Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Preface FCC RF Radiation Exposure Statement: 1. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. Warning Use only shielded cables to connect I/O devices to this equipment.
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: 1. 2. 3. 4. 5. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool. Avoid using this equipment with a telephone line (other than a cordless type) during an electrical storm.
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: 1. Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer to any shock or vibration. 2. Do not place it on an unstable surface. Do not place anything heavy on the computer. Keep it dry, and don’t overheat it.
Preface 3. Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. 4. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work. Remember to periodically save your data as data may be lost if the battery is depleted. Do not turn off the power until you properly shut down all programs. 5.
Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a steady, uninterrupted power supply. If you are unsure of your local power specifications, consult your service representative or local power company. • The power adapter may have either a 2-prong or a 3-prong grounded plug.
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the power supply.
Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: 1. 2. 3. 4. 5. 6. 7. 8. Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched. Disconnect the AC/DC adapter and cables. Stow them in the carrying bag. The AC/DC adapter uses voltages from 100 to 240 volts so you won’t need a second voltage adapter.
Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common. Don’t check it with “normal” luggage. Baggage handlers may not be sufficiently careful. Avoid knocking the computer against hard objects.
Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints. The following are some tips to reduce the strain: •Adjust the height of the chair and/or desk so that the keyboard is at or slightly below the level of your elbow. Keep your forearms, wrists, and hands in a relaxed position.
Preface Lighting Proper lighting and a comfortable viewing angle can reduce eye strain and shoulder and neck muscle fatigue. • • • • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. Position the display directly in front of you at a comfortable viewing distance. Adjust the display-viewing angle to find the best position.
Preface XIV
Preface Contents Notice .................................................................................I FCC Statement .............................................................II FCC RF Radiation Exposure Statement: ................... III Instructions for Care and Operation ........................... V Power Safety .............................................................VII Battery Precautions ................................................. VIII Cleaning .....................................
Preface USB Printer ...............................................................2-10 Install Instructions: ...................................................2-10 Parallel Printer ...........................................................2-10 Power Management Overview ........................................................................3-1 The Power Sources ........................................................3-2 AC/DC Adapter ...........................................................
Preface Intel Turbo Memory Technology Driver ....................4-8 BIOS Utilities Overview ........................................................................5-1 The Power-On Self Test (POST) ...................................5-2 Failing the POST .........................................................5-3 Fatal Errors .................................................................5-3 Non-Fatal Errors .........................................................5-3 The Setup Utility .................
Preface 802.11b/g Driver Installation ......................................7-7 Connecting to a Wireless Network ..............................7-8 PC Camera Module ......................................................7-11 PC Camera Driver Installation .................................7-11 PC Camera Audio Setup ...........................................7-12 3.5G Module ................................................................7-18 3G Watcher Application ............................................
Preface Enabling TV Display ..................................................B-12 Windows XP Information Specifications DVD Regional Codes ...................................................D-2 Windows XP Start Menu & Control Panel ...................D-3 Audio Features ..............................................................D-4 Function/Hot Key Indicators ........................................D-5 Video Features ..............................................................
Preface Driver Installation ....................................................... D-22 Manual Driver Installation........................................... D-23 Updating/Reinstalling Individual Drivers ...................D-24 Driver Installation Procedure....................................... D-24 Found New Hardware Wizard ..................................... D-24 Chipset ........................................................................D-25 Audio .................................................
Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: • Chapter 2 • Chapter 3 • Chapter 4 • Chapter 5 • Chapter 6 • Chapter 7 • Chapter 8 • Appendix A • Appendix B • Appendix C • Appendix D A guide to using some of the main features of the computer e.g.
1 Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “Drivers & Utilities” on page 4 - 1, “BIOS Utilities” on page 5 - 1 and “Upgrading The Computer” on page 6 - 1 in the User’s Manual. You may also find the notes marked with a of interest to you. Notes Check the light colored boxes with the mark above to find detailed information about the computer’s features.
Quick Start Guide Model Differences This notebook series includes two different design types, however only one design is pictured in this manual. Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the appropriate drivers. Drivers are programs which act as an interface between the computer and a hardware component e.g. a wireless network module.
1 Quick Start Guide System Software Your computer may already come with system software pre-installed.
Quick Start Guide System Startup 1. Remove all packing materials, and place the computer on a stable surface. 2. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. 3. Attach the AC/DC adapter to the DC-In jack at the rear of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter. 4.
1 Quick Start Guide Figure 1 - 2 LCD Panel Open System Map: LCD Panel Open 1 1. Optional Built-In PC Camera 2. LCD 3. Hot Key Buttons 4. Power Button 5. Speakers 6. Keyboard 7. Built-In Microphone 8. TouchPad and Buttons 9. Fingerprint Reader Module (optional) Wireless Device Operation Aboard Aircraft The use of any portable electronic transmission devices (e.g. WLAN or Bluetooth) aboard aircraft is usually prohibited.
Quick Start Guide LED Indicators The LED indicators on the computer display helpful information about the current status of the computer.
1 Quick Start Guide Hot Key Buttons These buttons give instant access to the default Internet browser and e-mail program, and to a user-defined application, with one quick button press. Hot Key Function Activate the Default E-Mail Browser Activate the Default Internet Program Toggle *Silent Mode (for power saving) Table 1 - 3 - Hot Key Buttons *When enabled, Silent Mode will reduce fan noise and save power consumption. Note this may reduce computer performance.
Quick Start Guide Keyboard The keyboard has a numerical keypad for easy numeric data input, and features function keys to allow you to change operational features instantly. See Table 1 - 4, on page 1 - 10 for full function key combination details. Function Keys NumLk & ScrLk Keys Play/Pause Key Numerical Keypad 3.5G Module Power Toggle Key Fn Key Other Keyboards If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard.
1 Quick Start Guide Function/Hot Key Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators (see the table below) are available when the hot key utility is installed (see “Hot Key” on page 4 - 6). After installing the driver an icon will appear in the taskbar.
Quick Start Guide System Map: Front & Rear Views 1 2 3 Figure 1 - 4 Front View 4 5 9 6 11 7 8 12 10 Overheating To prevent your computer from overheating make sure nothing blocks the Vent/Fan Intake/Outlet while the computer is in use. 1. 2. 3. 4. 5. 6. Headphone-Out Jack Microphone-In Jack *S/PDIF-Out Jack Mini-IEEE 1394 Port LED Indicators Vent/Fan Intake/ Outlet 7. DVI-Out Port 8. HDMI-Out Port 9. **Combined eSATA/ USB Port 10. USB 2.0 Port 11. DC-In Jack 12.
1 Quick Start Guide Figure 1 - 5 Right View 1. 2. 3. 4. 5. Express Card Slot 7-in-1 Card Reader 2 * USB 2.0 Ports RJ-45 LAN Jack RJ-11 Phone Jack System Map: Right View 1 2 3 3 4 5 ExpressCard Slot The ExpressCard Slot accepts either ExpressCard/34 or ExpressCard/54 formats. 7-in-1 Card Reader The card reader allows you to use the most popular digital storage card formats: USB Ports Note that the connections to the USB ports only fit one way, do not force them.
Quick Start Guide System Map: Left View Figure 1 - 6 Left View 1. Optional Device Drive Bay (for CD/DVD Device, see page 2 - 3) 1 Changing DVD Regional Codes CD/DVD Emergency Eject Go to the Control Panel and double-click Device Manager (Hardware and Sound), then click the + next to DVD/CD-ROM drives.
1 Quick Start Guide Figure 1 - 7 Bottom View System Map: Bottom View 1 1. Vent/Fan Intake/Outlet 2. Battery 3. Battery Release Latch 4. Component Bay Cover 5. 3.5G USIM Card Cover 1 1 1 1 2 3 1 4 5 1 Battery Information Always completely discharge, then fully charge, a new battery before using it. Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges. See “Battery Information” on page 3 - 10 for full instructions.
Quick Start Guide Windows Vista Start Menu & Control Panel Most of the control panels, utilities and programs within Windows Vista (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop. Right-click the Start menu icon , and then select Properties if you want to customize the appearance of the Start menu.
1 Quick Start Guide Video Features You can configure display options, from the Display Settings control panel in Windows as long as the appropriate video driver is installed. For more detailed video information see “NVIDIA Video Driver Controls” on page B - 1. To access Display Settings in Windows: 1. Click Start, and click Control Panel (or point to Settings and click Control Panel). 2.
Quick Start Guide Display Devices & Options Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display or TV (connected to the DVI-Out port/HDMI-Out port) as your display device. 1 2 4 3 Figure 1 - 9 - Display Settings & NVIDIA Control Panel NVIDIA Display Mode Description Single One display device is used.
1 Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 1 - 15) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu. Note that the Power saver plan may have an affect on computer performance.
Storage Devices, Mouse, Audio & Printer Chapter 2: Storage Devices, Mouse, Audio & Printer Overview Read this chapter to learn more about the following main features and components of the computer: • • • • • • • Hard Disk Drive Optical Device 7-in-1 Card Reader ExpressCard Slot TouchPad and Buttons/Mouse Audio Features Adding a Printer Overview 2 - 1 2
Storage Devices, Mouse, Audio & Printer 2 Power Safety Before attempting to access any of the internal components of your computer please ensure that the machine is not connected to the AC power, and that the machine is turned off. Also ensure that all peripheral cables, including phone lines, are disconnected from the computer. Figure 2 - 1 Hard Disk Location 2 - 2 Hard Disk Drive Hard Disk Drive The hard disk drive is used to store your data in the computer.
