference only. They do not guarantee that the specified
battery life will be attained under actual operating conditions.
• Frequency of flash, zoom, Auto Focus, and High Speed CS usage, configured
settings, the amount of time the camera is left turned on, and ambient temperature
in the area where the camera is used all greatly affect recording time and number
of shots values.
Number of Shots (Operating Time)*
1
470 shots
Number of Shots (ECO)*
1
590 shots
Actual movie recording time (FHD Movie)*
1
1 hour 30 minutes
Approximate continuous movie recording time (FHD Movie)*
2
2 hours 30 minutes
Approximate continuous movie recording time
(High speed movie (HS 240))*
2
2 hours 40 minutes
Approximate time lapse recording time*
2
(FHD Movie*
3
) 4 hours 30 minutes
Continuous Playback (Snapshots)*
4
5 hours 30 minutes
Power Consumption 3.7 V DC, Approximately 5.8 W
Dimensions 107.5 (W)
x
61.5 (H)
x
36.7 (D) mm
(4.2" (W)
x
2.4" (H)
x
1.4" (D))
(28 mm (1.1") thick excluding projections)
Weight Approximately 256 g (9.0 oz)
(including battery and memory card*)
Approximately 216 g (7.6 oz)
(excluding battery and memory card)
* 16GB SDHC memory card (SanDisk Corporation)
