INSTALLATION INSTRUCTIONS

FUSION™ CAT 5 Surge Adapter Bracket

Spanish Product Description

German Product Description

Portuguese Product Description

Italian Product Description

Dutch Product Description

French Product Description

FCA100

Summary of content (4 pages)

PAGE 1
INSTALLATION INSTRUCTIONS FUSION™ CAT 5 Surge Adapter Bracket Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description FCA100
PAGE 2
FCA100 Installation Instructions DISCLAIMER Milestone AV Technologies and its affiliated corporations and subsidiaries (collectively "Milestone"), intend to make this manual accurate and complete. However, Milestone makes no claim that the information contained herein covers all details, conditions or variations, nor does it provide for every possible contingency in connection with the installation or use of this product.
PAGE 3
Installation Instructions FCA100 INSTALLATION 5. NOTE: The FCA100 may be used to support a surge adapter or other components that don’t exceed the weight capacity of the FCA100. 1. Put Velcro tabs (C) together so there are 4 squares of Velcro. 2. Remove paper from one side of each of the four Velcro squares. 3. Attach Velcro squares to the left and right brackets (A and B). (See Figure 1) Place the left and right brackets with the surge adapter onto the wall mount.
PAGE 4
FCA100 Installation Instructions USA/International Europe Chief Manufacturing, a products division of Milestone AV Technologies 8805-000260 Rev00 2009 Milestone AV Technologies, a Duchossois Group Company www.chiefmfg.com 02/09 Asia Pacific A P F A P F A 8401 Eagle Creek Parkway, Savage, MN 55378 800.582.6480 / 952.894.6280 877.894.6918 / 952.894.