Storage Devices, Mouse, Audio & Printer Optical Device There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual device will depend on the model you purchased (see “Storage” on page C - 3). The optical device is usually labeled “Drive D:” and may be used as a boot device if properly set in the BIOS (see “Boot Menu” on page 5 - 13).
Storage Devices, Mouse, Audio & Printer 2 Handling CDs or DVDs CD Emergency Eject If you need to manually eject a CD (e.g. due to an unexpected power interruption) you may push the end of a straightened paper clip into the emergency eject hole. However please do NOT use a sharpened pencil or similar object that may break and become lodged in the hole. Disk Eject Warning Don’t try to remove a CD/DVD while the system is accessing it. This may cause the system to “crash”.
Storage Devices, Mouse, Audio & Printer DVD Regional Codes 2 To change the DVD regional codes see “Changing DVD Regional Codes” on page 1 - 13.
Storage Devices, Mouse, Audio & Printer 2 Card Reader Cover Make sure you keep the cover in the card reader when not in use. This will help prevent foreign objects and/or dust getting in to the card reader. 7-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).
Storage Devices, Mouse, Audio & Printer ExpressCard Slot The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/ 34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC Cards). ExpressCard/54 is used for applications which require a larger interface slot, e.g. CompactFlash card reader. The number denotes the card width; 54mm for the Express Card/54 and 34mm for the ExpressCard/34.
Storage Devices, Mouse, Audio & Printer 2 Mouse Driver If you are using an external mouse your operating system may be able to auto-configure your mouse during its installation or only enable its basic functions. Be sure to check the device’s user documentation for details. TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a mouse to your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse.
Storage Devices, Mouse, Audio & Printer Audio Features You can configure the audio options on your computer from the Sound control panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar/ control panel (right-click the taskbar icon to bring up an audio menu). The volume may also be adjusted by means of the Fn + F5/F6 key combination. Sound Volume Adjustment The sound volume level is set using the volume control within Windows (and the volume function keys on the computer).
Storage Devices, Mouse, Audio & Printer 2 Parallel Printer After setting up the printer attach the parallel cable to the printer. Connect the printer’s parallel cable to the Parallel to USB converter, and then plug the converter into the USB port. Turn ON the printer, then turn ON the computer. Windows will identify the printer and either load one of its own drivers or ask you to supply one. Follow the on-screen instructions. Adding a Printer The most commonly used peripheral is a printer.
Power Management Chapter 3: Power Management Overview To conserve power, especially when using the battery, your computer power management conserves power by controlling individual components of the computer (the monitor and hard disk drive) or the whole system.
Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. 3 AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components (see page C - 6). 1. 2. 3. 4. Attach the AC/DC adapter to the DC-In jack at the rear of the computer. Plug the AC power cord into an outlet, and then connect the AC power cord to the AC/DC adapter. Raise the lid/LCD to a comfortable viewing angle.
Power Management Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press the power button on the front panel. When the computer is on, you can use the power button as a Sleep/Hibernate hotkey button when it is pressed for less than 4 seconds (pressing and holding the power button for longer than this will force the computer to shut down). Use Power Options (Hardware and Sound menu) control panel in Windows Vista to configure this feature.
Power Management 3 Resuming Operation See Table 3 - 1, on page 3 - 9 for information on how to resume from a power-saving state. Password It is recommended that you enable a password on system resume in order to protect your data. Figure 3 - 1 Power Plan Advanced Settings 3 - 4 Power Plans Power Plans The computer can be configured to conserve power by means of power plans. You can use (or modify) an existing power plan, or create a new one.
Power Management Each Windows Power Plan will also adjust the processor performance of your machine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). 3 Choose High performance for maximum performance when the computer is powered from an AC power source.
Power Management 3 Power Button The Power Button in the Start Menu (in Classic View use the Shut Down button ) can be used to send the computer into a powersaving state. Sleep Mode & Mobile PC Battery A mobile PC in Sleep uses very little battery power. After an extended period of time the computer will save any open documents and applications to hard disk. Power-Saving States You can use power-saving states to stop the computer’s operation and restart where you left off.
Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost. Hibernate will also return you to where you last left off within seconds.
Power Management 3 Password Protection Configuring the Power Buttons The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the computer in to a power-saving state. It is recommended that you enable a password on wake up in order to protect your data. However you can disable this setting from the Power Options menu by clicking Require a password on wakeup in the left menu, and selecting the options (click Change settings that are currently unavailable).
Power Management Resuming Operation You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo). Power Status Icon To Resume Color Power Off Off Press the Power Button Sleep Blinking Green Press the Power Button Closing the Lid If you have chosen to send the computer to Sleep when the lid is closed, raising the lid will wake the system up.
Power Management 3 Low Battery Warning When the battery is critically low, immediately connect the AC/DC adapter to the computer or save your work, otherwise, the unsaved data will be lost when the power is depleted. Battery Information Please follow these simple guidelines to get the best use out of your battery. Battery Power Your computer’s battery power is dependent upon many factors, including the programs you are running, and peripheral devices attached. You can set actions to be taken (e.g.
Power Management Conserving Battery Power • Use a power plan that conserves power (e.g Power saver), however note that this may have an affect on computer performance. • Lower the brightness level of the LCD display. The system will decrease LCD brightness slightly to save power when it is not powered by the AC/DC adapter. • Reduce the amount of time before the display is turned off. • Close wireless, Bluetooth, modem or communication applications when they are not being used.
Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. 3 We recommend that you do not remove the battery yourself. If you do need to remove the battery for any reason see “Removing the Battery” on page 6 - 3. New Battery Always completely discharge, then fully charge, a new battery (see “Battery FAQ” on page 3 - 14 for instructions on how to do this).
Power Management Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode • DO NOT connect the metal terminals (+, -) to each other Damaged Battery Warning Should you notice any physical defects (e.g. the battery is bent out of shape after being dropped), or any unusual smells emanating from the notebook battery, shut your computer down immediately and contact your service center.
Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own. 3 1. 2. 3. Figure 3 - 7 Power Plan Create 3 - 14 Battery Life Save and close all files and applications. Create a power plan for discharging the battery and set all the options to Never.
Power Management 4. 5. Scroll down to Battery and click + to expand the battery options.
Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. 3 How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
Drivers & Utilities Chapter 4: Drivers & Utilities This chapter deals with installing the drivers and utilities essential to the operation or improvement of some of the computer’s subsystems. The system takes advantage of some newer hardware components for which the latest versions of most available operating systems haven’t built in drivers and utilities. Thus, some of the system components won’t be auto-configured with an appropriate driver or utility during operating system installation.
Drivers & Utilities Driver Installation Insert the Device Drivers & Utilities + User’s Manual disc and click Install Drivers (button), or Option Drivers (button) to access the Optional driver menu. 1. 2. 4 3. Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in this order) which is the same as that listed in the Drivers Installer menu below. Click to select the driver you wish to install, after installing each driver it will become grayed out.
Drivers & Utilities Driver Page Chipset Page 4 - 5 Video Page 4 - 5 Audio Page 4 - 5 Modem Page 4 - 5 LAN Page 4 - 5 TouchPad Page 4 - 6 Card Reader/ExpressCard Page 4 - 6 Hot Key Page 4 - 6 Intel MEI Driver Page 4 - 6 e-SATA Support Page 7 - 33 Wireless LAN Module Page 7 - 6 PC Camera Module Page 7 - 12 3.
Drivers & Utilities 4 Updating/Reinstalling Individual Drivers User Account Control (Win Vista) If you wish to update/reinstall individual drivers it may be necessary to uninstall the original driver.To do this go to the Control Panel in the Windows OS and double-click the Programs and Features icon (Programs > Uninstall a program). Click to select the driver (if it is not listed see below) and click Uninstall, and then follow the on screen prompts (it may be necessary to restart the computer).
Drivers & Utilities Driver Installation Procedure Insert the Device Drivers & Utilities + User’s Manual disc and click Install Drivers (button), or Option Drivers (button) to access the Optional driver menu. Chipset 1. Click 1.Install Chipset Driver > Yes. 2. Click Next > Yes > Next > Next. 3. Click Finish to restart the computer. Video 1. Click 2.Install Video Driver > Yes. 2. Click Next. 3. Click Finish to restart the computer. Audio 1. Click 3. Install Audio Driver > Yes. 2. Click Next. 3.
Drivers & Utilities 4 TouchPad 1. Click 6.Install Touchpad Driver > Yes. 2. Click Next > Finish. 3. Click Restart Now to restart the computer. Intel MEI Driver 1. Click 9.Install Intel MEI Driver > Yes. 2. Click Next > Yes > Next. 3. Click Next > Finish to complete the installation. Card Reader/ExpressCard 1. Click 7.Install Cardreader Driver > Yes. 2. Click Next > Install. 3. Click Finish. e-SATA Support Hot Key 1. Click 8.Install HotKey Utility > Yes. 2. Click Next > Install. 3.
