Q-Scan 250 & Q-Roll 250 User Manual 10 2005-11-15/13:24
Note!
If the fixture is connected to a
controller, please disconnect it.
The display will read the previously
selected setting.
Only one fixture can be the Master
assigned fixture. However, 16 units
can be slaved to the master unit.
Operating Modes
 A stand-alone mode will listen to sound and run through its diverse range of built in programs.
 Master/Slave mode will allow the command of up to as many units you want in a synchronized
light show to the sound.
 DMX control mode will provide the greatest flexibility and creativity. Each fixture trait can be
controlled individually using any universal DMX-512 controller.
Master & Stand Alone (P6)
In order to create the correct environment for Stand Alone
operation, several parameters have to be set in the control
panel. Please make the changes to the functions as listed in
the table below.
FUNCTION SET TO NOTES
P6 -y Master mode (one Master only)
P4 -y Sound activated
A 001 Channel address
P1 Any Pan invert
P2 Any Tilt invert
Setting Slave Fixtures
The Master/Slave mode will allow you to link multiple units in a daisy chain fashion. In this mode, the
first unit in the daisy chain, the master, will automatically command all other units following. The first
unit will operate in a Stand/Alone mode and all units following will synchronize to the first unit. Up to
16 fixtures can be daisy chained in Master/Slave mode.
MENU SET TO NOTES
P6 -n Master mode
P4 -n Sound activated
A 001 Channel address
P1 Any Pan invert
P2 Any Tilt invert
You can change the Pan and Tilt settings freely.
Sound-active (P4) or Auto-run (P5)
In Master/Slave mode you can choose whether the fixture will run in a sound-active state where the
movement is triggered by sound or in auto-run where the speed is pre-programmed.
MENU SET TO NOTES
P4 -n Sound Activated
or
P5 -n Auto-run
