Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
Preface R&TTE Directive This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Directive 1999/5/EC. This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Luxembourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland, United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slovenia.
Preface CE Marking This device has been tested to and conforms to the regulatory requirements of the European Union and has attained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies to products regulated by certain European health, safety and environmental protection legislation. The CE Mark is obligatory for products it applies to: the manufacturer affixes the marking in order to be allowed to sell his product in the European market.
Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Preface FCC RF Radiation Exposure Statement: 1. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. Warning Use only shielded cables to connect I/O devices to this equipment.
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: 1. 2. 3. 4. 5. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool. Avoid using this equipment with a telephone line (other than a cordless type) during an electrical storm.
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: 1. Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer to any shock or vibration. 2. Do not place it on an unstable surface. Do not place anything heavy on the computer. Keep it dry, and don’t overheat it.
Preface 3. Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. 4. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work. Remember to periodically save your data as data may be lost if the battery is depleted. Do not turn off the power until you properly shut down all programs. 5.
Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a steady, uninterrupted power supply. If you are unsure of your local power specifications, consult your service representative or local power company. • The power adapter may have either a 2-prong or a 3-prong grounded plug.
Preface Polymer Battery Precautions Note the following information which is specific to polymer batteries only, and where applicable, this overrides the general battery precaution information overleaf. • Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mechanism and is not a cause for concern. • Use proper handling procedures when using polymer batteries.
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the power supply.
Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: 1. 2. 3. 4. 5. 6. 7. 8. Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched. Disconnect the AC/DC adapter and cables. Stow them in the carrying bag. The AC/DC adapter uses voltages from 100 to 240 volts so you won’t need a second voltage adapter.
Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common. Don’t check it with normal luggage. Baggage handlers may not be sufficiently careful. Avoid knocking the computer against hard objects.
Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints. The following are some tips to reduce the strain: • Adjust the height of the chair and/or desk so that the keyboard is at or slightly below the level of your elbow. Keep your forearms, wrists, and hands in a relaxed position.
Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • • • • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. Position the display directly in front of you at a comfortable viewing distance. Adjust the display-viewing angle to find the best position.
Preface Contents Notice .................................................................................I EuP-Standby and Off Mode Power Consumption Statement: .........................................................................II FCC Statement ................................................................ IV FCC RF Radiation Exposure Statement: ......................... V Instructions for Care and Operation ..............................VII Power Safety ............................................
Preface Optical (CD/DVD) Device ............................................2-3 Loading Discs ................................................................2-3 Handling CDs or DVDs .................................................2-4 DVD Regional Codes ....................................................2-5 Multi-In-1 Card Reader .................................................2-6 Touchpad and Buttons/Mouse .......................................2-7 Gestures and Device Settings ..........................
Preface Audio .............................................................................4-6 Windows Experience Index ...........................................4-7 Optional Drivers ............................................................4-8 PC Camera Module ........................................................4-8 Wireless LAN Module ...................................................4-8 3.75G/HSPA Module .....................................................
Preface Creating a Profile .........................................................7-37 Choosing a Profile .......................................................7-40 Editing a Profile ...........................................................7-41 Text Messaging Service (SMS) ...................................7-42 Setting ..........................................................................7-45 Statistics & Information ...............................................7-51 Wireless Manager ............
Preface Audio ............................................................................ C-3 Keyboard & Pointing Device ........................................ C-3 Interface ........................................................................ C-3 Slots .............................................................................. C-3 Card Reader .................................................................. C-3 Communication .............................................................
Preface XXII
Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: • Chapter 2 A guide to using some of the main features of the computer e.g. the storage devices (hard disk, optical device, Multi-in-1 card reader), TouchPad & Mouse, Audio & Printer. • Chapter 3 The computer’s power saving options.
1 Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - 1, “BIOS Utilities” on page 5 - 1 and “Upgrading The Computer” on page 6 - 1 in the reminder of the User’s Manual. You may also find the notes marked with a of interest to you.
Quick Start Guide Not Included Operating Systems (e.g. Windows 7) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals. Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the drivers listed in “Drivers & Utilities” on page 4 - 1. Drivers are programs which act as an interface between the computer and a hardware component e.g.
1 Quick Start Guide System Startup 1. 2. 3. 4. 5. Remove all packing materials. Place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC/DC adapter to the DC-In jack on the left of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.
Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find that this manual refers to the Windows 7 operating system with Service Pack 1 installed.
1 Quick Start Guide Model Differences This notebook series includes three different models that vary slightly in design style, color and general appearance (Model A has three distinct design styles as pictured on the following pages). Note that though your computer may look slightly different from that pictured throughout this manual, all ports, jacks and general functions are the same for all the design styles (see “Specifications” on page C - 1 for further details of any differences between the models).
Quick Start Guide System Map: LCD Panel Open - Model A Design I 1 Wireless Device Operation Aboard Aircraft 2 The use of any portable electronic transmission devices aboard aircraft is usually prohibited. Make sure the module(s) are OFF if you are using the computer aboard aircraft. 4 5 6 7 Figure 1 - 2 LCD Panel Open Model A Design I 3 Use the key combinations to toggle power to the 3.
1 Quick Start Guide Figure 1 - 3 LCD Panel Open Model A Design II 1. 2. 3. 4. 5. 6. 7. System Map: LCD Panel Open - Model A Design II 1 Wireless Device Operation Aboard Aircraft Built-in PC Camera (Optional) LCD Power Button LED Status Indicators Keyboard Built-In Microphone Touchpad & Buttons The use of any portable electronic transmission devices aboard aircraft is usually prohibited. Make sure the module(s) are OFF if you are using the computer aboard aircraft.
Quick Start Guide System Map: LCD Panel Open - Model A Design III 1 Wireless Device Operation Aboard Aircraft 2 The use of any portable electronic transmission devices aboard aircraft is usually prohibited. Make sure the module(s) are OFF if you are using the computer aboard aircraft. 4 5 6 Figure 1 - 4 LCD Panel Open Model A Design III 3 Use the key combinations to toggle power to the 3.
1 Quick Start Guide Figure 1 - 5 LCD Panel Open Model B 1. 2. 3. 4. 5. 6. 7. System Map: LCD Panel Open - Model B 1 Built-in PC Camera (Optional) LCD Power Button LED Status Indicators Keyboard Built-In Microphone Touchpad & Buttons Wireless Device Operation Aboard Aircraft 2 The use of any portable electronic transmission devices aboard aircraft is usually prohibited. Make sure the module(s) are OFF if you are using the computer aboard aircraft.
Quick Start Guide System Map: LCD Panel Open - Model C 1 Wireless Device Operation Aboard Aircraft 2 The use of any portable electronic transmission devices aboard aircraft is usually prohibited. Make sure the module(s) are OFF if you are using the computer aboard aircraft. 4 3 5 Figure 1 - 6 LCD Panel Open Model C Use the key combinations to toggle power to the 3.
1 Quick Start Guide LED Indicators Icon Color Description The LED indicators on the computer display helpful information about the current status of the computer.
Quick Start Guide Hot Key Buttons - Model A Design I Only These buttons give instant access to the default Internet browser and e-mail program, and allow you to toggle the Silent Mode on/off with one quick button press. Hot Key Function 3 2 1 1 Toggle *Silent Mode (for power saving) 2 Activate the Default Internet Program 3 Activate the Default E-Mail Browser (Note that in Windows 7 without Outlook/Outlook Express installed this button has no function.
1 Quick Start Guide Hot Key Buttons - Model A Design III Only These buttons give instant access to the default Internet browser and e-mail program, and allow you to toggle the WLAN module on/off with one quick button press. Hot Key Function 3 2 1 1 Toggle WLAN Module On/Off 2 Activate the Default Internet Program 3 Activate the Default E-Mail Browser (Note that in Windows 7 without Outlook/Outlook Express installed this button has no function.
Quick Start Guide Keyboard - Model A Designs I & II The keyboard has an embedded numerical keypad for easy numeric data input, and features function keys to allow you to change operational features instantly. See Table 1 - 6, on page 1 - 18 for full function key combination details. Function Keys NumLk & ScrLk Keys Play/Pause Key Numerical Keypad 3.
1 Quick Start Guide Other Keyboards If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard. The system will detect and enable it automatically. However special functions/hot-keys unique to the system’s regular keyboard may not work. NumLk & ScrLk Keyboard - Model A Design III The keyboard has an embedded numerical keypad for easy numeric data input, and features function keys to allow you to change operational features instantly.
Quick Start Guide Keyboard - Models B & C The keyboard has an embedded numerical keypad for easy numeric data input, and features function keys to allow you to change operational features instantly. See Table 1 - 6, on page 1 - 18 for full function key combination details. Function Keys NumLk & ScrLk Keys Play/Pause Key 3.75G/HSPA Module Power Toggle Key (Model B only) Numerical Keypad Other Keyboards If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard.