Drivers & Utilities Optional Drivers Windows Update See the pages indicated for the driver installation procedures for any modules included in your purchase option. After installing all the drivers make sure you enable Windows Update in order to get all the latest security updates etc. (all updates will include the latest hotfixes from Microsoft). 4 To enable Windows Update make sure you are connected to the internet: 1. 2. 3. 4. 5.
Drivers & Utilities 4 Bluetooth Module Fingerprint Reader Module Note: The operating system is the default setting for Bluetooth control in Windows Vista, and does not require a driver. See “Bluetooth Module” on page 7 - 2 for configuration instructions. See the install procedure in “Fingerprint Reader Module” on page 7 - 28. Wireless LAN See the appropriate install procedure for your WLAN module in “Wireless LAN Module” on page 7 - 6.
BIOS Utilities Chapter 5: BIOS Utilities Overview This chapter gives a brief introduction to the computer’s built-in software: Diagnostics: The POST (Power-On Self Test) Configuration: The Setup utility If your computer has never been set up, or you are making important changes to the system (e.g. hard disk setup), then you should review this chapter first and note the original settings found in Setup. Even if you are a beginner, keep a record of the settings you find and any changes you make.
BIOS Utilities POST Screen 5 1.BIOS information 2.CPU type 3.Memory status 4.Enter Setup prompt appears only during POST Note: The POST screen as pictured is for guideline purposes only. Figure 5 - 1 POST Screen The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to conduct a POST, including a quick test of the on-board RAM (memory). As the POST proceeds, the computer will tell you if there is anything wrong.
BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “nonfatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible. Non-Fatal Errors This kind of error still allows you to boot.
BIOS Utilities The Setup Utility The Phoenix Setup utility tells the system how to configure itself and manage basic features and subsystems (e.g. port configuration). Entering Setup 5 To enter Setup, turn on the computer and press F2 during the POST. The prompt (Press F2 to Enter Setup) seen in Figure 5 - 1 on page 5 - 2 is usually present for a few seconds after you turn on the system. If you get a “Keyboard Error”, (usually because you pressed F2 too quickly) just press F2 again.
BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with menu headings. When you select a heading, a new screen appears. Scroll through the features listed on each screen to make changes to Setup. Instructions on how to navigate each screen are in the box along the bottom of the screen.
BIOS Utilities Main Menu Phoenix SecureCore(tm) Setup Utility Figure 5 - 2 Main Main Main Menu Security Boot Exit Item Specific Help System Time: System Date: [22:12:05] [04/18/2008] SATA Port 1 SATA Port 2 SATA Port 3 [FUJITSU MHW2160BH-(P] [Optiarc DVD RWDVD CRX8] [None] System Memory: Extended Memory: 640 KB 2045 MB BIOS Revision: KBC/EC Firmware Revision: ******** ******** VGA Card: VBIOS Revision: VBIOS Build Date: ******** ******** ******** 5 Advanced F1 Esc Help Exit
BIOS Utilities SATA Port 1/2/3 (Main Menu) Pressing Enter opens the sub-menu to show the configuration of a hard disk or optical device drive on the computer’s SATA Ports. Use the Auto (Type:) setting to have the items configured automatically for you. System/Extended Memory: (Main Menu) This item contains information on the system memory, and is not user configurable. The system will auto detect the amount of memory installed. 5 BIOS Revision/VGA Card etc.
BIOS Utilities Advanced Menu Phoenix SecureCore(tm) Setup Utility Figure 5 - 3 Main A dvanced Advanced Security Boot Exit Advanced Menu 5 SATA Mode & eSata Port You should select AHCI mode in SATA Mode Selection to support the eSATA port in Windows Vista (hot-swapping is not supported in Windows XP).
BIOS Utilities SATA Mode Selection (Advanced Menu) This menu is only available if you select the Vista O/S as your operating system. You can configure SATA (Serial ATA) control to operate in either IDE (native/ compatible) or AHCI (Advanced Host Controller Interface) modes from this menu. The SATA mode should be set to AHCI mode for this system (unless you are sure your hard disk can only operate in IDE mode). If you are unsure of the mode your hard disk supports contact your service center.
BIOS Utilities Boot-time Diagnostic Screen: (Advanced Menu) Use this menu item to enable/disable the Boot-time Diagnostic Screen. Legacy OS Boot: (Advanced Menu) Enable this item to support only system boot from the Legacy OS (e.g Windows Vista). If disabled the system will attempt to boot from the EFI (Extensible Firmware Interface) before the Legacy OS. 5 Reset Configuration Data: (Advanced Menu) This item is set to No as default.
BIOS Utilities Security Menu Phoenix SecureCore(tm) Setup Utility Main Advanced Security Security Boot Exit Security Menu = Item Specific Help F1 Esc Supervisor Password Is: User Password Is: Clear Clear Set Supervisor Password Set User Password [Enter] [Enter] Password on boot: Fixed disk boot sector: [Disabled] [Normal] Help Exit Select Item Select Menu -/+ Enter Supervisor Password controls access to the setup utility.
BIOS Utilities Password Warning 5 If you set a boot password (Password on boot is “Enabled“), NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk. Set User Password (Security Menu) You can set a password for user mode access to the Phoenix SecureCore Setup Utility.
BIOS Utilities Boot Menu Phoenix SecureCore(tm) Setup Utility Main Advanced Security Boot Figure 5 - 5 Exit Item Specific Help Boot priority order: 1: USB FDC: 2: USB KEY: 3: USB HDD: 4: IDE CD: Optiarc CDRWDVD CRX890S-(P 5: IDE HDD: FUJITSU MHY2160BH-(PM) 6: PCI BEV: 7: 8: Excluded from boot order: : USB CDROM: : USB ZIP: F1 Esc Help Exit Select Item Select Menu -/+ Enter Boot Menu Keys used to view or configure devices: Up and Down arrows select a device.
BIOS Utilities Exit Menu Figure 5 - 6 Exit Menu Phoenix SecureCore(tm) Setup Utility Main Advanced Security Boot Exit Item Specific Help Exit Saving Changes Exit Discarding Changes Load Setup Defaults Discard Changes Save Changes 5 F1 Esc Help Exit Select Item Select Menu Exit System Setup and save your changes to CMOS.
Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps outlined to make the desired upgrades. If you have any trouble or problems you can contact your service representative for further help.
Upgrading The Computer When Not to Upgrade Power Safety Warning 6 Before you undertake any upgrade procedures, make sure that you have turned off the power, and disconnected all peripherals and cables (including telephone lines). It is advisable to also remove your battery in order to prevent accidentally turning the machine on. These procedures involve opening the system’s case, adding and sometimes replacing parts.
Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons it is best to remove the battery. 1. 2. Turn the computer off, turn it over and remove the battery. Slide latch 1 towards the unlock symbol and hold it in place, and lift the battery 2 up and out of the battery bay. Warranty Warning Please check with your service representative before undertaking any upgrade procedures to find out if this will VOID your warranty.
Upgrading The Computer HDD System Warning 6 New HDD’s are blank. Before you begin make sure: You have backed up any data you want to keep from your old HDD. You have all the CD-ROMs and FDDs required to install your operating system and programs. If you have access to the internet, download the latest application and hardware driver updates for the operating system you plan to install. Copy these to a removable medium.
Upgrading The Computer 3. 4. Carefully (a fan and cable are attached to the under side of the cover) lift up the bay cover. Carefully disconnect the fan cable 8 , and remove the cover 9 . Fan Cable 8 9 8 Make sure you reconnect the fan cable 8 before screwing down the bay cover. Figure 6 - 3 Bay Cover Removal 5. Remove screws 10 - 11 from the hard disk cover.
Upgrading The Computer 6. Pull the hard disk assembly in the direction of the arrow 12 . Figure 6 - 5 Hard Disk Pull 12 6 7. Carefully remove the hard disk assembly in the direction of the arrow 13 .
Upgrading The Computer 8. 9. Remove screws 14 - 15 to separate the hard disk from the bracket. Reverse the process to install any new hard disk.
Upgrading The Computer Upgrading the System Memory (RAM) The computer has two memory sockets for 204 pin Small Outline Dual In-line (SODIMM) DDR III (DDR3) type memory modules (see “Memory” on page C - 2). The total memory size is automatically detected by the POST routine once you turn on your computer. 1. 2. Turn off the computer, and turn it over and remove the battery. Locate the component bay cover and remove screws 1 - 7 .
Upgrading The Computer 3. 4. Carefully (a fan and cable are attached to the under side of the cover) lift up the bay cover. Carefully disconnect the fan cable 8 , and remove the cover 9 . Fan Cable Make sure you reconnect the fan cable 8 before screwing down the bay cover. 8 9 8 Figure 6 - 9 Bay Cover Removal 5. Gently pull the two release latches ( 10 & 11 ) on the sides of the memory socket in the direction indicated below.
Upgrading The Computer 6. The RAM module 12 will pop-up, and you can remove it. Contact Warning 6 Be careful not to touch the metal pins on the module’s connecting edge. Even the cleanest hands have oils which can attract particles, and degrade the module’s performance. 12 Figure 6 - 11 RAM Module Removal Fan Cable Make sure you reconnect the fan cable 8 (see Figure 6 - 9) before screwing down the bay cover. 7. 8. Pull the latches to release the second module if necessary.
