1.4 - SPECIFICATION ►
Single phase power supply 230 V 50-60 Hz
Protection class IP 54
Max. power consumption 1,1 Kw
Monitor TOUCH 15"
Balancing speed approx. < 180 min
-1
Cycle time for average wheel (16 Kg - 175/65X15") 3,8 seconds
Balancing accuracy < 1 gram
Position resolution ± 1.4 °
Average noise level < 70 dB(A)
Distance rim - machine 0 - 280 mm (400 mm can be preset)
Rim width setting range 1.5" ÷ 20" or 40 ÷ 510 mm
Diameter setting range 10" ÷ 30" or 265 ÷ 765 mm
Total wheel diameter within guard 1067mm (42")
Total wheel width within guard 500 mm (42")
Min/max. compressed air pressure 8 ÷ 10 Kg/cm
2
approx. 0.8 to 1 Mpa;
approx. 8 to 10 BAR;
approx. 115 to 145 PSI.
Air consumption per cycle 15 l. (at 8 Kg./cm
2
)
1.4 - OVERALL DIMENSIONS ►
