Q-Scan 250 & Q-Roll 250 User Manual 14 2005-11-15/13:24
DMX Channel Values (16 Bit)
DEFAULT VALUE FUNCTION
1
000  255
Pan
Left > Right ( 128 = center)
000  255
Tilt (Q-Scan 250)
Up > Down (128 = center)
2
000  005
006  120
121  140
141  255
Barrel Spin (Q-Roll 250)
Stop
Rotation: Fast > Slow (clockwise)
Stop
Rotation: Slow > Fast (counter-clockwise)
3
000  005
006  063
064  095
096  127
128  159
160  191
192  223
224  255
Shutter/Strobe/Dimmer
Blackout
Dimmer: Closed > Open (0-100%)
Variable strobe: Slow > Fast
Open
(no function)
Pulse strobe in sequence: Slow > Fast | (Close > Open)
Pulse strobe in sequence: Fast > Slow | (Open > Close)
Open
4
000  013
014  027
028  041
042  055
056  069
070  083
084  097
098  111
112  126
127  136
137  146
147  156
157  166
167  176
177  186
187  196
197  206
207  217
218  219
220  255
Rotating Gobo Wheel
Open
Gobo 1
Gobo 2
Gobo 3
Gobo 4
Gobo 5
Gobo 6
Gobo 7
Gobo 8
Open
Gobo 1 (variable bounce): Slow > Fast
Gobo 2 (variable bounce): Slow > Fast
Gobo 3 (variable bounce): Slow > Fast
Gobo 4 (variable bounce): Slow > Fast
Gobo 5 (variable bounce): Slow > Fast
Gobo 6 (variable bounce): Slow > Fast
Gobo 7 (variable bounce): Slow > Fast
Gobo 8 (variable bounce): Slow > Fast
Open
Gobo spin: Slow > Fast
5
000  009
010  020
021  031
032  041
042  052
053  063
064  073
074  084
085  095
096  105
106  116
117  128
129  190
191  220
221  222
223  255
Color Wheel
White (Open)
Red
Blue
Yellow
Light Green
Magenta
UV
Light Blue or Cyan
Orange
Pink
Tri-color: Red – White - Blue
Quad-color: Blue – Pink – Purple - Yellow
Linear progression of color wheel (color-splits)
Rainbow effect: Fast > Slow (clockwise)
Stop
Rainbow effect: Slow > Fast (counter-clockwise)
6
000  127
128  189
190  193
194  255
Gobo Rotation
Gobo incremental rotation
Clockwise gobo rotation: Fast > Slow
No Rotation
Counter clockwise gobo rotation: Slow > Fast
7
000
 000
001  200
201
 204
205  255
Pan/Tilt Speed (P7-n setting)
Tracking control: Maximum
Vector control: Maximum > Slowest
Fixture Reset
Tracking control: Maximum
