User guide

Concise User’s Guide
3.5G Module - 29
English
7. Slide the SIMLOCK in the direction of the arrow
(Figure 16) in order to release the lock and lift it up.
Figure 16 - Unlock the SIMLOCK
8. Insert the USIM card and close the SIMLOCK by pushing
it in the direction of the arrow in Figure 17.
Figure 17 - Insert the USIM Card & Lock the SIM-
LOCK
9. Replace the hard disk assembly, cover, screws and
battery etc.
3G Watcher Application
With the 3.5G module and USIM card (provided by
your service provider) installed you may then install the
3G Watcher application. The 3G Watcher application
allows you to directly access your 3.5G internet service
from the computer.
3G Watcher Application Installation
1. Make sure you enable power to the module by pressing
the
Fn + key combination (the icon will be green).
2. If the Found New Hardware wizard appears, click
Cancel .
3. Click Option Drivers (button).
4. Click 3.Install 3G Driver > Yes.
5. Click Next.
6. Click the button to accept the license agreement, and
then click Install.
7. When the next screen appears wait about 2 minutes
before clicking Finish (to allow the hardware to detect
the 3.5G module).
8. The 3G Watcher icon will appear on the desktop.
9. You can access the 3G Watcher application from the
Start menu (Start > Programs/All Programs > Sierra
Wireless > 3G Watcher), or by clicking the desktop
icon .
7