Upgrading The Computer Upgrading the Optical (CD/DVD) Device 1. 2. Turn off the computer, and turn it over and remove the battery. Locate the component bay cover and remove screws 1 - 7 .
Upgrading The Computer 3. 4. Carefully (a fan and cable are attached to the under side of the cover) lift up the bay cover. Carefully disconnect the fan cable 8 , and remove the cover 9 . Fan Cable Make sure you reconnect the fan cable 8 before screwing down the bay cover. 6 8 9 8 Figure 6 - 13 Bay Cover Removal 5. Remove the screw at point 10 , and use a screwdriver to carefully push out the optical device at point 11 .
Modules Chapter 7: Modules Overview This chapter contains the information on the various modules (some of which are optional) which may come with your computer, depending on the configuration purchased. If you are unsure please contact your service representative. The chapter includes information on the following: • • • • • • Bluetooth Module Wireless LAN Module PC Camera Module 3.
Modules 7 Bluetooth Module Wireless Device Operation Aboard Aircraft The optional Bluetooth module allows you to connect your computer to Bluetooth enabled devices such as other computers, desktop computers, mobile phones, printers, digital cameras, PDAs, headsets etc. using a short-range radio frequency. The use of any portable electronic transmission devices aboard aircraft is usually prohibited. Make sure the module(s) are OFF if you are using the computer aboard aircraft.
Modules Bluetooth Configuration in Windows Vista Setup your Bluetooth Device so the Computer Can Find it 1. 2. Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Make the device discoverable (to do this check your device documentation). To Turn the Bluetooth Module On 1. 2. 3. Press the Fn + F12 key combination to power on the Bluetooth module. A Bluetooth icon will appear in the taskbar (see sidebar). You can then do any of the following to access the Bluetooth Devices control panel.
Modules To Add a Bluetooth Device 1. 2. Figure 7 - 2 Add Bluetooth Device Wizard 3. 4. 5. Access the Bluetooth Devices control panel. Click Options (tab), and make sure that Allow Bluetooth devices to connect to this computer check box (Connections) has a tick inside it. Click Devices (tab), and then click Add. The Add Bluetooth Device Wizard will appear. Click to select “My device is set up and ready to be found”, and then click Next. 6. 7. 8.
Modules To Change Settings for the Bluetooth Device 1. 2. Access the Bluetooth Devices control panel. Click on the device you want to change and click Properties to: • • Change the name of the device (click General, type a new name and click OK). Enable/Disable a service (click Services, clear/tick the check box next to the service and click OK). To Make your Computer Discoverable to Bluetooth Devices 1. 2. 3. Access the Bluetooth Devices control panel.
Modules Wireless Device Operation Aboard Aircraft The use of any portable electronic transmission devices aboard aircraft is usually prohibited. Make sure the module(s) are OFF if you are using the computer aboard aircraft. 7 Wireless LAN Module If you have included an Intel® Wi-Fi Link 5100/5300 Series (802.11 a/g/n) WLAN module, or 3rd Party 802.11b/g WLAN module in your purchase option, make sure that the Wireless LAN module is on before installing the driver.
Modules Intel® Wi-Fi Link 5100/5300 Series (802.11 a/g/n) Driver Installation 1. Make sure the module is powered on, then insert the Device Drivers & Utilities + User’s Manual disc into the CD/DVD drive. 2. Click Option Drivers (button). 3. Click 1.Install Wireless Lan Driver > Yes. 4. Windows will then configure the driver software and automatically restart the computer. Note: The operating system is the default setting for Wireless LAN control in Windows Vista (see overleaf). 802.
Modules Connecting to a Wireless Network Make sure the Wireless LAN module is turned on. 1. Click the taskbar wireless icon , and then click Connect to a network (or rightclick the icon , and then click Connect to a network). Figure 7 - 5 Taskbar Menus Click icon Right-click icon 7 Network and Sharing Center 2. 3. In the Show list, click to choose Wireless from the drop-down menu. A list of currently available networks will appear.
Modules 4. 5. Click a network, and then click Connect. If you do not see a network you want to connect to, click Set up a connection or network (a list of options will appear allowing manual searching, and creating a new network). Figure 7 - 7 Connecting 7 6. Move the cursor over the taskbar icon to see the connection status (see below).
Modules 7. Security Enabled Networks To disconnect from the wireless network you can click the taskbar wireless icon , and then select Connect or disconnect to access the network menu, and click Disconnect (or right-click the icon , and then click Disconnect from). You should try to make sure that any network you are connecting to is a secure network. 7 Click icon Connecting to unsecure networks may allow unauthorized access to your computer, documents, websites and files etc.
Modules PC Camera Module Before installing the driver, make sure the PC Camera is on. Use the Fn + F10 key combination (see Table 1 - 4, on page 1 - 10) to toggle power to the PC Camera module. When the PC Camera module is powered on, the indicator will briefly be displayed. Make sure you install the drivers in the order indicated in Table 4 1, on page 4 - 3. PC Camera Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. 2.
Modules PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. 1. 2. 3. 4. 7 Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound). Click Recording (tab). Right-click Microphone (Realtek High Definition Audio) and make sure the item is not disabled. 5. Double-click Microphone (or select Properties from the right-click menu). 6.
Modules Figure 7 - 10 Audio Setup for PC Camera Right-click 7 PC Camera Module 7 - 13
Modules Pre-Allocating File Space You may pre-allocate the file size (File > Allocate File Size) for the capture file in the BisonCap program. 7 Pre-allocating space on the hard disk can improve the capture quality (particularly of large capture files), by reducing the amount of work the hard disk has to do in finding space for the video data as it is being captured. See also “Reducing Video File Size” on page 7 - 15.
Modules Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties). If necessary you can remove the recorded video file to a removable medium e.g. CD, DVD or USB Flash drive.
Modules Eliminating Screen Flicker If you find that the video screen in the BisonCap program is flickering, you can try to adjust the setting in the Video Capture Filter options. 1. 2. 3. Run the BisonCap program. Go to Options and scroll down to select Video Capture Filter.... Click either 50Hz or 60Hz under Frequency in Property Page (tab).
Modules Zoom The BisonCap program allows you to zoom the camera in and out. 1. 2. Run the BisonCap program. Go to Zoom and select Zoom Out/Zoom In. Figure 7 - 12 Zoom/Setting Snapshot Folder Taking Still Pictures The BisonCap program allows you to take still pictures. 1. 2. 3. Run the BisonCap program. Go to Options and select Take Picture. The picture (in JPEG format) will be placed in the Snapshot folder desktop. on the The Snapshot folder’s default location is on the desktop.
Modules Power Safety Warning 7 Before you undertake any installation procedures, make sure that you have turned off the power, and disconnected all peripherals and cables (including telephone lines). It is advisable to also remove your battery in order to prevent accidentally turning the machine on. 3.5G Module If you have included an optional 3.
Modules 4. Slide the SIMLOCK towards the hinge (in the direction of the arrow in Figure 7 14) in order to release the lock and lift it up. Figure 7 - 14 SIMLOCK Open 5. 6. 7 Insert the USIM card as illustrated (Figure 7 - 15) and close the SIMLOCK. Lock the SIMLOCK by pushing it in the direction of the arrow (Figure 7 - 15) until it clicks into the lock position (replace the screw and cover as per Figure 7 - 13). Figure 7 - 15 Insert SIM Card and Lock SIMLOCK 3.
Modules 3G Watcher Application Wireless Device Operation Aboard Aircraft The use of any portable electronic transmission devices aboard aircraft is usually prohibited. Make sure the module(s) are OFF if you are using the computer aboard aircraft. 7 Use the Fn + key combination to toggle power to the 3.5G module, and check the indicator to see if the module is powered on or not (see Table 1 - 4, on page 1 - 10/). Figure 7 - 16 3G Watcher Application 7 - 20 3.5G Module With the 3.
Modules Setting Up a Carrier Profile Although the connection information is stored on the USIM card supplied by the service provider, you will need to set up the appropriate carrier profile from the 3G Watcher software. 1. 2. 3. 4. Power on the 3.5G module using the Fn + key combination. Access the 3G Watcher application from the Start menu (Start > Programs/All Programs > Sierra Wireless > 3G Watcher), or by clicking the desktop icon . Click Tools and select Options.
Modules 5. Figure 7 - 18 User Options Profile Information Profile Details 7 If you have chosen the profile from the dropdown list then most of the information in the General and Advanced tabs should be automatically filled in for you (however check with your service provider for the latest information as you may at least need to add in your Username and Password). Figure 7 - 19 Choose Profile 7 - 22 3.
Modules Connecting to the Service Provider 1. 2. 3. Power on the 3.5G module using the Fn + key combination. You can access the 3G Watcher application from the Start menu (Start > Programs/All Programs > Sierra Wireless > 3G Watcher), or by clicking the desktop icon . The software will run and display the service provider name (see “Setting Up a Carrier Profile” on page 7 - 21). Figure 7 - 20 Connect Button 7 4. 5. Click Connect to begin the connection process.
