Product Name
WLAN and Bluetooth combo dongle, USB interface
Standards
IEEE 802.11b/g/n, Bluetooth v2.1+EDR/ v3.0/ v3.0+HS/ v4.0
Data Transfer Rate
WLAN:
802.11b: 11, 5.5, 2, 1 Mbps
802.11g: 54, 48, 36, 24, 18, 12, 9, 6 Mbps
802.11n: MCS0 to 7 for HT20MHz, MCS0 to 7 for HT40MHz
Bluetooth:
Basic rate: 1Mbps
Enhanced data rate: 2, 3 Mbps
High Speed: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Modulation Method
WLAN: BPSK/ QPSK/ 16-QAM/ 64-QAM/ DBPSK/ DQPSK/ CCK
Bluetooth: 8DPSK, π/4 DQPSK, GFSKFSK
Frequency Range
2.4GHz ISM band
RF Output Power
(tolerance ±2dBm)
WLAN:
17dBm – 802.11b@11Mbps
15dBm – 802.11g@54Mbps
13dBm – 802.11n@MCS0_HT20
13dBm – 802.11n@MCS7_HT20
13dBm – 802.11n@MCS0_HT40
13dBm – 802.11n@MCS7_HT40
Bluetooth: class 2
Receiver Sensitivity
WLAN:
-82dBm – 802.11b@11Mbps
-71dBm – 802.11g@54MBps
-67dBm – 802.11n@MCS7_HT20
-64dBm - 802.11n@MCS7_HT40
Bluetooth:
-89dBm@1Mbps
-90dBm@2Mbps
Antenna
Chip Antenna
Operating Temperature
-10 ~ 50° C ambient temperature
0 to 95 % (non-condensing)
Storage Temperature
-10 ~ 60°C ambient temperature
0 to 95 % (non-condensing)
Dimension
49.6 x 18 x 7.7 mm (LxWxH)
