6. TECHNICAL SPECIFICATIONS
Dimensions and
Weight
Length Width Height Weight
15 in (381 mm)
25.9 in (660 mm)
15 in (381 mm)
32.4 lb (14.7 kg)
Note: Dimensions in inches rounded to the nearest decimal digit.
Power
Power Supply Type Range Voltage Selection
Model-specific
120 VAC, 60 Hz
Fixed
Parameter 120 VAC, 60 Hz
Consumption
1,480 W
Current
12.39 A
Breaker
15 A
Power I/O
U.S./Canada
Worldwide
Power input connector
Neutrik® powerCON® A
Neutrik® powerCON® A
Power cord plug
Edison (U.S.)
Local plug
Operation/Capacity/
Consumption
Heat-up Time Tank Capacity Fluid Consumption
8 min
2.5 gal (9.5 l)
140 ml/min
Misc.
Output
40,000 cfm
Thermal
Max. External Temperature
Cooling System
104 °F (40 °C)
Fan-Assisted Convection
DMX
I/O Connectors Connector Type Channel Range
3- and 5-pin XLR
Sockets
1
Ordering
Product Name Item Code UPC Number
Atmos™
05070859
781462212070