Modules 6. When the connection is successful a taskbar notification will appear (as below). 7. You can then access the internet, download e-mail etc. as per any internet connection. While you are connected the taskbar icon will be green (it will be red when the program is running but not connected). To disconnect click the Disconnect icon. Figure 7 - 22 Connected Taskbar Notification 8. 7 9. Figure 7 - 23 3GWatcher Connected 10. The program will disconnect from the service provider. 11.
Modules 12. If you click the 3G Watcher close icon to click OK to confirm the program exit. a message will be displayed asking you Figure 7 - 24 Exit Warning 7 13. Exiting the program DOES NOT turn off the 3.5G module, and you will need to press the Fn + key combination to turn off the module (pay careful attention to this aboard aircraft - see “Wireless Device Operation Aboard Aircraft” on page 7 - 20). 14.
Modules Short Messaging Service In addition to standard internet services you may also send and receive SMS text messages using the 3G Watcher program, if your service supports SMS. Reading SMS Messages 1. 2. 3. 4. 7 The SMS message indicator in the main window will notify you of any new messages received. Double-click the icon or select Tools > SMS Express. Select the inbox folder and select any message to read it.
Modules Fingerprint Reader Module The optional fingerprint reader Protector Suite Software provides a high level of security for your computer. A further level of security and control is provided in the BIOS (see “Security Menu” on page 5 - 11).
Modules Help & Manual Right-click the taskbar icon to bring up the menu to select Help. 7 Insert the Device Drivers & Utilities + User’s Manual disc and click Option Drivers (button). Click Unlock (button) and then click 4.Install FingerPrint Driver > Yes. Fingerprint Reader Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. 2. Click Option Drivers. 3. Click 4.Install FingerPrint Driver > Yes. 4. Click Software Installation. 5.
Modules User Enrollment (Application Version 1) 1. 2. 3. Click Start > Programs/All Programs > Protector Suite QL > User Enrollment, or double click the taskbar icon . On the first run of the program you will be asked to click the button to accept the license, and then click OK. Click Next and select “Enrollment to the hard disk”, and click Finish. Figure 7 - 25 Enroll to Hard Disk 4. 5. 6. 7. 8.
Modules 9. Fingerprint Enrollment Note that it is strongly recommended that you enroll more than one finger in case of injury etc. 10. 11. 12. 13. 14. Click the button above any of the fingers to begin the enrollment process for that finger. Swipe the finger three times to enroll that finger. Repeat the process for all the fingers you wish to enroll (see sidebar), and then click Next. Click Finish. Click any of the headings under “Learn more about:” to get more information on any topic. Click Close.
Modules 15. Right-click the taskbar icon to bring up the Control Center that allows you to Edit Fingerprints, Start Control Center, access the Help menu etc. You can also run the Control Center etc. from the Protector Suite QL item in the Programs/ All Programs menu. Figure 7 - 27 Control Center & Biomenu 7 16. See “Help & Manual” on page 7 - 28 for further details. 17.
Modules User Enrollment (Application Version 2) 1. 2. Click Start > Programs/All Programs > Protector Suite QL > User Enrollment, or double click the taskbar icon . Click Initialize. Figure 7 - 28 Initialize Fingerprints 7 3. 4. On the first run of the program you will be asked to click the button to accept the license, and then click OK. Click Next and select “Enrollment to the hard disk”, and click Finish.
Modules 5. 6. 7. 8. If you have not set a Windows password you will be prompted to do so (note: If you have not set a password Protector Suite QL cannot secure access to your computer). Click Next. You will then be prompted to enter your Windows password and click Next. Select either to use the fingerprint reader alone for authentication, or choose both the fingerprint reader and the Windows password, and then click Next. Figure 7 - 30 Multifactor 7 9.
Modules Fingerprint Enrollment Note that it is strongly recommended that you enroll more than one finger in case of injury etc. 11. Click the button above any of the fingers to begin the enrollment process for that finger. 12. Swipe the finger five times to enroll that finger. 13. Repeat the process for all the fingers you wish to enroll (see sidebar), and then click Next. 14. Click Finish. 15. Click “Help” in the Fingerprint Control Center to get more information on any topic. 16.
Modules 17. Right-click the taskbar icon to bring up the Control Center that allows you to Edit Fingerprints, register applications, manage Password Bank, File Safe and access the Help menu etc. You can also run the Control Center etc. from the Protector Suite QL item in the Programs/All Programs menu. Figure 7 - 32 Control Center & Biomenu 7 18. See “Help & Manual” on page 7 - 28 for further details. 19.
Modules Fingerprint Control Center Features (Application Version 2) Application Launcher The Application Launcher allows you to register applications to be launched when assigned to a particular finger. Simply copy the application icon on to one of the registered fingers and ten click OK to close the application window. Once registered the application will launch when you swipe the appropriate finger across the sensor.
Modules Intel Turbo Memory Module If you have included an Intel Turbo Memory (Robson) NAND flash memory card module in your purchase option, then you will need to enable the option in the BIOS (see “Advanced Menu” on page 5 - 8) BEFORE installing the Windows Vista operating system software (do not enable this option in Windows XP or on a Windows Vista operating system that has been installed without the option enabled).
Modules ReadyBoost Issue When the Intel® Turbo Memory Console is opened immediately after powering on the system, Windows ReadyBoost may appear to be disabled. 7 This is expected behavior. The status appears as disabled while Microsoft generates the Windows ReadyBoost file. Once the file has been generated, the status should appear as Enabled again. See the Intel website (http://support.intel.com/ support/chipsets/itm/sb/ CS-025852.htm) for the latest updated information on this issue. 6.
Modules Intel Turbo Memory Dashboard (User Pinning Supported Only) The Intel Turbo Memory Dashboard allows you to pin an application or file to load into the Intel Turbo Memory NAND cache for performance acceleration. 1. 2. 3. 4. 5. Run the Intel® Turbo Memory Dashboard from the Programs/All Programs menu (Intel® Turbo Memory) or from the desktop shortcut. The Pinning Capacity Consumption Meter 1 displays the amount of pinning space used.
Modules Unpinning an Application Click the application in the Accelerated Window and drag it back to the Applications Window to unpin the application. 7 Pinning an Application (User Pinning Supported Only) 1. The Intel® Turbo Memory Dashboard allows you to select files and applications to accelerate and therefore open faster and display quicker. 2. Applications will be listed in the Applications Window on the right. 3.
Modules Custom File Sets (User Pinning Supported Only) A Custom File Set allows you to group applications and files to accelerate. These sets can be moved easily in and out of the Accelerated Window which is of benefit when space is limited. You need to create the custom file set before dragging the set to the accelerated window. 1. 2. 3. 4. 5. Click Custom File Sets and type a name for the set, and then click Next. Select the file set folder icon and click Advanced.
Modules Windows ReadyBoost Intel Turbo Memory Console (All Modules) 1. Run the Intel® Turbo Memory Console from the Programs/All Programs menu (Intel® Turbo Memory). 2. You can enable/disable Windows ReadyBoost and Windows ReadyDrive from the Intel® Turbo Memory Console. If your module supports User Pinning (i.e. the Intel Turbo Memory Dashboard is installed) then ReadyBoost is not supported (the item will be grayed out).
Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.
Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer appears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working. Check the LED Power Indicators (see “LED Indicators” on page 1 - 7) to see the computer’s power status. • Connections - Check all the cables to make sure that there are no loose connections anywhere.
Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wallet. • Run maintenance programs on your hard disk and OS as often as you can. You may schedule these programs to run at times when you are not using your computer.
Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the definitions file updates are usually downloadable directly from the internet. • Be careful when opening e-mail from sources you don’t know.
Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing. • Read the documentation.
Troubleshooting • Don’t over complicate things. The less you have to deal with then the easier the source of the problem may be found; Example - if your computer has many devices plugged into its ports, and a number of programs running, then it will be difficult to determine the cause of a problem. Try disconnecting all of the devices and restarting the computer with all the peripheral devices unplugged.
Troubleshooting Problems & Possible Solutions Problem Possible Cause - Solution You turned the power on but it doesn’t work. Battery missing / incorrectly installed. Check the battery bay, make sure the battery is present and seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts. The Battery LED power indicator , is blinking orange. Low Battery. Plug in the AC power source.
Troubleshooting Problem Possible Cause - Solution The computer feels too hot. Make sure the computer is properly ventilated and the vents/fan intakes are not blocked. If this doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating” on page 1 - 11). Make sure you’re using the correct adapter.
Troubleshooting Problem You forget password. the Possible Cause - Solution boot If you forget the password, you may have to discharge the battery of the CMOS. Contact your service representative for help. Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
Troubleshooting 8 Problem Possible Cause - Solution The TouchPad doesn’t work. The Touchpad has been disabled. Press the Touchpad toggle (Fn + F1) key combination (make sure you have installed the Touchpad driver. The system freezes or the screen goes dark. The system’s power saving features have timed-out. Use the AC/DC adapter, press a key on the keyboard, or press the sleep (Fn + F4) key combination, or press the power button if no LEDs are lit. The system never goes into a power saving mode.
