Amhaze™ II User Manual Rev. 1 -13-
Technical Specifications
Dimensions and
Weight
Length Width Height Weight
21.5 in (546 mm)
24.7 in (627 mm)
8 in (203 mm)
41.2 lb (18.7 kg)
Note: Dimensions in inches rounded to the nearest decimal digit.
Power
Power Supply Type
Range
Voltage Selection
Model-specific
120 VAC, 60 Hz
or 230 VAC, 50 Hz
Fixed
Parameter 120 V, 60 Hz 230 V, 50 Hz
Consumption
760 W
250 W
Operating current
6.3 A
5 A
Breaker
8 A
8 A
Power U.S./Worldwide Europe
Power input connector
Neutrik® powerCON® A
Neutrik® powerCON® A
Power cord plug
Edison (U.S.)
Local plug
Operation/Capacity/
Consumption
Heat-up Time Tank Capacity Fluid Consumption
2 min
0.92 gal (3.5 l)
18 ml/min
Misc.
Output
3,500 cfm
Thermal
Max. External Temperature Cooling System
104 °F (40 °C)
Fan-Assisted Convection
DMX
I/O Connectors Connector Type Channel Range
3- and 5-pin XLR
Sockets
2
Ordering
Product Name
Item Code
UPC Number
Amhaze™ II (120 V)
05070742
781462210908
Amhaze™ II (230 V)
05070743
781462210915
