Channels and Maximum Power Settings for Cisco Aironet Autonomous Access Points and Bridges
OL-11142-01
Chapter 5 Cisco Aironet 1250 Series Autonomous Access Point
Channels and Maximum Power Levels
Table 5-3 indicates the channel identifiers, channel center frequencies, and maximum power levels for
each channel allowed by the –E regulatory domain for a 2.4-GHz radio with up to 6-dBi antennas.
Table 5-3 Channels and Maximum Conducted Power in the –E Regulatory Domain with up to 6-dBi Antennas
Maximum Conducted Power Levels (dBm) in the –E Regulatory Domain for the 2.4-GHz Radio with up to 6-dBi Antennas
Freq
(MHz)
Center
Channel
802.11b
Single Antenna
1 to 11 Mbps
802.11g
Single Antenna
6 to 54 Mbps
802.11g
Dual Antennas
6 to 54 Mbps
802.11g
Dual Antennas
with Beam
Forming
HT-20 MHz
Dual Antennas
M0 to M15
HT-40 MHz
Dual Antennas
M0 to M15
20
MHz
40
MHz
Tx
A
Tx
B
Total
Power
Tx
A
Tx
B
Total
Power
Tx
A
Tx
B
Total
Power
Tx
A
Tx
B
Total
Power
Tx
A
Tx
B
Total
Power
Tx
A
Tx
B
Total
Power
2412 1 3 14 OFF 14 14 OFF 14 11 11 14 8 8 11 11 11 14 11 11 14
2417 2 4 14 OFF 14 14 OFF 14 11 11 14 8 8 11 11 11 14 11 11 14
2422 3 5 14 OFF 14 14 OFF 14 11 11 14 8 8 11 11 11 14 11 11 14
2427 4 6 14 OFF 14 14 OFF 14 11 11 14 8 8 11 11 11 14 11 11 14
243253, 714OFF1414OFF14111114 88 11111114111114
243764, 814OFF1414OFF14111114 88 11111114111114
244275, 914OFF1414OFF14111114 88 11111114111114
2447 8 6 14 OFF 14 14 OFF 14 11 11 14 8 8 11 11 11 14 11 11 14
2452 9 7 14 OFF 14 14 OFF 14 11 11 14 8 8 11 11 11 14 11 11 14
245710814OFF1414OFF14111114 88 11111114111114
246211914OFF1414OFF14111114 88 11111114111114
246712–14OFF1414OFF14111114 88 11111114 –– –
247213–14OFF1414OFF14111114 88 11111114 –– –
2484––––––––––––––––––––