1 Quick Start Guide Function/Hot Key Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators are available when the hot key utility is installed. Keys Function Keys Function Fn + ~ Play/Pause (in Audio/Video Programs) Fn + F7 Display Toggle Fn + Fn + F1 Fn + F2 Fn + F3 3.
Quick Start Guide System Map: Front & Left Views Figure 1 - 10 Front & Left Views Model A 1. 1 Models B & C 1 2. 3. Model A 2 3 5 4 6 6 8 7 Models B & C 2 3 4 5 6 7 6 4. 5. 6. 7. 8. 8 LED Power Indicators (see Table 1 - 2, on page 1 - 12) DC-In Jack External Monitor Port RJ-45 LAN Jack HDMI-Out Port USB 2.
1 Quick Start Guide Figure 1 - 11 Right & Rear Views 1. 2. 3. 4. 5. 6. Microphone-In Jack Headphone-Out Jack USB 2.0 Port Optical Device Drive Bay (for CD/ DVD Device) Security Lock Slot Battery System Map: Right & Rear Views Model A 3 2 4 5 Model B 1 1 2 3 Model C 1 2 Battery Information Always completely discharge, then fully charge, a new battery before using it. Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
Quick Start Guide Disk Eject Warning Changing DVD Regional Codes Don’t try to eject a CD/DVD while the system is accessing it. This may cause the system to “crash”. Stop the disk first then eject it, or press the stop button twice. Go to the Control Panel and double-click Device Manager (Hardware and Sound), then click the + next to DVD/CD-ROM drives.
1 Quick Start Guide Figure 1 - 12 Bottom View Model A 1. 2. 3. 4. 5. System Map: Bottom View - Model A 1 Battery Component Bay Cover Vent/Fan Intake/ Outlet Hard Disk Bay Cover 3.75G USIM Card Cover (Optional) 3 3 2 3 4 5 CPU The CPU is not a user serviceable part. Overheating To prevent your computer from overheating make sure nothing blocks the Vent/Fan Intake while the computer is in use. Bottom Covers If your model includes the 3.
Quick Start Guide System Map: Bottom View - Model B Figure 1 - 13 Bottom View Model B 1 1. 2. 3 3. 3 2 4. 3 5 5. 6. 3 4 Battery Component Bay Cover Vent/Fan Intake/ Outlet Hard Disk Bay Cover 3.75G USIM Card Cover (Optional) Speakers CPU 6 6 The CPU is not a user serviceable part. Overheating Bottom Covers To prevent your computer from overheating make sure nothing blocks the Vent/Fan Intake while the computer is in use. If your model includes the 3.
1 Quick Start Guide Figure 1 - 14 Bottom View Model C 1. 2. 3. 4. 5. System Map: Bottom View - Model C 1 Battery Component Bay Cover Fan Intake/Vent Hard Disk Bay Cover Speakers 3 3 2 3 3 4 3 Battery Information Always completely discharge, then fully charge, a new battery before using it. Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges. 5 5 CPU The CPU is not a user serviceable part.
Quick Start Guide Windows 7 Start Menu & Control Panel Most of the control panels, utilities and programs within Windows 7 (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop. Right-click the Start menu icon , and then select Properties if you want to customize the appearance of the Start menu.
1 Quick Start Guide Video Features You can switch display devices, and configure display options, from the Display control panel (in Appearances and Personalization) in Windows 7. For more detailed video information see “AMD Video Driver Controls” on page B - 1. To access Display (Control Panel) and Screen Resolution in Windows: 1. 2. 3. 4. 5. 6. Click Start and click Control Panel. Click Display (icon) - In the Appearances and Personalization category. Click Adjust Screen Resolution/Adjust resolution.
Quick Start Guide To access the AMD Vision Engine/CatalystTM Control Center (See Appendix B for detailed information): 1. 2. 3. Right-click the desktop and select AMD VISION Engine Control Center/Catalyst Control Center 3 . OR 4 in the Windows taskbar notification area (or right-click the icon and select AMD Double-click the icon VISION Engine Control Center/Catalyst Control Center).
1 Quick Start Guide 4. 5. Click the Preferences button and select either Advanced View or Standard View. The menu headings allow you to select which items you wish to change.
Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 1 - 23) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu. Note that the Power saver plan may have an affect on computer performance.
1 Quick Start Guide 1 - 30
Features & Components Chapter 2: Features & Components 2 Overview Read this chapter to learn more about the following main features and components of the computer: • • • • • • Hard Disk Drive Optical (CD/DVD) Device Multi-In-1 Card Reader Touchpad and Buttons/Mouse Audio Features Adding a Printer Overview 2 - 1
Features & Components 2 Power Safety Before attempting to access any of the internal components of your computer please ensure that the machine is not connected to the AC power, and that the machine is turned off. Also ensure that all peripheral cables, including phone lines, are disconnected from the computer. Hard Disk Drive The hard disk drive is used to store your data in the computer.
Features & Components Optical (CD/DVD) Device There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual device will depend on the module you purchased (see “Storage” on page C - 3). The optical device is usually labeled “Drive D:” and may be used as a boot device if properly set in the BIOS (see “Boot Menu” on page 5 - 12).
Features & Components 2 Handling CDs or DVDs CD Emergency Eject If you need to manually eject a CD (e.g. due to an unexpected power interruption) you may push the end of a straightened paper clip into the emergency eject hole. However please do NOT use a sharpened pencil or similar object that may break and become lodged in the hole. Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be accessed.
Features & Components DVD Regional Codes 2 To change the DVD regional codes: 1. 2. 3. 4. Go to the Control Panel Double-click Device Manager (Hardware and Sound), then click the + next to DVD/CD-ROM drives. Double-click on the DVD-ROM device to bring up the Properties dialog box, and select the DVD Region (tab) to bring up the control panel to allow you to adjust the regional code. DVD region detection is device dependent, not OS-dependent. You can select your module’s region code 5 times.
Features & Components 2 Card Reader Cover Make sure you keep the rubber cover provided in the card reader when not in use. This will help prevent foreign objects and/or dust getting in to the card reader. Multi-In-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).
Features & Components Touchpad and Buttons/Mouse The Touchpad is an alternative to the mouse; however, you can also add a mouse to your computer through one of the USB ports. The Touchpad buttons function in much the same way as a two-button mouse. Once you have installed the Touchpad driver (see “TouchPad” on page 4 - 6) you can configure the functions by double-clicking the Touchpad driver icon in the notification area.
Features & Components 2 Show Video You can get a clearer view of the gestures involved by clicking the Show Video option for each gesture item. Select the gesture (Pinch Zoom, Rotating, Three Fingers Down and Three Finger Flick) in the Device Settings > Settings left tree menu and click the Show Video button to see the demonstration video.
Features & Components Scrolling The Two-Finger scrolling feature works in most scrollable windows and allows you to scroll horizontally and vertically. Place two fingers, slightly separated, on the Touchpad surface and slide both fingers in the direction required (in a straight continuous motion).
Features & Components Rotating Use the Pivot Rotate gesture to rotate objects (e.g. photos) in 90 degree increments. Place a finger down on the left “target” zone and keep it stationary. Place another finger near the middle of the Touchpad and slide it in a circular motion around the stationary finger (clockwise or counterclockwise) to rotate the object.
Features & Components Audio Features You can configure the audio options on your computer from the Sound control panel in Windows, or from the Realtek HD Audio Manager icon in the notification area/control panel (right-click the notification area icon to bring up an audio menu). The volume may also be adjusted by means of the Fn + F5/F6 key combination (see Table 1 - 6, on page 1 - 18).
Features & Components Setup for Audio Recording 2 To record audio sources on your computer at optimum quality follow the instructions below: 1. 2. 3. 4. Figure 2 - 12 Realtek Audio Manager Recording Setup 2 - 12 Audio Features Click Start, and click Control Panel (or point to Settings and click Control Panel) and make sure you are in Classic View. Click Realtek HD Audio Manager (or right-click the notification area icon and select Sound Manager).
Features & Components Adding a Printer The most commonly used peripheral is a printer. The following conventions will help you to add a printer; however it is always best to refer to the printer manual for specific instructions and configuration options. USB Printer Most current printers have a USB interface connection. You may use any one of the ports to connect the printer. Install Instructions: 1. 2. 3. 4. 5.
Features & Components 2 2 - 14
Power Management Chapter 3: Power Management Overview To conserve power, especially when using the battery, your computer power management conserves power by controlling individual components of the computer (the monitor and hard disk drive) or the whole system.
Power Management 3 Silent Mode (Model A Design I Only) Use the key to toggle Silent Mode to reduce fan noise and save power consumption. Note this may reduce computer performance. The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components. 1. 2. 3. 4. Attach the AC/DC adapter to the DC-in jack on the left of the computer.
Power Management Turning On the Computer Now you are ready to begin using your computer. To turn it on simply press the power button on the front panel. When the computer is on, you can use the power button as a Stand by/Hibernate/ Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and holding the power button for longer than this will shut the computer down). Use Power Options in the Windows control panel to configure this feature.
