HCC662 Ceramic Hob Manual for Installation, Use and Maintenance Passionate about style Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.
Important The CDA Group Ltd cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please note that CDA reserve the right to invalidate the guarantee supplied with this product following incorrect installation or misuse of the appliance or use in a commercial environment.
Please note: • Ceramic hobs become hot and remain hot during and immediately after use. Do not touch the hob until it has been allowed to cool. • Keep children away from the appliance when in use. • Never put cooking foil or plastic materials on the ceramic surface when the hob is hot. These materials could melt and cause damage to the hob. • Never use the hob top for storage. • Pan handles should never stand out beyond the edge of the worktop. This will ensure children cannot reach them.
Using your hob 2 3 7 8 9 1 4 10 5 6 Fig.1 Zones: 1. Front left 0.7/2.1 kW 130/220 mm dual 2. Back left 1.2 kW 160 mm 3. Back right 1.8 kW 190 mm 4. Front right 1.2 kW 160 mm 5. 6. 7. 8. 9. 10.
Using your hob To switch the zone on • Touch the power key. • Select the zone required by touching the zone selection key until the required zone flashes a 0 in the zone display. The order for zone selection is clockwise starting at the front right zone. The zone display will flash for approximately ten seconds when the zone will be set at the power level selected or switch off if no power level is set. Please note: • To activate a zone, touch the zone selection key until the required zone display flashes.
Efficient Use of your Hob Before using your hob for the first time, switch the zones on for a FEW SECONDS to burn off any grease left over from the manufacturing process The ceramic glass retains heat, so to make best use of the residual heat, switch off the zone five minutes prior to the end of cooking. To reduce the cooking time, the zone can be set to the maximum setting at the beginning of cooking, and then reduced during cooking time.
Care and Maintenance Always disconnect the appliance from the power supply before undertaking any cleaning or maintenance. You should use a non-abrasive cleaner to clean the hob top. Any abrasive cleaner (including Cif) will scratch the surface and could erase the control panel markings. Types of residues Clean with Cleaning advice Light Cleaning sponge and soft cloth Wipe over the zone to be cleaned with a sponge and hot water, and then wipe off with a soft dry cloth.
Mains Electricity Connection Warning! This appliance must be earthed We recommend that the appliance is connected by a qualified electrician, who is a member of the N.I.C.E.I.C. and who will comply with the I.E.E. and local regulations. This appliance is intended to be connected to fixed wiring and is not suitable for connection to a 13a plug or 13a supply. This appliance is intended to be connected to fixed wiring by a double pole switch, having a contact separation of at least 3mm in all poles.
Fitting the Hob Unpacking the hob: Take care not to lose or mishandle any parts. • Fitting position of the hob: This appliance must be installed a minimum of 50mm from any back wall and a minimum of 190mm away from any adjacent vertical surfaces, e.g. a tall cupboard end panel. This may be reduced to 100mm if the adjacent surface is resistant to fire (tiles or steel, for example). These dimensions are shown in Fig.4.
How to Install the Hob How to install the hob: Overall dimensions of the hob: Worktop cut-out dimensions: Width: 580mm Depth: 510mm Width: 560mm Depth: 490mm 60cm 65mm 400mm 480cm 470mm 650mm (600mm minimum) 1. Make the required hole in the worktop. Before doing this, you must check the instructions supplied with any cooker hood to ensure that you will have the required clearance. The cut-out (Fig.4) shows a 60mm gap from the wall to the cut-out edge.
To contact our Customer Care Department, or for Service, please contact us on the details below. Passionate about style Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.
