PHASE HZ WATTS NO. OF RECEPTACLE AMPS KW HEATERS NEMA NO. POWER CORD CIRCUIT BREAKER AMPS 5-15R 5-15P [2 WIRES+GND] 15A 12.5 6-20R 6-20P [2 WIRES+GND] 20A 25 6-30R 6-30P [2WIRES+GND] 30A MODEL NO. VOLTS FTC-3-N, FTC-3.5-N FTC-5-N, 120 1 60 1.75 1 15 FTC-5-N, FTC-10-N 240 1 60 2.80 1 FTC-10-N 240 1 60 5.60 2 ELECTRICAL SPECFICATIONS * Export 220 Volts, 2.
Note: In areas with extremely hard water, a Water Softener must be installed to prevent a malfunctioning of the equipment due to high lime and mineral buildup. Not doing so it will void the warranty. COMPLIANCES! This equipment to be installed to comply with the Basic Plumbing Code of the Building Officials and Code Administrators International, Inc. (BOCA) and of the Food and Drug Administration (FDA.) INITIAL SET-UP, 1 .Make sure unit is disconnected from power source. 2..
Tea Brewing Instructions CAUTION: Operate with care. Tea Brewer dispenses HOT WATER and HOT TEA that can cause serious burns. 1. Start each brew cycle with a clean brew funnel and a clean empty tea dispenser. 2. Place a tea bag into the funnel and slide the funnel into the funnel rails until it stops. 3. When the Green Brew Switch Light comes on, press and release the Brew Button. NOTE: This tea brewer will not brew until the pre-set brew temperature (197-203° F) is reached. 4.
SANITIZING: All food dispensing units should be sanitized periodically. All parts to be sanitized must be cleaned first. To prepare a sanitizing solution: ADD 2 TSP. OF LIQUID CLOROX BLEACH (5.25% CONCENTRATION) TO 1 GALLON OF WATER AT ROOM TEMPERATURE (70° - 90°F). Soak all parts for a minimum of 3 min. in the sanitizing solution. Note: Always start with an unopened bottle of Clorox Bleach since the solution from an opened bottle has a short life span. Let all sanitized parts drain and dry naturally.
TROUBLESHOOTING GUIDE WARNING: To reduce the risk of electrical shock unplug the dispenser power cord before repairing or replacing any internal components of the unit.. Before any attempt to replace a component be sure to check all electrical connections for proper contact PROBLEM PROBABLE CAUSE REMEDY 1 Brewed Cold Tea. a) Heater Switch OFF. b) Run out of hot water c) Thermostat is OFF. d) Loose electrical connection. e) Thermostat is defective. f) Hi-Limit Temperature Switch is tripped.
