8-Port 6Gb/s SAS/SATA Backplane 80H10323601A1 User’s Manual CHENBRO Storage Chassis 8-Port 6Gb/s SAS/SATA Backplane 80H10323601A1 Feb / 10 / 2013 15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C., Tel: +886 2 82265500 Fax: +886 2 82265392 Email: info@chenbro.com.tw 1 w w w . c h e n b r o .
8-Port 6Gb/s SAS/SATA Backplane 80H10323601A1 User’s Manual Copyright Copyright © 2012 Chenbro Micom Co., Ltd.. All rights reserved. Unless otherwise indicated, all materials in this manual are copyrighted by Chenbro Micom Co., Ltd.. All rights reserved. No part of this manual, either text or image may be used for any purpose other than internal use within purchasing company.
8-Port 6Gb/s SAS/SATA Backplane 80H10323601A1 User’s Manual Contents Technical Support Copyright Revision History Backplane Specification Backplane Hardware Backplane Assembly Backplane Wiring Appendix w w w . c h e n b r o . c o m 15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C., Tel: +886 2 82265500 Fax: +886 2 82265392 Email: info@chenbro.com.
8-Port 6Gb/s SAS/SATA Backplane 80H10323601A1 User’s Manual Revision History Date Feb / 10 / 2013 Modifications First release (V1.0) w w w . c h e n b r o . c o m 15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C., Tel: +886 2 82265500 Fax: +886 2 82265392 Email: info@chenbro.com.
8-Port 6Gb/s SAS/SATA Backplane 80H10323601A1 User’s Manual 6Gb/s Backplane Specification P/N : 80H10323601A1 (Version A0) Specification Host Interface SATA HDD Interface SAS Hot-Swap Yes, allows user to replace hard disk drive during power on stage Display LED indicates Hard Disk Drive status Power LED – Blue (When HDD is present) Access LED – Green (When HDD is busy) Error LED – Red (When HDD is error) Cooling Four PWM FAN CONNECTOR Environment Monitor Temperature sensor detect(RT1, RT2) Co
8-Port 6Gb/s SAS/SATA Backplane 80H10323601A1 User’s Manual Backplane Layout Backplane Connectors Front View CH51 CH61 CH71 CH81 CH11 CH21 CH31 CH41 Rear View CN04 CH82 CH72 CN03 CH62 CH52 CN06 CN05 JF2 JF4 CN02 CH42 CH32 JF1 CN01 JF3 CN07 CH22 CH12 SW1 (1) [CH11 ~ CH41 / CH51 ~ CH81] : 22-pin SATA-II or 29-pin SAS ( for HDD) (2) [JF1 / JF2 / JF3 / JF4] : PWM Fan connectors 1~4 (3) [CN01 ~ CN04] : 4-pin Power connectors (4) [CN07] : M/B fan signal connector ( Clock and PWM ) (gets either
8-Port 6Gb/s SAS/SATA Backplane 80H10323601A1 User’s Manual POWER Connector (CN01 ~ CN04) Pin NO. Descriptions 1 12V 2 GND 3 GND 4 5V Fan Connector (JF1 ~ JF4) Pin NO. Descriptions 1 GND 2 12V 3 FAN Clock Input 4 FAN PWM Output MB PWM Connector (CN07) Pin NO. Descriptions 1 FAN Clock Output to MB 2 FAN PWM Input from MB 15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C., Tel: +886 2 82265500 Fax: +886 2 82265392 Email: info@chenbro.com.tw 7 w w w .
-Port 6Gb/s SAS/SATA Backplane 80H10323601A1 User’s Manual SGPIO SIGNAL CONNECTOR (CN05 & CN06) Pin Descriptions NO. Pin NO.
8-Port 6Gb/s SAS/SATA Backplane 80H10323601A1 User’s Manual SW1 FUNCTION SW1-1: FAN1 Monitor Enable/Disable Setting Sw1-1 FAN1 ON Enable OFF Disable (Default) SW1-2: FAN2 Monitor Enable/Disable Setting Sw1-2 FAN2 ON Enable (Default) OFF Disable SW1-3: FAN3 Monitor Enable/Disable Setting Sw1-3 FAN3 ON Enable (Default) OFF Disable SW1-4: FAN4 Monitor Enable/Disable Setting FAN4 ON Enable (Default) OFF Disable SW1-5: MB PWM Monitor Enable/Disable Setting Sw1-5 MB PWM ON Enable OFF
8-Port 6Gb/s SAS/SATA Backplane 80H10323601A1 User’s Manual HDD IN Connector (CH11, CH21, CH31, CH41, CH51, CH61, CH71, CH81) Pin Pin NO. Descriptions S1 GND P1 NC S2 RP P2 NC S3 RN P3 NC S4 GND P4 GND S5 TN P5 POWER ENABLE S6 TP P6 GND S7 GND P7 5V PRE-CHARGE S8 NC P8 5V S9 NC P9 5V S10 NC P10 GND S11 NC P11 ACCESS SIGNAL S12 NC P12 GND S13 NC P13 12V PRE-CHARGE S14 NC P14 12V P15 12V NO. Descriptions w w w . c h e n b r o . c o m 15Fl., No.
8-Port 6Gb/s SAS/SATA Backplane 80H10323601A1 User’s Manual Backplane Assembly The Chenbro 8-Port 6Gb/s SAS/SATA Backplane can be assembled on Chenbro Storage Server Chassis RM23608 only. Please refer to the Chassis Quick Installation Guide for detail information. Figure : Front and Rear View of 8-port Backplane Backplane Wiring Fan cable w w w . c h e n b r o .
8-Port 6Gb/s SAS/SATA Backplane 80H10323601A1 User’s Manual Appendix 1 PWM fan duty cycle definition table Temperature (℃) Loading percentage (%) <= 31℃ 34% 32℃ 38% 33℃ 42% 34℃ 46% 35℃ 50% 36℃ 54% 37℃ 58% 38℃ 62% 39℃ 66% 40℃ 70% 41℃ 73% 42℃ 76% 43℃ 79% 44℃ 82% 45℃ 85% 46℃ 88% 47℃ 91% 48℃ 94% 49℃ 97% >= 50℃ 100% w w w . c h e n b r o . c o m 15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C.