Troubleshooting Problem Possible Cause - Solution The Hibernate function has disappeared. You have a computer with 4GB of RAM and have installed Windows Vista Service Pack 1. This is a known issue if your computer has 4GB of RAM and is running Windows Vista Service Pack 1. To re-enable Hibernate mode go to the Command Prompt and type the command “powercfg -h on” (make sure you are logged on as an Administrator): 1. 2. 3. 4. 5. 6.
Troubleshooting 8 Problem Possible Cause - Solution Nothing appears on the screen when the PC Camera software is run. You have selected an external display as the default display device. The PC Camera application software needs to be run while the default notebook LCD is the selected display device. After a camera picture is obtained on the default notebook LCD, you may then use the Fn + F7 to toggle through the display modes (give the screen time to refresh).
Troubleshooting Problem Possible Cause - Solution The Connect to a network window does not display any available wireless networks when the connect to a network button is clicked in the Windows Mobility Center (for 3rd party 802.11b/g WLAN modules only). You have clicked the connect to a network button in the Windows Mobility Center while the Wireless LAN module is powered OFF.
Troubleshooting Screen Resolution Error If you are experiencing either screen resolution reduction, or screen flickering after resuming from Sleep in Windows Vista only then follow the instructions below to fix this problem. This error arises in compliance with Windows Vista policy, which triggers TMM (Transient Multi-Monitor Manager) when the notebook lid (S3) is closed. TMM disconnects the LCD display from the OS and then adds the LCD display back when the lid is opened.
Troubleshooting 3. 4. 5. Double-click Task Scheduler Library > Microsoft > Windows. Click MobilePC to open the control panel. Right-click TMM and select Disable. 8 Figure 8 - 2 - TMM Disable 6. Close all the control panels.
Troubleshooting 8 8 - 16
Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the ports & jacks which allow your computer to communicate with external devices, connect to the internet etc.
Interface (Ports & Jacks) Ports and Jacks Item Card Reader Description The card reader allows you to use the following digital storage cards: MMC (MultiMedia Card) SD (Secure Digital) MS (Memory Stick) MS (Memory Stick Pro) DC-In Jack A RS MMC (requires PC adapter) Mini SD (requires PC adapter) MS Duo (requires PC adapter) Plug the supplied AC/DC adapter into this jack to power your computer. DVI-Out Port The DVI-Out (Digital Visual Interface) Port is a video connector interface.
Interface (Ports & Jacks) Item Description HDMI-Out Port HDMI The HDMI-Out (High-Definition Multimedia Interface) is an audio/video connector interface for transmitting uncompressed digital streams. This allows you to connect an external monitor, TV or Flat Panel Display etc. as a display device (see “Attaching Other Displays” on page B - 5) by means of a HDMI cable. Note that HDMI carries both audio and video signals (see “HDMI Audio Configuration” on page B - 7).
Interface (Ports & Jacks) A Item Description RJ-11 Phone Jack This port connects to the built-in modem. You may plug the telephone line directly into this RJ-11 telephone connection. Note: Broadband (e.g. ADSL) modems usually connect to the LAN port. RJ-45 LAN Jack This port supports LAN (Network) functions. Note: Broadband (e.g. ADSL) modems usually connect to the LAN port.
NVIDIA Video Driver Controls Appendix B: NVIDIA Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - 16. Resolution Error NVIDIA Video Driver Installation Make sure you install the drivers in the order indicated in Table 4 - 1, on page 4 - 3. 1. Insert the Device Drivers & Utilities + User’s Manual disc and click Install Drivers (button). 2. Click 2.Install Video Driver > Yes. 3. Click Next. 4. Click Finish to restart the computer.
NVIDIA Video Driver Controls NVIDIA Control Panel To access the GeForce..... control panel from the desktop; right-click the desktop, then click NVIDIA Control Panel. B NVIDIA Control Panel More advanced video configuration options are provided in the NVIDIA Control Panel tab. 1. 2. 3. 4. Open the Display Settings (see page 1 - 17) control panel. Click Advanced Settings (button). Click GeForce..... (tab). Click Start the NVIDIA Control Panel to make any video adjustments. 1. 2.
NVIDIA Video Driver Controls The NVIDIA Control Panel provides additional video configuration controls and tools which allow quick access to features such as display configuration, 3D Settings and Help menus etc. Navigating the Control Panel Navigate through the control panels in much the same way as you would a web page. Click on the sub-heading tasks in the left menu (and on the highlighted links) for information. Use the buttons on the top left to go back, forward etc.
NVIDIA Video Driver Controls The Help menus provide index and search features, and direct links to the NVIDIA website etc.
NVIDIA Video Driver Controls Attaching Other Displays Note that you can use a DVI cable connected to the DVI-Out port, or an HDMI (High-Definition Multimedia Interface) cable connected to the HDMI-Out port to connect an external display (if you are using an older type of monitor you can use a converter to convert the signal from DVI to VGA). See your display device manual to see which formats are supported. Configuring an External Display in Windows Vista 1. 2. 3.
NVIDIA Video Driver Controls Configuring an External Display using the NVIDIA Control Panel Alternatively you can use the NVIDIA control panel to configure any attached displays. 1. 2. 3. Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. Go to NVIDIA Control Panel (see “NVIDIA Control Panel” on page B - 2). Click Display, and then click Set up multiple displays. 4. 5. Click to select the nView display mode you wish to use (see page B - 9).
NVIDIA Video Driver Controls HDMI Audio Configuration As HDMI (High-Definition Multimedia Interface) carries both audio and video signals you will need to configure the audio output as per the instructions below. The settings will depend upon the video card you have installed in your purchase option. Windows Audio Setup for HDMI 1. 2. 3. 4. 5. 6. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound).
NVIDIA Video Driver Controls Other Applications If you are using a third party application to play DVDs etc. you will need to consult the application’s documentation to see the appropriate audio configuration (the application must support digital to analog translation). HDMI Notes • Connect a device with HDMI support to the HDMI-Out port BEFORE attempting to play audio/video sources through the device.
NVIDIA Video Driver Controls Display Modes Single Display Mode Only one of your displays is used. Clone Mode Clone Mode simply shows an exact copy of the Primary display desktop on the other display(s). This mode will drive multiple displays with the same content. Resolution Error If you are experiencing screen resolution problems/screen flickering after resuming from Sleep in Windows Vista see page 8 - 14.
NVIDIA Video Driver Controls Using New Display Detected to Enable Extended Mode 1. 2. 3. 4. 5. Figure B - 7 New Display Detected (Extended) B B - 10 Display Modes Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. If a New Display Detected window does not appear in Windows Vista, go to the Windows Mobility Center control panel (Mobile PC > Adjust commonly used mobility settings) and click Connect display.
NVIDIA Video Driver Controls Using Display Settings to Enable Extended Mode 1. 2. 3. 4. Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Adjust screen resolution under the Appearance and Personalization menu (or double-click Personalization > Display Settings). Click the monitor icon (e.g. 2 ), and make sure you have checked “Extend the desktop onto this monitor.” and click Apply.
NVIDIA Video Driver Controls Detect Displays To get a full range of display options click “My display is not shown in the list...”. HDMI Audio Setup Enabling TV Display To display desktop images on a TV, connect the TV to your computer by using an HDMI cable/DVI cable from the TV to the HDMI-Out port/DVI-Out port at the rear of the computer. You will need to enable the TV display from the NVIDIA Control Panel as per the instructions on B - 5. The TV will appear as a display option (2.
NVIDIA Video Driver Controls Changing the TV Signal Format 1. 2. 3. 4. When the TV is enabled as a display device, click the sub-menus under Video & Television. Click “Change the signal or HD format”. Select the TV signal format (the menu allows you to select TV format by country if you are unsure of your TV format). Apply the settings, and then click Yes to save the changes.
NVIDIA Video Driver Controls B B - 14
Specifications Appendix C: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your service center for details.
Specifications Feature Specification Core Logic Intel(R) PM45 + ICH9M Chipset LCD Flat Panel TFT (For One of the Following Options) 15.4" WXGA (1280 * 800) TFT LCD (Glare Type) OR 15.4" WXGA+ (1440 * 900) TFT LCD OR 15.4" WSXGA+ (1680 * 1050) TFT LCD (Glare Type) OR 15.
Specifications Feature Video Adapter Options Video Card Options Note that card types, specifications and drivers are subject to continual updates and changes. Check with your service center for the latest details on video cards supported. Specification NVIDIA GeForce 9600M GS PCI-E Video Card 256MB GDDR3 Video RAM On Board MS DirectX® 10.0 Compatible Supports HDCP NVIDIA GeForce 8800M GTX PCI-E Video Card 512MB GDDR3 Video RAM On Board MS DirectX® 10.
