Area A LCD：
LCD with blue back light supports Chinese/English operation interface optional,
and device status/program information real-time display.
Area B The Main Buttons：
Green back light Red status instruction
【012„„9】： Number and character input.
【ALM】： Switching the alarms
【MON】： Switching the monitors
【CAM】： Switching the cameras
【ESC】： Cancel
【ENTER】： Confirm
【MULTI】： Switching videos in DVR control mode
【LOCK】： Lock the current camera in Matrix control mode
【MAC】： Start or stop macroinstruction
【PROG】： Press this button to enter into keyboard setting when the
keyboard is in Login interface; Press this button to enter into PTZ
setting when the keyboard is under PTZ control mode.
【AUX1~4】： auxiliary switch
【ARM】： Press【ARM】to enable the alarm; Press【SHIFT】+【ARM】to
disable the alarm.
【ACK】： Alarm responder
【MUTE】： Keyboard mute button
【HOLD】： Save
【SHIFT】： Combination Key；
【PRESET】： Presets setting button. Press【PRESET】+ Number to set preset
positions.
【CALL】： Press 【CALL】+ No. of presets to call upon that preset position
【SITE】： Press this button to set the main address when the keyboard is
under DVR control mode.
【PREV】： Press【PREV】to switch camera, monitor or alarm;
Press【PREV】to select the item upward in the menu setting
【NEXT】： Press【NEXT】to switch camera, monitor or alarm;
Press【NEXT】to select the item downward in the menu setting