Power Management 3 Resuming Operation See Table 3 - 1, on page 3 - 9 for information on how to resume from a power-saving state. Password It is recommended that you enable a password on system resume in order to protect your data. Figure 3 - 1 Power Plan Advanced Settings 3 - 4 Power Plans Power Plans The computer can be configured to conserve power by means of power plans. You can use (or modify) an existing power plan, or create a new one.
Power Management Each Windows power plan will also adjust the processor performance of your machine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). 3 Choose High performance (you may need to click Show additional plans to view the High performance plan) for maximum performance when the computer is powered from an AC power source.
Power Management Power-Saving States 3 You can use power-saving states to stop the computer’s operation and restart where you left off. Win 7 uses the Sleep, Hibernate and Shut Down power-saving states. Sleep In Sleep all of your work, settings and preferences are saved to memory before the system sleeps. When you are not using your computer for a certain length of time, which you specify in the operating system, it will enter Sleep to save power.
Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost. Hibernate will also return you to where you last left off within seconds.
Power Management 3 Password Protection Configuring the Power Buttons The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the computer in to a power-saving state. Click Choose what the power buttons do on the left menu in Power Options to bring up the menu. It is recommended that you enable a password on wake up in order to protect your data.
Power Management Resuming Operation You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo). Power Status Icon To Resume Color Power Off Off Press the Power Button Sleep Blinking Green Press the Power Button Closing the Lid If you have chosen to send the computer to Sleep when the lid is closed, raising the lid will wake the system up.
Power Management 3 Notification Area Icon If the notification area icon does not appear then click the notification area arrow and select Customize. Energy Star Power Saving This system supports Energy Star power management features that place computers (CPU, hard drive, etc.) into a low-power sleep modes after a designated period of inactivity. If you want to enable Energy Star power saving then follow these instructions: 1. 2. 3. Right-click the notification area icon (see sidebar).
Power Management Battery Information Follow these simple guidelines to get the best use out of your battery. Low Battery Warning Battery Power Your computer’s battery power is dependent upon many factors, including the programs you are running, and peripheral devices attached. You can set actions to be taken (e.g. Shut down, Hibernate etc.), and set critical and low battery levels from power plan Change plan settings > Change advanced power settings (see Figure 3 - 2 on page 3 - 5).
Power Management 3 Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. Conserving Battery Power • Use a power plan that conserves power (e.g Power saver), however note that this may have an affect on computer performance. • Lower the brightness level of the LCD display.
Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to remove the battery for any reason see “Removing the Battery” on page 6 - 3. New Battery Always completely discharge, then fully charge, a new battery (see “Battery FAQ” on page 3 - 15 for instructions on how to do this).
Power Management Proper handling of the Battery Pack 3 Caution • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode • DO NOT connect the metal terminals (+, -) to each other Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Discard used battery according to the manufacturer’s instructions.
Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own. 1. 2. 3 Save and close all files and applications. Create a power plan for discharging the battery and set all the options to Never.
Power Management 3. Click Change plan settings (after creating it) and click Change plan settings > Change advanced power settings.
Power Management 4. 5. Scroll down to Battery and click + to expand the battery options.
Power Management 3 How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
Drivers & Utilities Chapter 4: Drivers & Utilities This chapter deals with installing the drivers and utilities essential to the operation or improvement of some of the computer’s subsystems. The system takes advantage of some newer hardware components for which the latest versions of most available operating systems haven’t built in drivers and utilities. Thus, some of the system components won’t be auto-configured with an appropriate driver or utility during operating system installation.
Drivers & Utilities Driver Installation Insert the Device Drivers & Utilities + User’s Manual disc and click Install Drivers (button), or Option Drivers (button) to access the Optional driver menu. 4 1. 2. 3. Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in this order) which is the same as that listed in the Drivers Installer menu below. Click to select the driver you wish to install, (you should note down the drivers as you install them).
Drivers & Utilities Driver Win 7 Driver Win 7 Video (VGA) Page 4 - 5 PC Camera Module Page 7 - 2 LAN Page 4 - 6 Wireless LAN Module Page 7 - 10 CardReader Page 4 - 6 Bluetooth & Wireless LAN Combo Module Page 7 - 16 TouchPad Page 4 - 6 3.75G/HSPA Module Page 7 - 29 Hot Key Page 4 - 6 Audio Page 4 - 6 Note that you need to install both the WLAN & Bluetooth drivers for the WLAN & Bluetooth Combo module.
Drivers & Utilities 4 Updating/Reinstalling Individual Drivers User Account Control If you wish to update/reinstall individual drivers it may be necessary to uninstall the original driver.To do this go to the Control Panel in the Windows OS and double-click the Programs and Features icon (Programs > Uninstall a program). Click to select the driver (if it is not listed see below) and click Uninstall, and then follow the on screen prompts (it may be necessary to restart the computer).
Drivers & Utilities New Hardware Found Driver Installation Procedure If you see the message “New Hardware Found” during the installation procedure (other than when outlined in the driver install procedure), click Cancel to close the window, and follow the installation procedure. Insert the Device Drivers & Utilities + User’s Manual disc and click Install Drivers (button).
Drivers & Utilities LAN 1. Click 2.Install LAN Driver > Yes. 2. Click Install > Finish. 4 CardReader 1. Click 3.Install Cardreader Driver > Yes. 2. Click Install > Finish. TouchPad 1. Click 4.Install Touchpad Driver > Yes. 2. Click Next. 3. Click the button to accept the license agreement and click Next. 4. Click Finish > Restart Now to restart the computer. Hot Key 1. Click 5.Install Hotkey AP > Yes. 2. Click Next > Next. 3. Click Finish > Finish to restart the computer.
Drivers & Utilities Windows Experience Index Windows Update After installing all the drivers make sure you enable Windows Update in order to get all the latest security updates etc. (all updates will include the latest hotfixes from Microsoft). To enable Windows Update make sure you are connected to the internet: 1. 2. 3. 4. 5. 6. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Windows Update (System and Security/ Security). Click Check for updates (button).
Drivers & Utilities Optional Drivers PC Camera Module See the pages indicated for the driver installation procedures for any modules included in your purchase option. See the introduction in “PC Camera Module” on page 7 - 2, and check the installation procedure. Wireless LAN Module 4 See the introduction in “Wireless LAN Module” on page 7 - 10, and check the installation procedure. Bluetooth & WLAN Combo Module See “Bluetooth & Wireless LAN Combo Module” on page 7 - 16. 3.
BIOS Utilities Chapter 5: BIOS Utilities Overview This chapter gives a brief introduction to the computer’s built-in software: If your computer has never been set up, or you are making important changes to the system (e.g. hard disk setup), then you should review this chapter first and note the original settings found in Setup. Even if you are a beginner, keep a record of the settings you find and any changes you make. This information could be useful if your system ever needs servicing.
BIOS Utilities BIOS Settings Warning 5 Incorrect settings can cause your system to malfunction. To correct mistakes, return to Setup and restore the Previous Values with , or Optimized Defaults with . The Setup Utility Each time you turn on the computer the system takes a few seconds to conduct a POST, including a quick test of the on-board RAM (memory). As the POST proceeds, the computer will tell you if there is anything wrong.
BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “nonfatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible. Non-Fatal Errors This kind of error still allows you to boot.
BIOS Utilities Setup Menus 5 The Setup menus shown in this section are for reference only. Your computer’s menus will indicate the configuration appropriate for your model and options. Setup Screens The following pages contain additional advice on portions of the Setup. Along the top of the screen is a menu bar with menu headings. When you select a heading, a new screen appears. Scroll through the features listed on each screen to make changes to Setup.
BIOS Utilities Main Menu Figure 5 - 2 Main Menu System Time & Date (Main Menu) The hour setting uses the 24-hour system (i.e., ØØ = midnight; 13 = 1 pm). If you can change the date and time settings in your operating system, you will also change these settings. Some applications may also alter data files to reflect these changes.
BIOS Utilities SATA Port # (Main Menu) Pressing Enter opens the sub-menu to show the configuration of a optical Device/ HDD on the computer’s SATA Ports. System/Extended Memory: (Main Menu) This item contains information on the system memory, and is not user configurable. The system will auto detect the amount of memory installed. 5 MB Series / BIOS Revision / KBC/EC firmware Revision This item contains information on the BIOS version etc., and is not user configurable.
BIOS Utilities Advanced Menu Figure 5 - 3 Advanced Menu 5 Advanced Chipset Control (Advanced Menu) The sub-menu here allows you to adjust the Bluetooth Power Setting.
BIOS Utilities SATA Mode Selection 5 If you have installed the Windows 7 operating system with either IDE or AHCI mode enabled, DO NOT disable the set mode (if you wish to disable the set mode you will need to reinstall the Windows 7 OS). Bluetooth Power Setting (Advanced Menu > Advanced Chipset Control) You can adjust the Bluetooth module power setting to your preference. The default setting (Disabled) will see the Bluetooth module powered off when the system is started up or restarted.