Specifications Feature C Specification Card Reader Embedded 7-in-1 Card Reader (MS/ MS Pro/ SD/ Mini SD/ MMC/ RS MMC/ MS Duo) Note: MS Duo/ Mini SD/ RS MMC Cards Require a PC Adapter Audio High Definition Audio 3D Stereo Enhanced Sound System Sound-Blaster PRO™ Compatible Built-In Microphone 2 * Built-In Speakers S/PDIF Digital Output Keyboard & Pointing Device Full Size Winkey Keyboard with Numeric Keypad Built-In TouchPad (Scroll Functionality Included) ExpressCard Slot ExpressCard/34/54 Slot
Specifications Feature Communication Specification Built-In 56K Fax Modem Built-In 10/100/1000Mb Base-TX Ethernet LAN Intel® WiFi Link 5300 Series (3*3 - 802.11a/g/n) Wireless LAN Mini-Card Module (Option) Intel® WiFi Link 5100 Series (1*2 - 802.11a/g/n) Wireless LAN Mini-Card Module (Option) 3rd Party 802.11b/g Wireless LAN Mini-Card Module with USB interface (Option) Bluetooth 2.0 + EDR (Enhanced Data Rate) Module (Factory Option) 1.3M or 2.0M Pixel PC Camera Module with USB interface (Factory Option) 3.
Specifications Feature Specification Power Full Range AC/DC Adapter – AC in 100 - 240V, 50 - 60Hz DC Output 20V, 6A (120 Watts) Easy Changeable 8-Cell Smart Lithium-Ion 4400mAH Main Battery Environmental Spec Temperature Operating: Non-Operating: Physical Dimensions & Weight 364mm (w) * 269.5mm (d) * 29 ~ 41mm (h) Around 3.
Windows XP Information Appendix D: Windows XP Information This Appendix contains information (including control panel information, driver installation etc.) for users of the Windows XP OS.
Windows XP Information DVD Regional Codes Changing DVD Regional Codes Go to the Control Panel and double-click System > Hardware (tab), click Device Manager, then click the + next to DVD/CD-ROM drives. Double-click on the DVD-ROM device to bring up the Properties dialogue box, and select the DVD Region (tab) to bring up the control panel to allow you to adjust the regional code. DVD region detection is device dependent, not OS-dependent. You can select your module’s region code 5 times.
Windows XP Information Windows XP Start Menu & Control Panel Most of the control panels, utilities and programs within Windows XP (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop. You can customize the look of the Start menu by right-clicking the Start menu and selecting Properties from the menu.
Windows XP Information Sound Volume Adjustment How high the sound volume can be set depends on the setting of the volume control within Windows (and the volume control function keys on the computer). Click the Volume icon on the taskbar to check the setting. Figure D - 3 D Realtek Audio Configuration Menus D - 4 Audio Features Audio Features You can configure the audio options on your computer from the Sounds and Audio Devices Windows control panel.
Windows XP Information Function/Hot Key Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators (see the table below) are available when the hot key utility is installed (see “Hot Key” on page D - 26). After installing the driver an icon will appear in the taskbar.
Windows XP Information Video Features You can switch display devices, and configure display options, from the Display Properties control panel in Windows as long as the appropriate video driver is installed. To access Display Properties in Windows: 1. 2. 3. 4. 5. 6. Click Start, point to Settings and click Control Panel (or just click Control Panel). Double-click Display (icon) - In the Appearances and Themes category. Click Settings (tab) in the Display Properties dialog box.
Windows XP Information Display Properties & NVIDIA Control Panel 1 2 4 3 Figure D - 4 - Display Properties & NVIDIA Control Panel Video Card Options Note that card types, specifications and drivers are subject to continual updates and changes. Check with your service center for the latest details on video cards supported.
Windows XP Information Navigating the Control Panel NVIDIA Video Driver Controls Access the NVIDIA Control Panel as indicated on page D - 6. You may make changes to the video and display settings by clicking the appropriate menu item. Navigate through the control panels in much the same way as you would a web page. Click on the headings, menus and highlighted links for information. Use the buttons on the top left to go back, forward etc.
Windows XP Information Display Devices and Modes (NVIDIA) Note that you can use a DVI cable connected to the DVI-Out port, or an HDMI (High-Definition Multimedia Interface) cable connected to the HDMI-Out port to connect an external display (if you are using an older type of monitor you can use an adapter to convert the signal from DVI to VGA). See your display device manual to see which formats are supported.
Windows XP Information Attaching Other Displays 1. 2. 3. 4. 5. 6. D Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. Go to the NVIDIA Control Panel. Click Display, and then click Set up multiple displays. Choose the nView display mode you wish to use. Select the displays you want to use (if your display is not shown click “My Display is not shown in the list...” or use the Fn + F7 key combination), and choose which display is to be the primary display. Click Apply.
Windows XP Information To Enable Extended Desktop (Windows Display Properties) 1. 2. 3. 4. 5. Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. Click Start, point to Settings (or click Control Panel) and click Control Panel (if you are in Category View choose Appearance and Themes). Double-click Display (icon). In the Display Properties dialog box, click Settings (tab). Click the monitor icon (e.g.
Windows XP Information HDMI Audio Configuration As HDMI (High-Definition Multimedia Interface) carries both audio and video signals you will need to configure the audio output as per the instructions below. Windows Audio Setup for HDMI 1. Connect a device with HDMI support to the HDMI-Out port. 2. Go to the Start menu and point to Settings (or just click Control Panel) and click Control Panel, then double-click the Sounds & Audio Devices icon (Sounds, Speech, and Audio Devices in Category View). 3.
Windows XP Information HDMI Note • Connect a device with HDMI support to the HDMI-Out port BEFORE attempting to play audio/video sources through the device. • If you disconnect the HDMI cable the default audio playback device will not revert to speakers until the computer is restarted (if you do not wish to restart the computer then go to the Sound control panel and select Speakers as the default audio playback device). HDMI Video Configuration 1. 2. 3. 4.
Windows XP Information Power Management Features The Power Options control panel icon in Windows (see page D - 3) allows you to configure power management features for your computer. You may conserve power through individual components such as the monitor or hard disk, or you may use either Stand by or Hibernate mode to conserve power throughout the system. Power Schemes You can set your computer to conserve power through individual components by means of Power Schemes.
Windows XP Information Each Windows Power Scheme will also adjust the processor performance of your machine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose the Home/Office Desk scheme for maximum performance when the computer is powered from an AC power source.
Windows XP Information Stand by Stand by saves the least amount of power, but takes the shortest time to return to full operation. During Stand by the hard disk is turned off, and the CPU is made to idle at its slowest speed. All open applications are retained in memory. When you are not using your computer for a certain length of time, which you specify in the operating system, it will enter Stand by mode to save power.
Windows XP Information Configuring the Power Button The power button may be set to send the computer in to either Stand by or Hibernate mode. In Stand by mode, the LED will blink green. In Hibernate mode the LED will be off (battery). If you are in a power saving mode set to save power through individual components (e.g. hard disk, monitor), the LED will remain green. Sleep Button You may also configure the Sleep/Resume key combination (Fn + F4). In Windows this is referred to as the Sleep button.
Windows XP Information Battery Information Please follow these simple guidelines to get the best use out of your battery. New Battery Always completely discharge, then fully charge, a new battery (see “Battery FAQ” on page D - 21). Battery Life Your computer’s battery life is dependent upon many factors, including the programs you are running, and peripheral devices attached.
Windows XP Information Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to remove the battery for any reason see “Removing the Battery” on page 6 - 3.
Windows XP Information Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode • DO NOT connect the metal terminals (+, -) to each other Damaged Battery Warning Should you notice any physical defects (e.g. the battery is bent out of shape after being dropped), or any unusual smells emanating from the notebook battery, shut your computer down immediately and contact your service center.
Windows XP Information Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer by yourself even when you see a message that indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Windows XP Information Driver Installation Insert the Device Drivers & Utilities + User’s Manual disc and click Install Drivers (button), or Optional (button) to access the Optional driver menu. 1. 2. If you wish to install the drivers manually see page “Manual Driver Installation” on page D - 23. 3. D Check the driver installation order from Table D - 4, on page D - 23 (the drivers must be installed in this order) which is the same as that listed in the Drivers Installer menu below.
Windows XP Information WinXP SP2 Driver Page # Chipset D - 25 Manual Driver Installation Audio D - 25 Video D - 25 Modem D - 25 Click the Browse CD button in the Drivers Installer application and browse to the executable file in the appropriate driver folder. LAN D - 25 TouchPad D - 26 Card Reader/ExpressCard D - 26 Hot Key D - 26 Intel MEI Driver D - 26 Wireless LAN Module D - 32 802.11b/g WLAN Driver Installation D - 35 3.
Windows XP Information Updating/Reinstalling Individual Drivers If you wish to update/reinstall individual drivers it may be necessary to uninstall the original driver.To do this go to the Control Panel in the Windows OS and double-click the Add/Remove Programs item. If you see the individual driver listed (if not see below), uninstall it, following the on screen prompts (it may be necessary to restart the computer).
Windows XP Information Chipset 1. Click 1.Install Chipset Driver > Yes. 2. Click Next > Yes > Next > Next. 3. Click Finish to restart the computer. Audio 1. Click 2. Install Audio Driver > Yes. 2. Click Next (click Cancel if a Found New Hardware Wizard appears). 3. Click Finish to restart the computer. Video 1. Click 3.Install Video Driver > Yes. 2. Click Next. 3. Click “Yes, I want to restart my computer now” (button). 4. Click Finish to rest9art the computer. Modem 1. Click 4.Install Modem Driver > Yes.
