User Manual

ManualsBrandsCDN ManualsRelayPT1A - 4-Ev ENt Timer & Clock EN

Features

• 4 channels

• Programmable

• Dual function

• Memory

• Counts up & down in 4 channels separately

or simultaneously

• Clock

• Stopwatch

• Loud and long alarm

• Individual channel sounds

• Stop and restart

• Counts up after zero

• ABS plastic

• Sliding mode switch

• International time

• 4-way mounting: pocket clip/magnet/stand/loop

• Battery and instructions included

Note: Remove sticker from display before use.

Note: In the following instructions, names of the control

buttons are shown in CAPS. Function information that appears

on the display is shown in BOLD CAPS.

Battery Installation

Replace battery when LCD becomes dim or alarm

level declines.

1. Remove battery door by turning it

counterclockwise.

2. Install LR44 battery with positive (+) side up.

3. Replace battery door and lock it by turning

it clockwise.

Operating Instructions

A. Set Clock

1. Select CLOCK mode with sliding mode switch.

12:0000AM will appear after inserting battery.

2. Press and hold ENTER approximately

2 seconds until the display ashes.

3. Press CLEAR to toggle between 12-hour,

AM/PM time, and 24-hour, international time.

4. Press HR, MIN and SEC to enter the desired

time. Press and hold button for fast advance.

5. Press ENTER to exit. The PT1A will

automatically exit 3 seconds after the last entry.

B. Count Down

1. Select COUNT DOWN mode with sliding mode

switch. COUNT DOWN will appear on the

display.

2. Press HR, MIN and/or SEC to enter the desired

time. Press and hold button for fast advance.

3. Press START/STOP to start the count down.

Press START/STOP button to interrupt the

count. Press START/STOP button again to

resume the count.

4. When the desired time is reached, alarm will

sound and the timer will start to count up the

“overtime”. OT (OverTime) and COUNT UP

will appear on the display while TIME’S UP

ashes.

5. Press START/STOP to stop the alarm. The

alarm will stop automatically after 60 seconds

while the count up continues.

Model: PT1A

4-Event Timer & Clock

Counts 100 hours by minutes & seconds

Summary of content (3 pages)

PAGE 1
Model: PT1A 4-Event Timer & Clock Counts 100 hours by minutes & seconds Features Battery Installation • • • • • Replace battery when LCD becomes dim or alarm level declines. 1. Remove battery door by turning it counterclockwise. 2. Install LR44 battery with positive (+) side up. 3. Replace battery door and lock it by turning it clockwise.
PAGE 2
6. Press CLEAR to reset to 0:0000. Note: The timer will retain any time showing on the display when the sliding mode switch is moved to another position. C. Count Up 1. Select COUNT UP mode with sliding mode switch. COUNT UP will appear on the display. 2. Press START/STOP to start the count up. If desired, the PT1A can count up from any desired time by entering that time with the HR, MIN and SEC buttons. 3. Press START/STOP button to interrupt the count. Press START/STOP button again to resume the count.
PAGE 3
The information in this document has been reviewed and is believed to be accurate. However, neither the manufacturer nor its affiliates assume any responsibility for inaccuracies, errors or omissions that may be contained herein. In no event will the manufacturer or its affiliates be liable for direct, indirect, special, incidental or consequential damages arisen by using this product or resulting from any defect/omission in this document, even if advised of the possibility of such damages.