BIOS Utilities Boot Logo (Advanced Menu) Use this menu item to enable/disable the Boot Logo screen at system startup. If you disable the Boot Logo you will not see the F2 Enter Setup or F7 Boot Options prompts on the screen, however you can still press these keys, while the boot sceen is displayed, to perform the Enter Setup or Boot Option functions. Power On Boot Beep (Advanced Menu) Use this menu item to enable/disable the beep as the computer starts up.
BIOS Utilities Security Menu Security Menu 5 The changes you make here affect the access to the Setup utility itself, and also access to your machine as it boots up after you turn it on. These settings do not affect your machine or network passwords which will be set in your software OS. Figure 5 - 4 Security Menu Set Supervisor Password (Security Menu) You can set a password for access to the Aptio Setup Utility. This will not affect access to the computer OS (only the Aptio Setup Utility).
BIOS Utilities Note: To clear existing passwords press Enter and type the existing password, then press Enter for the new password (without typing any password entry) and Enter again to confirm the password clearance. Password Warning If you set a boot password (Password on boot is “Enabled“), NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
BIOS Utilities Boot Menu Figure 5 - 5 Boot Menu 5 BIOS Screens Note that the BIOS screens pictured on these pages are intended for guidance in setting up your system’s BIOS. BIOS versions are subject to constant change and revision, therefore your computer’s actual screens may appear slightly different from those pictured on these pages. 5 - 12 Boot Menu When you turn the computer on it will look for an operating system (e.g.
BIOS Utilities Boot Sequence (Boot Menu) Use the arrow keys to move up and down the menu and use the F5 and F6 keys to move the device’s boot priority up and down the list (the selected device will be highlighted in white).
BIOS Utilities Exit Menu Figure 5 - 6 Exit Menu 5 Click Save Changes and Reset to save all changes made. Choosing to Discard Changes, or Exit Discarding Changes, will wipe out any changes you have made to the Setup. You can also choose to restore the original Setup defaults that will return the Setup to its original state, and erase any previous changes you have made in a previous session.
Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps outlined to make the desired upgrades. If you have any trouble or problems you can contact your service representative for further help.
Upgrading The Computer When Not to Upgrade Power Safety Warning 6 Before you undertake any upgrade procedures, make sure that you have turned off the power, and disconnected all peripherals and cables (including telephone lines). It is advisable to also remove your battery in order to prevent accidentally turning the machine on. These procedures involve opening the system’s case, adding and sometimes replacing parts.
Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons it is best to remove the battery. 1. 2. 3. 4. Turn the computer off, and turn it over. Slide the latch 1 in the direction of the arrow. Slide the latch 2 in the direction of the arrow, and hold it in place. Slide the battery out in the direction of the arrow 3 .
Upgrading The Computer HDD System Warning 6 New HDD’s are blank. Before you begin make sure: You have backed up any data you want to keep from your old HDD. You have all the discs required to install your operating system and programs. If you have access to the internet, download the latest application and hardware driver updates for the operating system you plan to install. Copy these to a removable medium. Upgrading the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.
Upgrading The Computer 1. 2. 3. Turn off the computer, and turn it over and remove the battery. Locate the hard disk bay cover and loosen screws 1 & 2 . Remove the hard disk bay cover 3 .
Upgrading The Computer Hard Disk Screws & Cover 6 4. 5. 6. 7. Grip the tab and slide the hard disk in the direction of arrow 4 . Lift the hard disk out of the bay 5 . Remove the screw(s) 6 - 9 and the adhesive cover 10 . Reverse the process to install a new hard disk drive (do not forget to replace all the screws and covers). The hard disks and covers pictured here may appear slightly different from your model design (these designs are subject to change and upgrade without notice).
Upgrading The Computer Upgrading the Optical (CD/DVD) Device The procedure for removing the optical device will depend upon your particular computer model: • See “Removing the Optical Device for Model A Computers” on page 6 - 8. • See “Removing the Optical Device for Model B & C Computers” on page 6 10.
Upgrading The Computer Fan Cable & Cover 6 Make sure you reconnect the fan cable 5 before screwing down the bay cover. Note the information on replacing the RAM & CPU bay cover in “Cover Pins” on page 6 - 14. Removing the Optical Device for Model A Computers 1. 2. 3. 4. Turn off the computer, and turn it over and remove the battery. Locate the component bay cover and remove screws 1 - 4 . Carefully (a fan and cable are attached to the under side of the cover) lift up the bay cover.
Upgrading The Computer 5. 6. Remove the screw at point 7 , and use a screwdriver to carefully push out the optical device at point 8 . Reverse the process to install the new device.
Upgrading The Computer Removing the Optical Device for Model B & C Computers 1. 2. 3. 4. Turn off the computer, and turn it over and remove the battery. Remove the hard disk (see page 6 - 4) Remove the screw at point 1 , and use a screwdriver to carefully push out the optical device at point 2 . Reverse the process to install the new device.
Upgrading The Computer Upgrading the System Memory (RAM) Model A & B computers have one memory socket, and Model C computers have two memory sockets, for 204 pin Small Outline Dual In-line (SO-DIMM) DDRIII (DDR3) type memory modules (see “Memory” on page C - 2 for details of supported module types). 1. 2. Turn off the computer, and turn it over and remove the battery. Locate the component bay cover and remove screws 1 - 4 .
Upgrading The Computer 3. 4. Carefully (a fan and cable are attached to the under side of the cover) lift up the bay cover (note that for Model C computers you need to raise the bottom cover up to an angle of LESS THAN 30°). Carefully disconnect the fan cable 5 , and remove the cover 6 .
Upgrading The Computer 5. Gently pull the two release latches on the sides of the memory socket in the direction indicated by the arrows ( 7 & 8 ) in Figure 6 - 8. Figure 6 - 9 RAM Module Release 7 9 6 8 6. 7. 8. The RAM module will 9 pop-up, and you can remove it. Pull the latches to release the second module if necessary. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot. 9. The module’s pin alignment will allow it to only fit one way.
Upgrading The Computer Cover Pins 6 Note that this computer model has four cover pins. These pins need to be aligned with slots in the case to insure a proper cover fit, before screwing down the bay cover. 11. Replace the bay cover by (for Model C computers make sure you insert the cover at an angle of LESS THAN 30° ) aligning the cover pins (see sidebar make sure you reconnect the fan cable before screwing down the bay cover). 12.
Modules & Options Chapter 7: Modules & Options Overview This chapter contains information on the following modules, which may come with your computer, depending on the configuration purchased. If you are unsure please contact your service representative. • PC Camera Module • Wireless LAN Module • Bluetooth & Wireless LAN Combo Module • 3.75G/HSPA Module Wireless Device Operation Aboard Aircraft The use of any portable electronic transmission devices aboard aircraft is usually prohibited.
Modules & Options Latest PC Camera Driver Information Check the Device Drivers & Utilities + User’s Manual disc and any accompanying insert pages, for the latest updated information on the PC Camera driver, which may override the information provided here. 7 PC Camera Module Before installing the PC Camera driver, make sure that the optional PC Camera is on. Use the Fn + F10 key combination (see “Function/Hot Key Indicators” on page 1 - 18) to toggle power to the PC Camera module.
Modules & Options PC Camera Driver Installation 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual disc into the CD/DVD drive. 2. Click Option Drivers (button). 3. Click 1.Install Webcam Driver > Yes. 4. Click Next > Install > Finish to restart the computer. OR Click Next > Finish to restart the computer. 5. Run the camera application program from the desktop shortcut (if the hardware is turned off use the Fn + F10 key combination to turn it on again).
Modules & Options PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. 1. 2. 3. 4. 7 Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound). Click Recording (tab). Right-click Microphone (Realtek High Definition Audio) and make sure the item is not disabled. 5. Double-click Microphone (or select Properties from the right-click menu). 6.
Modules & Options Figure 7 - 1 Audio Setup for PC Camera Right-click 7 PC Camera Module 7 - 5
Modules & Options Camera Application The camera application is a video viewer for general purpose video viewing and testing, and for capturing video files to .avi format. 1. 2. 3. 7 Run the camera application from the desktop shortcut (it is recommended that you set the capture file before the capture process - see Set Capture File below). Go to the Capture menu heading (if you wish to capture audio check “PC Camera Audio Setup” on page 7 - 4) and select Start Capture.
Modules & Options Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties). If necessary you can remove the recorded video file to a removable medium e.g. CD, DVD or USB Flash drive.
Modules & Options Latest PC Camera Driver Information 7 Check the Device Drivers & Utilities + User’s Manual disc, and any accompanying insert pages, for the latest updated information on the PC Camera driver, which may override the information provided here, including the figures pictured here. Eliminating Screen Flicker If you find that the video screen in the camera program is flickering, you can try to adjust the setting in the Video Capture Filter options. 1. 2. 3.
