Specifications
Specifications C - 3
C
Video
Model C:
Integrated with C50 APU - AMD
Mobility Radeon™ HD 6250M PCIe * 16
Video Card
Integrated with E350 APU - AMD
Mobility Radeon™ HD 6310M PCIe * 16
Video Card
High Preference 3D/2D Graphic
Accelerator
Shared Memory Architecture of up to
1469MB
(if 4GB of System Memory is
installed on
Windows 7
32-bit)
Microsoft® DirectX11 Compatible
BIOS
One 16Mb SPI Flash ROM
AMI BIOS
Storage
One Changeable 12.7mm(h) Super Multi
Optical Device Drive with SATA Interface
(Factory Option)
One Changeable 2.5" / 9.5 mm (h) HDD
with SATA (Serial) Interface
Audio
High Definition Audio Interface
Direct Sound 3D™ Compatible
Built-In Microphone
2 * Built-In Speakers
Keyboard & Pointing Device
Isolated WinKey Keyboard
Built-in TouchPad with Multi-Gesture
Functionality
Interface
Three USB 2.0 Ports
One External Monitor Port
One HDMI 1.3 Out Port
One Microphone-In Jack
One Headphone-Out Jack
One RJ-45 LAN Jack
One DC-In Jack
Slots
Models A & B:
Two Mini-Card Slots with PCIe & USB
Interfaces:
Slot 1 for WLAN Module Or WLAN &
Bluetooth Combo Card
Slot 2 for 3.75G Module
Model C:
One Mini-Card Slot with PCIe & USB
Interfaces:
Slot 1 for WLAN Module Or WLAN &
Bluetooth Combo Card
Card Reader
Embedded Multi-In-1 Card Reader
- MMC/ RS MMC
- SD/ Mini SD / SDHC/ SDXC
- MS/ MS Pro/ MS Duo
Note: Some of these cards require PC
adapters that are usually supplied with
the cards.
