User Manual
TABLE OF CONTENTS 1. Before You Begin .......................................................................................................... 3 What Is Included ............................................................................................................................... 3 Unpacking Instructions ..................................................................................................................... 3 Claims ....................................................................
1. BEFORE YOU BEGIN What Is Included • • • • Nimbus™ Jr. Power Cord Warranty Card Quick Reference Guide Unpacking Instructions Carefully unpack the product immediately and check the container to make sure all the parts are in the package and are in good condition. Claims If the box or the contents (the product and included accessories) appear damaged from shipping, or show signs of mishandling, notify the carrier immediately, not CHAUVET®.
Product at a Glance Use on Dimmer x Outdoor Use x x x x Sound-Active DMX Master/Slave Safety Notes Page 4 of 11 Auto Programs Fixed voltage (120 VAC or 230 VAC) Replaceable Fuse User-Serviceable x P x x These Safety Notes include important information about the installation, use, and maintenance; including DRY ICE WARNINGS. Read carefully! • Always connect the product to a grounded and protected circuit to avoid the risk of electrocution.
• Always make sure that the voltage of the outlet to which you are connecting the product is within the range stated on the decal or rear panel of the product. • The product is for indoor use only! (IP20) To prevent risk of fire or shock, do not expose the product to rain or moisture. • Always install the product in a location with adequate ventilation, at least 20 in (50 cm) from adjacent surfaces. • Be sure that no ventilation slots on the product’s housing are blocked.
2. INTRODUCTION Overview Carry Handles Lid Latch Top Plate LED Indicators Power In Output Nozzle Basket/Operation Lever Page 6 of 11 Nimbus™ Jr. User Manual Rev.
Dimensions 15.5 in 393 mm 13.3 in 337 mm 13.6 in 345 mm Nimbus™ Jr. User Manual Rev.
3. SETUP AC Power The Nimbus™ Jr. has a fixed voltage power supply and it can work with an input voltage of either 120 VAC, 60 Hz or 230 VAC, 50 Hz, depending on the specific model. To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart. The listed current rating indicates the product’s average current draw under normal conditions.
4. OPERATION Setup The top plate has two LED indicators – one red and one green. The red LED indicates that the heater is on, and the green LED indicates the water is at its optimal operating temperature. The heater will not turn on unless there is enough water. As the dry ice sublimates, the water will cool and the green LED indicator will turn off. This is normal and the Nimbus™ Jr will continue to operate until all the dry ice is used.
6. TECHNICAL SPECIFICATIONS Dimensions and Weight Length 15.5 in (393 mm) Width 13.6 in (345 mm) Height Weight 13.3 in (337 mm) Empty: 14.6 lb (6.6 kg) Full: 34 lb (15.5 kg) Note: Dimensions in inches rounded to the nearest decimal digit. Power Heat Element Thermal Ordering Page 10 of 11 Power Supply Type Range Voltage Selection Model specific 120 V, 60 Hz or 230 V, 50 Hz Voltage specific Parameter 120 V, 60 Hz 230 V, 50 Hz Consumption 1,500 W 1,400 W Operating current 12.2 A 6.
Returns To return a product or request support: • • • In the U.S., contact CHAUVET® World Headquarters (see below). In the UK or Ireland, contact CHAUVET® Europe Ltd. (see below). In any other country, DO NOT contact CHAUVET®. Contact your distributor. See www.chauvetlighting.com for distributors outside the U.S., United Kingdom, or Ireland. If you live outside the U.S.