Modules & Options Taking Still Pictures The camera application allows you to take still pictures. 1. 2. 3. Run the camera application from the desktop shortcut. Go to Options and select Take Picture. The picture (in JPEG format) will be placed in the Snapshot folder desktop. Snapshot Folder on the The Snapshot folder’s default location is on the desktop. Do not move this folder or an error may appear when you try to take a still picture.
Modules & Options Wireless Device Operation Aboard Aircraft The use of any portable electronic transmission devices aboard aircraft is usually prohibited. Make sure the module(s) are OFF if you are using the computer aboard aircraft. 7 Wireless LAN Module If you have included a Wireless LAN (or WLAN & Bluetooth combo) module in your purchase option, make sure that the module is on before installing the driver.
Modules & Options 802.11b/g/n Driver Installation If you see the message “Found New Hardware” click Cancel to close the window. 1. Make sure the module is powered on, then insert the Device Drivers & Utilities + User’s Manual disc into the CD/DVD drive. 2. Click Option Drivers (button). 3. Click 2.Install WLAN Driver > Yes. 4. Choose the language you prefer and click Next. 5. Click Next > Install. 6. Click Finish to restart the computer.
Modules & Options Network and Sharing Center You can also use the Network and Sharing Center control panel in Windows (Network and Internet) to connect to any available wireless networks. Connecting to a Wireless Network in Windows 7 Make sure the Wireless LAN module is turned on. 1.
Modules & Options 2. 3. 4. You may need to enter a security key for any access point to which you are trying to connect. Click to select a network location (e.g. Home, Work or Public). Click “View or change settings in Network and Sharing Center” to access further options for the connection.
Modules & Options Security Enabled Networks 5. 6. Click the notification area icon to see any currently connected networks. To disconnect from the wireless network you can click the notification area wireless icon , click the active connection and then click Disconnect (button). You should try to make sure that any network you are connecting to is a secure network. 7 Connecting to unsecure networks may allow unauthorized access to your computer, documents, websites and files etc.
Modules & Options Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. To access the Windows Mobility Center: 1. 2. 3. Click Start, and click Control Panel (or point to Settings and click Control Panel). Double-click Windows Mobility Center (Mobile PC). Click the button to Turn wireless off/on, or click the icon to access the network menu.
Modules & Options Wireless Device Operation Aboard Aircraft The use of any portable electronic transmission devices aboard aircraft is usually prohibited. Make sure the module(s) are OFF if you are using the computer aboard aircraft. 7 Use the Fn + F12 key combination to toggle power to the Bluetooth module, and check the LED indicator to see if the module is powered on or not (see Table 1 - 6, on page 1 - 18/ Table 1 - 3, on page 1 - 12).
Modules & Options 3rd Party Bluetooth Combo Driver Installation Note this driver is required for the 3rd Party combo Bluetooth and WLAN module only. 1. Before installing the driver make sure the Bluetooth module is powered on (use Fn + F12 key combination), then insert the Device Drivers & Utilities + User’s Manual disc into the CD/DVD drive. If a Found New Hardware window appears, click Cancel in all windows that appear, and then proceed to install the driver as below. 2. Click Option Drivers (button).
Modules & Options Bluetooth Module & Resuming From Sleep Mode Bluetooth & WLAN Combo Settings 1. 2. 3. Make sure the Bluetooth module is powered on. Double-click the My Bluetooth application on the desktop (or access it from the Programs/All Programs menu). Click My Bluetooth Settings (menu heading). The Bluetooth module’s default state will be off after resuming from the Sleep power-saving state.
Modules & Options 4. 5. Click General Settings to change the computer name that other Bluetooth devices will see, and click the tickbox to Allow Bluetooth devices to find this computer Click OK to confirm the settings.
Modules & Options 6. 7. Click File Transfer Settings to Enable sharing of my files with other Bluetooth devices. Click OK to confirm the settings.
Modules & Options Bluetooth Networking Setup 1. 2. 3. Make sure the Bluetooth module is powered on. Double-click the My Bluetooth application on the desktop (or access it from the Programs/All Programs menu). Click My Bluetooth Settings (see Figure 7 - 7 on page 7 - 18). 7 Figure 7 - 10 Network Settings 4. 5. 6. Click Network Settings (make sure the Bluetooth module is powered on. Click Enable Bluetooth Network and click OK.
Modules & Options Bluetooth Module & Resuming From Sleep Mode The Bluetooth module’s default state will be off after resuming from the Sleep power-saving state. Use the key combination (Fn + F12) to power on the Bluetooth module after the computer resumes from Sleep. 7 Bluetooth & WLAN Combo Module Configuration Setup your Bluetooth Device so the Computer Can Find it 1. 2. Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on.
Modules & Options 3. You will then be presented with a menu of options to select from. 7 Figure 7 - 12 Bluetooth Device Options 4. Click the appropriate button to connect to the device.
Modules & Options 5. 6. You may need to allow the connection from your device, and you will then need to provide a passcode from the device. You can then enter the passcode on the computer and click OK to establish the connection.
Modules & Options Standard Bluetooth Configuration in Windows 7 Setup your Bluetooth Device so the Computer Can Find it 1. 2. Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Make the device discoverable (to do this check your device documentation). To Turn the Bluetooth Module On 1. 2. 3. Press the Fn + F12 key combination to power on the Bluetooth module. A Bluetooth icon will appear in the notification area.
Modules & Options To Add a Bluetooth Device 1. 2. Access the Bluetooth Devices control panel and click Add a device. Double-click the device you want to pair with the computer. 3. On first connection the computer will provide you with a pairing code to be entered onto the device. Pairing Options 7 If a device has been previously connected then the pairing option menu will appear when you attempt subsequent connections.
Modules & Options 4. Enter the code into your Bluetooth enabled device and follow any on-screen instructions to complete the pairing. Pairing Codes The example outlined here shows a connection to a mobile device. Other devices e.g. computers, may have a slightly different connection procedure, and may require you to confirm a pairing code is correct on both devices. Follow the onscreen instructions to complete the pairing. 5. 6. 7.
Modules & Options To Change Settings for the Bluetooth Device Bluetooth Help 7 To get help on Bluetooth configuration and settings, select Help and Support from the Start menu. Type Bluetooth in the Search Help box, and select an item from the returned search results to get more information. 1. 2. • • Click the notification area icon and select Show Bluetooth Devices.
Modules & Options 3.75G/HSPA Module If you have included an optional (not supported by Model C computers) 3.75G/ HSPA (High Speed Packet Access) module (see “Communication” on page C - 4 for specification details) in your purchase option, you will have the appropriate application (BandLuxe HSDPA Utility or Wireless Manager) provided for your particular module. Follow the instructions on page 7 - 30 to install the USIM card (which will be provided by your service provider), and then install the application.
Modules & Options 1. 2. Turn off the computer, and turn it over and remove the battery (see page 6 - 3). Locate the 3.75G USIM card cover and loosen screw 1 , and then remove the USIM card cover 2 . Figure 7 - 19 USIM Card Cover Removal 1 Power Safety Warning 7 Before you undertake any installation procedures, make sure that you have turned off the power, and disconnected all peripherals and cables (including telephone lines).
Modules & Options 6. Lock the SIMLOCK by pushing it in the direction of the arrow in Figure 7 - 21 until it clicks into the lock position. Figure 7 - 21 SIMLOCK Lock 3.75G/HSPA Modules & System Wake Up Note that the 3.75G modules DO NOT support system wake up on 3.75G/HSPA modem activity. 3.
Modules & Options Before installing the application, make sure that the 3.75G/HSPA module is ON (installing the driver with the module off will not allow the software to detect the module hardware correctly). Use the Fn + key combination (see Table 1 - 6, on page 1 - 18) to toggle power to the 3.75G/HSPA module. When the 3.75G/HSPA module is powered on, the indicator will briefly be displayed. Make sure you install the drivers in the order indicated in Table 4 - 1, on page 4 - 3.
Modules & Options BandLuxe HSDPA Utility With the 3.75G/HSPA module and USIM card (supplied by your service provider) installed you may then install the BandLuxe HSDPA Utility. The BandLuxe HSDPA Utility allows you to directly access your HSPA internet service from the computer. BandLuxe HSDPA Utility Installation 1. Enable power to the module by pressing the Fn + key combination (give the module about 10 seconds to power on - the on screen icon will indicate the module’s power status). 2.
Modules & Options BandLuxe HSDPA - Connection Manager The connection information is stored on the USIM card supplied by the service provider (where this is not the case you may need to create a profile - see “Creating a Profile” on page 7 - 37). 1. 2. 3. 7 Power on the 3.75G/HSPA module using the Fn + key combination. Access the Connection Manager from the Start menu (Connection Manager ), or (Start > Programs/All Programs > BandLuxe > BandLuxe HSDPA Utility R11 > Connection Manager). Click CONNECT .