Windows XP Information TouchPad 1. Click 6.Install Touchpad Driver > Yes. 2. Click Next > Next > Next. 3. Click Finish to restart the computer. Card Reader/ExpressCard 1. Click 7.Install Cardreader Driver > Yes. 2. Click Next > Install. 3. Click Finish. Hot Key 1. Click 8.Install HotKey Utility > Yes. 2. Click Next > Install. 3. Click Finish > Finish to restart the computer. Intel MEI Driver 1. Click 9.Install Intel MEI Driver > Yes. 2. Click Next > Yes > Next. 3.
Windows XP Information Bluetooth Module The operating system’s Bluetooth Devices control panel is used to configure the Bluetooth settings in Windows XP, and therefore does not require a driver. Use the Fn + F12 key combination (see “Function/Hot Key Indicators” on page D - 5) to toggle power to the Bluetooth module. Bluetooth Data Transfer Note that the transfer of data between the computer and a Bluetooth enabled device is supported in one direction only (simultaneous data transfer is not supported).
Windows XP Information Wireless Device Operation Aboard Aircraft The use of any portable electronic transmission devices aboard aircraft is usually prohibited. Make sure the module(s) are OFF if you are using the computer aboard aircraft. Bluetooth Local Area Connection Icon If you want to display the Local Area Connection icon for the Bluetooth connection in the taskbar, set it up as follows: 1.
Windows XP Information Bluetooth Configuration in Windows XP Setup your Bluetooth Device so the Computer Can Find it 1. 2. Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Make the device discoverable (to do this check your device documentation). Bluetooth Taskbar Icon To Turn the Bluetooth Module On 1. 2. 3. Press the Fn + F12 key combination to power on the Bluetooth module. A Bluetooth icon will appear in the taskbar (see sidebar).
Windows XP Information To Add a Bluetooth Device Figure D - 17 1. Access the Bluetooth Devices control panel. 2. Click Options (tab), and make sure that Allow Bluetooth devices to connect to this computer check box (Connections) has a tick inside it. 3. Click Devices (tab), and then click Add. 4. The Add Bluetooth Device Wizard will appear. 5. Click to select “My device is set up and ready to be found”, and then click Next.
Windows XP Information To Change Settings for the Bluetooth Device 1. 2. • • Access the Bluetooth Devices control panel. Click on the device you want to change and click Properties to: Change the name of the device (click General, type a new name and click OK). Enable/Disable a service (click Services, clear/tick the check box next to the service and click OK). To Make your Computer Discoverable to Bluetooth Devices 1. 2. 3. Access the Bluetooth Devices control panel.
Windows XP Information Wireless Device Operation Aboard Aircraft The use of any portable electronic transmission devices aboard aircraft is usually prohibited. Make sure the module(s) are OFF if you are using the computer aboard aircraft. Wireless LAN Module If you have included an Intel® Wi-Fi Link 5100/5300 Series (802.11 a/g/n) WLAN module, or 3rd Party 802.11b/g WLAN module in your purchase option, make sure that the Wireless LAN module is on before installing the driver.
Windows XP Information Intel WLAN Driver Installation 1. Make sure the module is powered on, then insert the Device Drivers & Utilities + User’s Manual disc into the CD/DVD drive. 2. Make sure the computer has a working internet connection. 3. Option Drivers (button). 4. Click 1.Install Wireless Lan Driver > Yes. 5. Click Next > Next to link to the required prerequisites on the internet. 6. Click Download (button) to download the Windows Installer executable (.exe) file to the computer’s hard disk. 7.
Windows XP Information 15. Configure the settings by going to the Intel PROSet Wireless WiFi Connection Utility (Start > Programs/All Programs > Intel PROSet Wireless WiFi Connection Utility), or by double-clicking the taskbar icon . 16. Click to select any available network, and click Connect to establish a connection. 17. If you do not see your Wireless Access Point click Refresh (button). 18. Click Help (link) to bring up the Help Menu. 19. Make sure that the WiFi On button is selected.
Windows XP Information 802.11b/g WLAN Driver Installation 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual disc into the CD/DVD drive. 2. Click Option Drivers (button). 3. Click 1.Install WLAN Driver > Yes. 4. Choose the language you prefer and click Next. 5. Click Next > Install. 6. Click Finish to restart the computer. 7. The operating system is the default setting for Wireless LAN control in Windows XP. 8.
Windows XP Information Taking Still Pictures Double-click the My Computer icon on the desktop, or go the Start menu and point to My Computer, then click it. Double-click the camera icon. Click Take a new picture in the Camera Tasks box. . PC Camera Module Before installing the optional PC Camera module driver use the Fn + F10 key combination to toggle power to the module. The PC Camera module uses the BisonCap application to capture video files.
Windows XP Information PC Camera Driver Installation 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual disc into the CD/DVD drive. 2. Click Option Drivers (button). 3. Click 2.Install WebCam Driver > Yes. 4. Choose the language you prefer and click Next > Next. 5. Click Finish to restart the computer. 6.
Windows XP Information PC Camera Audio Setup (all camera modules) If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. 1. Go to the Start menu and point to Settings (or just click Control Panel) and click Control Panel, then doubleclick the Sounds & Audio Devices icon (Sounds, Speech, and Audio Devices in Category View). 2. Click Advanced in the Volume > Device volume tab. 3. Click Options and scroll down and click Properties. 4.
Windows XP Information BisonCap BisonCap is a video viewer for general purpose video viewing and testing, and for capturing video files to .avi format. 1. 2. 3. Run the BisonCap application from the Start > Programs/All Programs > BisonCam menu (it is recommended that you set the capture file before the capture process - see Set Capture File below). Go to the Capture menu heading (if you wish to capture audio check “PC Camera Audio Setup (all camera modules)” on page D - 38) and select Start Capture.
Windows XP Information Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties) If necessary you can remove the recorded video file to a removable medium e.g. CD, DVD or USB Flash drive.
Windows XP Information Eliminating Screen Flicker If you find that the video screen in the BisonCap program is flickering, you can try to adjust the setting in the Video Capture Filter options. 1. 2. 3. Run the BisonCap program. Go to Options and scroll down to select Video Capture Filter.... Click either 50Hz or 60Hz under Frequency in Property Page (tab).
Windows XP Information Zoom The BisonCap program allows you to zoom the camera in and out. 1. Run the BisonCap program. 2. Go to Zoom and select Zoom Out/Zoom In. Figure D - 23 Zoom/Setting Snapshot Folder The Snapshot folder’s default location is on the desktop. Do not move this folder or an error may appear when you try to take a still picture. D Taking Still Pictures The BisonCap programs allows you to take still pictures. 1. Run the BisonCap program. 2. Go to Options and select Take Picture. 3.
Windows XP Information 3.5G Module If you have included an optional 3.5G module in your purchase option follow the instructions on page 7 - 19 to install the USIM card (which will be provided by your service provider), and then install the application. Before installing the application, make sure that the 3.5G module is on. Use the Fn + key combination (see “Function/Hot Key Indicators” on page D - 5) to toggle power to the 3.5G module. 3G Watcher Application Installation 1.
Windows XP Information Help & Manual If you have included the fingerprint reader in your purchase option you will need to install the driver as per the instructions below. Right-click the taskbar icon to bring up the menu to select Help. Make sure you have administrator’s rights to your computer, and have a Windows password enabled for full security protection. Insert the Device Drivers & Utilities + User’s Manual disc and click Option Drivers (button). Click Unlock (button) and then click 4.
Windows XP Information User Enrollment (Application Version 1) 1. 2. 3. 4. 5. 6. 7. 8. 9. Click Start > Programs/All Programs > Protector Suite QL > User Enrollment, or double click the taskbar icon . On the first run of the program you will be asked to click the button to accept the license, and then click OK. Click Next and select “Enrollment to the hard disk”, and click Finish.
Windows XP Information 10. 11. 12. 13. Click Finish. Click any of the headings under “Learn more about:” to get more information on any topic. Click Close. Right-click the taskbar icon to bring up the menu that allows you to Edit Fingerprints, start Control Center, access the Help menu etc. You can also run the Control Center etc. from the Protector Suite QL item in the Programs/All Programs menu. 14. See “Help & Manual” on page D - 44 for further details. 15.
Windows XP Information User Enrollment (Application Version 2) 1. Click Start > Programs/All Programs > Protector Suite QL > User Enrollment, or double-click the taskbar icon . 2. Click Initialize. 3. On the first run of the program you will be asked to click the button to accept the license, and then click OK. 4. Click Next and select “Enrollment to the hard disk”, and click Finish. 5.
Windows XP Information 11. 12. 13. 14. 15. Swipe the finger five times to enroll that finger. Repeat the process for all the fingers you wish to enroll (see sidebar), and then click Next > Finish. Click “Help” in the Fingerprint Control Center to get more information on any topic. You can also run the Tutorial, or Introduction (to run the product tour video) to get more information.
Windows XP Information Fingerprint Control Center Features (Application Version 2) Application Launcher The Application Launcher allows you to register applications to be launched when assigned to a particular finger. Simply copy the application icon on to one of the registered fingers and ten click OK to close the application window. Once registered the application will launch when you swipe the appropriate finger across the sensor.
Windows XP Information D D - 50
