ME10E-N ME15E-N CME10E-N CME15E-N 18 Gauge Type 304L Stainless Steel construction to resist corrosion.
VENT OPENING POWER SUPPLY BOX POWER ON LIGHT ME10E-N CAUTION HOT SURFACES HEATER ON LIGHT POWER SWITCH TEMPERATURE CONTROL "A" TEMPERATURE CONTROL 4.0 SIDE ACCESS DOOR (SLIDES UP) OVERFLOW THERMOMETER 14.0 WATER INLET 4.0 3.4 16.0 NOTE: 1. FIELD WIRING MUST BE SUITABLE FOR 75 DEGREES CELSIUS. 2. USE COPPER WIRE ONLY FOR POWER SUPPLY CONNECTION. 3. 120 VOLT UNITS SUPPLIED WITH A GROUNDED 120V-15A LINE CORD AND PLUG.
AUTOMATIC HOT WATER BOILER WARRANTY Every Cecilware product has been carefully inspected before shipment. The finest materials and the highest standards of workmanship have been built in to the equipment. Within 1 year of purchase, should any Cecilware product show defect in factory workmanship or material, we agree to repair at our option or replace without cost to user, such parts which prove upon factory inspection to have been so defective.
ELECTRICAL HOOK-UP PROCEDURES: FOR QUALIFIED SERVICE PERSONNEL ONLY NOTE: Always check the rating plate of the unit for proper voltage and current requirements. 1. 120V water boilers are provided with 120V/15A grounding plug. Units must have a separate 120V/15A outlet. 2. 208/240V water boilers are provided with a terminal block inside the control box. Field wiring must be performed by a qualified serviceman. 1 and 3 phase hook-up for units with terminal blocks.
COUPLING COMPONENT TESTS A) Thermostat Adjustments: The Thermostat is factory set for proper dispense temperature of 190° F with the control shaft set to the maximum clockwise position. If field adjustments are needed proceed as follows: To DECREASE temperature, turn the control shaft slightly in the COUNTERCLOCKWISE direction. NUT - CCW - DECREASES TEMPERATURE For qualified technicians ONLY: Remove the knob and locate the Slotted Adjustment Screw inside the hollow thermostat shaft.
20 19 18 2 5 19 4 3 2 1 ME10E-N ME15E-N 28 27 26 25 24 23 22 21 13 12 11 10 9 8 6 7 ITEM DESCRIPTION 17 16 15 14 ME10E-N 19 2 ME15E-N QTY
ELECTRICAL DIAGRAM ME10E-N, ME15E-N 120 VOLTS N L1 WATER LEVEL CONTROL WATER INLET VALVE GND RED WHT WATER LEVEL PROBES BLU YEL GRN 1 FILL 2 AC-1L 3 AC-2N 4 L-LEVEL 5 H-LEVEL 6 COMMON LED WATER GND HEATER LIGHT HI-LIMIT SWITCH THERMOSTAT ON-OFF HEATER G199A (1.
ELECTRICAL DIAGRAM ME10E-N, ME15E-N 120/ 240 VOLTS N L1 WATER LEVEL CONTROL WATER INLET VALVE GND RED WHT WATER LEVEL PROBES BLU YEL GRN 1 FILL 2 AC-1L 3 AC-2N 4 L-LEVEL 5 H-LEVEL 6 COMMON LED WATER GND HEATER LIGHT HI-LIMIT SWITCH CONTACTOR THERMOSTAT ON-OFF (SEE HEATERS HOOK-UP SHEET 4) POWER LIGHT POWER SWITCH N L2 L1 SHEET 2 of 4 CECILWARE CORPORATION
ELECTRICAL DIAGRAM ME10E-N, ME15E-N 240 VOLTS L2 L1 WATER LEVEL CONTROL WATER INLET VALVE GND RED WHT BLU YEL GRN WATER LEVEL PROBES 1 FILL 2 AC-1L 3 AC-2N 4 L-LEVEL 5 H-LEVEL 6 COMMON LED WATER GND HEATER LIGHT THERMOSTAT ON-OFF HI-LIMIT SWITCH CONTACTOR (SEE HEATERS HOOK-UP SHEET 4) POWER LIGHT L3 L2 POWER SWITCH L1 SHEET 3 of 4 CECILWARE CORPORATION
ELECTRICAL DIAGRAM ME10E-N, ME15E-N 240 VOLTS HEATERS HOOK-UP N L1 L2 CONTACTOR TERMINAL BLOCK 1 PHASE 240 VOLTS G197A (2 x 3.5 KW) TOTAL: 7 KW N L1 L2 L3 CONTACTOR 3 PHASE 240 VOLTS G197A (3 x 3.5 KW ) TOTAL: 10.