Modules & Options 4. 5. The system will connect to your network (you may need to set your network connection to home, work or public on the first connection). The connected icon will appear at the top of the utility screen. Figure 7 - 23 Connected 6. You can then access the internet, download e-mail etc. as per any internet connection. 7 Figure 7 - 24 BandLuxe Connection Manager (Connected) 3.
Modules & Options 7. While you are connected the notification area icon will display the connected icon . , and the notification area will display the connected icon Figure 7 - 25 Notification Area Icon (Connected) 7 8. To disconnect from the service provider, click the Disconnect icon, or click the close icon at the top right of the utility, and click Yes to confirm. 9. The program will disconnect from the service provider. key combination 10.
Modules & Options Creating a Profile 1. 2. Access the Connection Manager from the Start menu (Connection Manager ), or (Start > Programs/All Programs > BandLuxe > BandLuxe HSDPA Utility R11 > Connection Manager). Click the Menu > Profile. Figure 7 - 26 Menu - Profile 7 3. The default profile will display the service provider’s name from the USIM card. Figure 7 - 27 Default Profile 3.
Modules & Options 4. Password The password can be any combination of letters and numbers, and is case sensitive. Check with your service provider to confirm that a user name and password are required. 5. 6. 7. 8. Click New (button) and input any Network Settings required by your service provider (all fields may not need to be filled in). The profile name is used to identify your profile if a number of profiles are used.
Modules & Options 9. Click the newly created profile in the profile window and then click Default (button) to set the profile as the default connection (note that only one profile may be stored as the default connection). 10. The newly created profile will now be stored as the default connection when you click Connect in the Connection Manager Home screen. 11. To use a profile click to select it, and then click Apply (button) and the settings will be transferred to Connection Manager.
Modules & Options Choosing a Profile If you need to switch stored profiles follow the instructions below: 1. 2. 3. 4. 5. 7 Access the Connection Manager from the Start menu (Connection Manager ), or (Start > Programs/All Programs > BandLuxe > BandLuxe HSDPA Utility R11 > Connection Manager). Click the Menu > Profile. Highlight the profile required and click Default. Click OK to confirm. YES will be displayed alongside the chosen default profile. Figure 7 - 30 Choosing a Profile 7 - 40 3.
Modules & Options Editing a Profile If you need to edit stored profiles follow the instructions below: 1. 2. 3. 4. Access the Connection Manager from the Start menu (Connection Manager ), or (Start > Programs/All Programs > BandLuxe > BandLuxe HSDPA Utility R11 > Connection Manager). Click the Menu > Profile. Highlight the profile required and click Edit.
Modules & Options Incoming Messages If the program is open (you do not have to be connected) you will be notified of incoming messages in the notification area (see “SMS Preference” on page 7 - 46 for settings detail). Text Messaging Service (SMS) In addition to standard internet services you may also send and receive SMS text messages using the Connection Manager, if your service supports SMS. Inbox The Inbox will contain any received SMS. Click to select the message and it will scroll open above.
Modules & Options Sent The Sent folder contains any successfully sent SMS. Select the message and press the Delete to erase the record. Outbox The Outbox folder contains any completed but unsent SMS. Select the message and press Send or Delete as appropriate. Compose Click Compose to create a new message. You can enter the telephone number in the To field, or click the contact button to add a contact from a list. The contact list allows you to choose 3 contact options (see sidebar).
Modules & Options Template A template can store text that is used regularly in messages, and can be easily inserted in to any new SMS. Click Template (button) to view any stored templates. Click to highlight a template and click Select (button) to insert it into the message. Click New (button) to create a new template, and Save (button) to add it to the existing list. To delete a template click to highlight it, and click Delete (button) to delete it.
Modules & Options Setting The Setting menu allows you to edit the programs basic parameters. 1. 2. 3. 4. Access the Connection Manager from the Start menu (Connection Manager ), or (Start > Programs/All Programs > BandLuxe > BandLuxe HSDPA Utility R11 > Connection Manager). Click the Menu > Setting. Click the appropriate tab heading to edit the settings. After you have edited the settings, click Save (button) to confirm the changes.
Modules & Options Figure 7 - 36 SMS - Preference Click the New SMS Notify checkbox to be automatically notified when a new SMS arrives. If enabled a the incoming message notification will appear in the notification area, and an envelope icon will appear in the upper left corner of the Home screen Incoming SMS Notification when a new message arrives.
Modules & Options SIM This menu allows you to edit the USIM card Personal Identification Number (PIN) and Enable/Disable the PIN if necessary. Press Apply after making any changes. A SIM card must be inserted for this function to be activated. Figure 7 - 38 Setting - SIM 7 If a PIN code is enabled, the input will be requested during USIM card initialization. After 3 incorrect PIN code entries the USIM card will be locked, and you will need to contact your service provider to unlock it. 3.
Modules & Options Radio Set the appropriate network search options from the dual mode setting menu. Click Apply (button) after making any changes. Figure 7 - 39 Setting - Radio 7 Note: 2G/3G/3.5G data transferring will be disconnected when you apply a new Radio setting. 7 - 48 3.
Modules & Options Network - Network Selection Edit the network selection settings from this menu. The Standard (auto) setting will search for networks in the order specified in the Prefer list. Click Standard (auto) > Next to view and adjust the Prefer list. The Prefer list is displayed at the top of the screen, and the bottom of the screen lists all available networks. Click Scan to bring up a list of all available networks.
Modules & Options The Manual setting allows you to choose a network from all available. Click Manual > Next to view the list. Click to highlight a network from the list, and click Select (button) to choose the network, or Cancel (button) to make no change. Figure 7 - 41 Setting - Network Manual 7 7 - 50 3.
Modules & Options Statistics & Information The Statistics screen displays a graph of recent upload and download activity. No data will be displayed if there is no current connection. 1. 2. 3. Access the Connection Manager from the Start menu (Connection Manager ), or (Start > Programs/All Programs > BandLuxe > BandLuxe HSDPA Utility R11 > Connection Manager). Click the Menu > Statistics. Click Connection Log (tab) to see data counting by each and total connection status (for reference only).
Modules & Options Wireless Manager Wireless Device Operation Aboard Aircraft The use of any portable electronic transmission devices aboard aircraft is usually prohibited. Make sure the module(s) are OFF if you are using the computer aboard aircraft. 7 Use the Fn + key combination to toggle power to the 3.75G/HSPA module, and check the indicator to see if the module is powered on or not (see Table 1 - 6, on page 1 - 18/ Table 1 - 3, on page 1 - 12). With the 3.
Modules & Options Wireless Manager Application The connection information is stored on the USIM card supplied by the service provider (where this is not the case you may need to create a profile - see “Creating a Profile” on page 7 - 59). 1. 2. 3. 4. Power on the 3.75G/HSPA module using the Fn + key combination. Access the Wireless Manager application from the Start menu (Start > All Programs > Wireless Manager > Wireless Manager) or the desktop shortcut .
Modules & Options Wireless Manager Help 5. 6. 7. The system will connect to your network. Connected will appear above the timer icon (the timer will indicate your connected time for the current session) . You can then access the internet, download e-mail etc. as per any internet connection. To get help on Wireless Manager configuration and settings, click the Help icon or press F1. 7 Figure 7 - 44 Wireless Manager (Connected) 7 - 54 3.
Modules & Options 8. Click the Wireless Manager notification area icon to view the connection status, or wireless icon to view the Mobile Broadband Connection status. Figure 7 - 45 Notification Area Icons (Connected) 9. 10. 11. 12. 13. The indicator will display the signal strength and radio access technology.
Modules & Options Profiles 1. 2. 3. Access the Wireless Manager application from the Start menu (Start > All Programs > Wireless Manager > Wireless Manager) or the desktop shortcut . Click the Settings > Advanced. Click the Profiles (tab). Figure 7 - 46 Advanced Settings Profiles 7 7 - 56 3.
Modules & Options 4. Multiple profiles may be available from the USIM card and the first time the application starts it may require you to select a profile (Set Profile) to use for your connection. Figure 7 - 47 Multiple Profiles Found 7 Automatic Profile Selection If Automatic selection is chosen, then the application will search the operator profile database for a profile that matches the details on your USIM card. If a correct profile is found it will be automatically selected as your profile.
Modules & Options Selecting a Profile 1. 2. 3. Click Manual selection (button). Click the Filter to view the drop-down list. Select the Profile you wish to use and click Apply to confirm the selection. Figure 7 - 48 Profile - Manual Selection (Filter) 7 7 - 58 3.
Modules & Options Creating a Profile 1. 2. 3. 4. 5. 6. 7. 8. Click Manual selection (button). Click the New. Enter a name you prefer for the profile. Enter the Access Point Name (APN). Enter the User Name and Password if required (some service providers may not require this information and the fields may then be left blank). If your service provider requires IP address, DNS and Protocols to be entered, click the appropriate tab and enter the supplied information (otherwise leave blank).
Modules & Options Settings The Settings tab allows you at adjust the application features. Click to put a tick in Launch Wireless Manager at Windows startup to launch the application at Windows Startup. Figure 7 - 50 Settings 7 The Advanced settings allows more detailed configuration. To access the Advanced settings: 1. 2. 3. Access the Wireless Manager program from the Start menu (Start > All Programs > Wireless Manager > Wireless Manager) or the desktop shortcut . Click the Settings > Advanced.
Modules & Options SIM Most USIM cards are protected by a Personal Identity Number (PIN). You may turn on or off the Request PIN at startup (click Apply to save any changes). You can also Change PIN (you will need to enter the new PIN in the two fields provided and click Apply to save any changes). Radio Radio needs to be turned on before you can make any connection (note this is not the same as powering the module off/on using the Fn + key combination), but you may turn it off when required.
Modules & Options Warning 7 Note that some applications automatically transmit data when connected, and you may be charged for the data transfer. Some auto connection/connection settings may lead to expensive roaming charges. Networks The mobile network list lists available networks at your location, and allows you to select a network which to connect. You must disconnect before being able to select a network.
Modules & Options Text Messaging Service (SMS) In addition to standard internet services you may also send and receive SMS text messages using the Wireless Manager, if your service supports SMS. SMS Utility 1. 2. 3. Access the Wireless Manager application from the Start menu (Start > All Programs > Wireless Manager > Wireless Manager) or the desktop shortcut . Click SMS and the SMS Utility will then start.
Modules & Options Messages Click the Messages tab to access the tabs displaying text messages. The tabs at the top of the menu display the Inbox, Drafts, Outbox, Sent and Trash menus. Inbox Drafts Outbox Sent Trash 7 Figure 7 - 54 SMS Utility Messages Text messages are automatically saved to your computer and may be sorted in ascending or descending order by name or date. 7 - 64 3.
Modules & Options Sending a Text Message 1. 2. 3. 4. 5. 6. Access the Wireless Manager application from the Start menu (Start > All Programs > Wireless Manager > Wireless Manager) or the desktop shortcut . Click SMS and the SMS Utility will then start. Click the New Message tab. Enter the phone number in the To field (multiple numbers may be entered to select a name from separated by a semicolon (;), or click the phonebook icon the phonebook.
Modules & Options 7. 8. 9. Click Send to send the message or Save to save the message in the Drafts folder. clears both the Message and To fields. Clicking the Clear icon If radio is on then the message will be sent, however if the radio is off the message will be stored in the Outbox. Note that you do not have to connect to the network to Send/Receive SMS messages. Inbox Any received text messages will be displayed in the Inbox.
Modules & Options Messages • Opening a text message: Double-click the message and the message will open in a new window (to close it click the close icon in the top right of the message). Figure 7 - 57 Click to close the message • Previewing a text message: Click the preview icon will open. Click the icon again to close the preview. Close Message and the message preview • Replying to a text message: Double-click the message and click Reply.
Modules & Options Phonebook The Phonebook allows you to view and edit all your frequently used contacts, and is divided into Contacts and Groups . To access the Phonebook: 1. 2. 3. Access the Wireless Manager application from the Start menu (Start > All Programs > Wireless Manager > Wireless Manager) or the desktop shortcut . Click SMS and the SMS Utility will then start. Click the Phonebook tab. 7 Figure 7 - 58 SMS Utility Phonebook (Contacts) 7 - 68 3.
Modules & Options Contacts • New Contact: Click the New contact button to create a contact. Add the name and at least one phone number (Mobile, Work, Home and Other fields are available) for the contact. Click the icon to expand the number details. Select Synchronize with SIM to synchronize the contact information with your USIM card. Click the Save icon to save the information. Import/Export Contacts Import/Export Contacts: Click the Import/ Export buttons to import or export the list of contacts.
Modules & Options Groups You can organize existing contacts into groups from the Groups tab. • New Group: Click the New group button to create a group. Click the icon to expand the group details, and click a check box to add at least one phone number from the contacts for the group. Click the Save icon to save the information.
Modules & Options SMS Settings The SMS Utility Settings tab allows you at adjust the SMS features. Figure 7 - 61 SMS Utility Settings SMS Settings Message Length: You can set the number of blocks that can be sent (up to a length of 10 blocks). The Advanced settings allows more detailed configuration. To access the Advanced settings: 1. 2. 3. 4. Access the Wireless Manager application from the Start menu (Start > All Programs > Wireless Manager > Wireless Manager) or the desktop shortcut .
Modules & Options Send Click Delivery Report to automatically request a reply from a recipient. If you click to Send messages in Outbox automatically upon connection then messages written when the radio is off, will then be sent automatically the next time radio is turned on. You can also choose to Include original message in reply. Notification This menu allows you to enable/disable Show animation on new message to get an animated notification of newly received messages.
Modules & Options Number You can choose to Use default service center number or you can uncheck the box and add your number manually if your service provider supplies a different number (click Apply to save the change or Default to return to the default number). Memory Phonebook memory status displays the number of contacts displayed on the USIM card. 7 Figure 7 - 63 SMS Utility Advanced Settings Number & Memory 3.
Modules & Options 7 7 - 74
Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.
Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer appears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working. Check the LED Power & Communication Indicators (see “System Map: LCD Panel Open - Model C” on page 1 - 11) to see the computer’s power status.
Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wallet. • Run maintenance programs on your hard disk and OS as often as you can. You may schedule these programs to run at times when you are not using your computer.
Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the definitions file updates are usually downloadable directly from the internet. • Be careful when opening e-mail from sources you don’t know.
Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing. • Read the documentation.
Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. • Don’t over complicate things.
Troubleshooting Problems and Possible Solutions Problem Possible Cause - Solution You turned on the power but it doesn’t work. Battery missing / incorrectly installed. Check the battery bay, make sure the battery is present and seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts. The battery LED power indicator blinking orange. , is Low Battery. Plug in the DC power source.
Troubleshooting Problem The computer feels too hot. Possible Cause - Solution Make sure the computer is properly ventilated and the Vent/Fan intakes are not blocked. If this doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating” on page 1 - 22). Make sure you’re using the correct adapter.
Troubleshooting Problem Possible Cause - Solution You forget the boot password. If you forget the password, you may have to discharge the battery of the CMOS. Contact your service representative for help. Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
Troubleshooting Problem Possible Cause - Solution I am sliding my finger up and down on the right side of the Touchpad to scroll a Window and the Touchpad does not respond. There are different Touchpad versions available on this computer, and this version requires tapping/holding to scroll. Either tap repeatedly, or hold the finger down, at the top or bottom right of the Touchpad (depending on the scrolling direction required) to scroll the window.
Troubleshooting Problem Possible Cause - Solution The Wireless LAN/Bluetooth/3.75G/ HSPA modules cannot be detected. The modules are off. Check the LED indicator and/or function key indicator to see if the WLAN/Bluetooth/3.75G/HSPA module is on or off (see “LED Indicators” on page 1 - 12). If the LED indicator is off, then press the Fn + F11 (WLAN), Fn + F12 (Bluetooth) or Fn + (3.75G/HSPA) key combination(s) in order to enable the modules (see Table 1 - 6, on page 1 - 18).
Troubleshooting Problem I cannot obtain high speed Bluetooth data transfer. 8 Possible Cause - Solution To obtain high speed Bluetooth data transfer take into account the following: • To achieve high speed transfer speeds, both devices must support high speed data transfer (i.e both the computer and the Bluetooth compatible device you are connecting to). • To obtain high speed (V3.
Troubleshooting Bluetooth Connection Problems If you are experiencing problems connecting to some Bluetooth devices (in particular certain mobile phones and headsets) it maybe necessary to download and install the Windows Mobile Device Center software (for Windows Vista and Windows 7). Go to the Microsoft website and search for the Microsoft Windows Device Center Driver for Windows Vista (64-bit or 32-bit) and Windows 7 (64-bit or 32-bit), and then download the driver. 1. 2. 3. 4. 5.
Troubleshooting 6. 7. 8. 8 Right-click Bluetooth Peripheral Device and click on Update Driver Software. Click Browse my computer for driver software. Click Let Me pick from a list of device drivers on my computer. Figure 8 - 2 - Browse my computer.../Let me pick from... 9. Select Bluetooth Radios from the list.
Troubleshooting 10. A list of drivers will appear with Manufacturer on one side and Model in the other. 11. Choose Microsoft Corporation (make sure you choose the full name Microsoft Corporation and do not choose Microsoft - Note that you must have installed the Microsoft Windows Device Center Driver for Microsoft Corporation to appear in the list). 12. Select Windows Mobile-based device support from the Model list. 8 Make sure you select Microsoft Corporation Figure 8 - 4 - Select Device Driver 13.
Troubleshooting 15. The Device Manager should now display the Windows Mobile-based device support under Bluetooth Radios. 16. You will need to repeat the process for any other Bluetooth Peripheral Devices listed under Other Devices.
Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc.
Interface (Ports & Jacks) Notebook Ports and Jacks Item Description Card Reader The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device. DC-In Jack Plug the supplied AC/DC adapter into this jack to power your computer. External Monitor (VGA) Port This port allows you to connect an external monitor, or Flat Panel Display, to get dual video or simultaneous display on the LCD and external monitor/FPD.
Interface (Ports & Jacks) Item Description Microphone-In Jack Plug an external microphone in to this jack to record on your computer. RJ-45 LAN Jack This port supports LAN (Network) functions. Note: Broadband (e.g. ADSL) modems usually connect to the LAN port. Security Lock Slot To prevent possible theft, a Kensington-type lock can be attached to this slot. Locks can be purchased at any computer store. USB 2.0/1.1 Ports These USB 2.0 compatible ports (USB 2.0 is fully USB 1.
Interface (Ports & Jacks) A A - 4
AMD Video Driver Controls Appendix B: AMD Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - 26. Video Driver Installation Make sure you install the drivers in the order indicated in Table 4 - 1, on page 4 - 3. Video (VGA) 1. Insert the Device Drivers & Utilities + User’s Manual disc and click Install Drivers (button). 2. Click 1.Install VGA Driver > Yes. 3. Click Next > Install (button). 4.
AMD Video Driver Controls AMD Vision Engine/Catalyst™ Control Center Adjust the video settings from the AMD/ATI Control Center. Taskbar Icon 1. The Control Center can also be accessed by double-clicking the icon in the taskbar notification area (or by right-clicking the icon and selecting the control center). If you don’t see the icon in the taskbar, click Preferences in the control center, and select Enable System Tray Menu (see over). 2.
AMD Video Driver Controls AMD Vision Engine/Catalyst™ Control Center Preferences The Preferences button in the control center menu allows you to configure the control panel settings. You can view the control panel in either Standard View or Advanced View. To display Standard View or Advanced View: 1. 2. Open the control center. Click the Preferences button and select either Advanced View or Standard View.
AMD Video Driver Controls Standard View The Standard View menus feature a series of menu headings with clickable submenus which allow you to adjust Desktops and Displays, Power, Video, Gaming and Information. Click the Start button to access the top level menu from any submenu heading.
AMD Video Driver Controls Advanced View The Advanced View menus display all the menu headings as a series of buttons on the left. Click the arrows in any button to display the sub-menus (note all the figures in the remainder of this chapter are in Advanced View). Sub-Menus Click a menu button to expand any sub-menus, and then click the appropriate sub-menu heading to configure the item. Click a menu button to expand the sub-menus.
AMD Video Driver Controls Help Menus The control center provides additional video configuration controls and tools which allow quick access to features such as display options, 3D Settings, color, power and Information menus etc. Adjust settings from the options in the sub-menus. Press F1 to bring up Help menu. Click the question mark icon in the top right to bring up help on a specific page.
AMD Video Driver Controls Display Devices & Options Besides the built-in LCD you can also use an external monitor/flat panel display/TV connected to the external monitor port or to the HDMI-Out port (High-Definition Multimedia Interface) as your display device. The table below outlines the display options.
AMD Video Driver Controls Detect Displays Click Detect Displays (button) to automatically update the attached display information. B Configuring an External Display You can use the control center to configure any attached displays. 1. 2. 3. 4. Attach your external display to the external monitor port/HDMI-Out port, and turn it on. Open the control center. Select Desktop Management from the menu on the left (click the arrow to expand the menu) and click Creating and Arranging Desktops.
AMD Video Driver Controls 5. 6. Click the triangle icon (or right-click the display icon) on the attached display icon at the bottom to bring up the options (e.g Duplicate or Extend). Select an option from the menu (click Continue if required), and click Yes to accept the settings. Disable Displays If you want to disable any of the displays, right-click the display icon at the bottom of the screen and click Disable. Figure B - 7 Attached displays will appear here. 7.
AMD Video Driver Controls Desktop Properties Use Desktop Properites (Desktop Management) to configure the desktop area resolution, color quality, refresh rate and rotation. If the displays are configured in Extend mode then they may be configured independently.
AMD Video Driver Controls My VGA Displays/My Digital Flat-Panels An additional menu button entitled My VGA Displays/My Digital Flat-Panels will appear (depending on the type of display attached) when an external display is attached. This menu allows you to configure the properties of the external display. After making any adjustments you may need to click the Apply button to confirm the changes.
AMD Video Driver Controls HDTV Support If your flat panel supports HDTV functions then this can be configured from My Digital Flat-Panels > HDTV Support (Digital Flat-Panel).
AMD Video Driver Controls Configuring an External Display In Windows 7 1. 2. 3. 4. Attach your external display to the external monitor port/HDMI-Out port, and turn it on. Go to the Screen resolution control panel (see “Video Features” on page 1 - 26). Click the Detect button. The computer will then detect any attached displays.
AMD Video Driver Controls 5. You can configure the displays from the Multiple Displays menu. Figure B - 12 Screen Resolution Multiple Display Options (Win 7) B • Duplicate these displays - Shows an exact copy of the main display desktop on the other display(s) • Extend these displays - Treats both connected displays as separate devices • Show desktop only on 1/2 - Only one of your displays is used.
AMD Video Driver Controls Using the Windows Logo Key + P Key Combination to Switch Displays You can also use the + P key combination to quickly change display configuration and modes (this is particularly useful when attaching a projector) in Windows 7. 1. 2. 3. 4. Attach your external display to the external monitor port and turn it on. + P key combination. Press the An on-screen menu will pop up.
AMD Video Driver Controls PowerPlay™ When enabled, PowerPlay™ can be used to automatically set to adjust the graphics processor settings for higher performance or longer battery life when the system is either Plugged In or on Battery.
AMD Video Driver Controls HDMI Audio Configuration HDMI (High-Definition Multimedia Interface) carries both audio and video signals. Configure the audio output as per the instructions below. 1. 2. 3. 4. Connect a device with HDMI support to the HDMI-Out port. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound), and click Playback (tab).
AMD Video Driver Controls 5. 6. Double-click the connected HDMI device (or right-click and select Properties) to adjust the HDMI settings from the control panel tabs. Click OK to close the control panel (see notes overleaf).
AMD Video Driver Controls HDMI Notes • Connect a device with HDMI support to the HDMI-Out port BEFORE attempting to play audio/video sources through the device. • To play audio sources through your external display’s (TV or LCD) speakers you will need to go to the audio configuration control panel on the display and configure the audio input accordingly (see your display device manual). HDMI Video Configuration 1. 2. 3. 4. Connect an HDMI cable from the HDMI-Out port to your external display.
AMD Video Driver Controls B B - 20
Specifications Appendix C: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your service center for details.
Specifications Processor Memory Display Models A, B & C: AMD-C Series Accelerated Processing Unit - C30 1C (1.2GHz) 512KB L2 Cache, 40nm (40 Nanometer), TDP 9W, DDR3 - 1066MHz Models A & B: Single Channel DDRIII (DDR3) Model A: 14.0” / 35.56cm HD (1366 * 768), 16:9 Panel AMD-C Series (Dual-Core) Accelerated Processing Unit - C50 2C (1.
Specifications Video Audio Slots Model C: Integrated with C50 APU - AMD Mobility Radeon™ HD 6250M PCIe * 16 Video Card High Definition Audio Interface Direct Sound 3D™ Compatible Built-In Microphone 2 * Built-In Speakers Models A & B: Integrated with E350 APU - AMD Mobility Radeon™ HD 6310M PCIe * 16 Video Card Keyboard & Pointing Device High Preference 3D/2D Graphic Accelerator Shared Memory Architecture of up to 1469MB (if 4GB of System Memory is installed on Windows 7 32-bit) Microsoft® DirectX11
Specifications Communication Power Indicators Built-In 10/100Mb Base-TX Ethernet LAN 1.3M/300K Pixel PC Camera Module with USB interface (Factory Option) Models A & B: Removable 3 Cell Smart Lithium Ion Battery Pack 24.42WH LED Indicators - Power/Suspend, Battery, HDD/ODD, Bluetooth/Wireless LAN, Num Lock, Caps Lock, Scroll Lock 802.11b/g/n Wireless LAN Half Mini-Card Module (Factory Option) Removable 6 Cell Smart Lithium Ion Battery Pack 48.
Specifications Dimensions & Weight Model A: 340mm (w) * 238mm (d) * 13.9 - 31.8mm (h) 2.05 kg with 3 Cell Battery & ODD For Model A Design II (and Some Other Model A Designs): 341mm (w) * 238.5mm (d) * 16- 34mm (h) 2.05 kg with 3 Cell Battery & ODD Model B: 374mm (w) * 250mm (d) * 14.3 - 34.1mm (h) 2.25kg with 3 Cell Battery & ODD Model C: 413mm (w) * 270mm (d) * 14.3~40.5mm (h) 2.
Specifications C C - 6
