Channels and Maximum Power Settings for Cisco Aironet Autonomous Access Points and Bridges
OL-11142-01
Chapter 5 Cisco Aironet 1250 Series Autonomous Access Point
Channels and Maximum Power Levels
Table 5-4 indicates the channel identifiers, channel center frequencies, and maximum power levels for
each channel allowed by the –E regulatory domain for a 2.4-GHz radio with up to 9-dBi antennas.
Table 5-4 Channels and Maximum Conducted Power in the –E Regulatory Domain with up to 9-dBi Antennas
Maximum Conducted Power Levels (dBm) in the –E Regulatory Domain for the 2.4-GHz Radio with up to 9-dBi Antennas
Freq
(MHz)
Center
Channel
802.11b
Single Antenna
1 to 11 Mbps
802.11g
Single Antenna
6 to 54 Mbps
802.11g
Dual Antennas
6 to 54 Mbps
802.11g
Dual Antennas
with Beam
Forming
HT-20 MHz
Dual Antennas
M0 to M15
HT-40 MHz
Dual Antennas
M0 to M15
20
MHz
40
MHz
Tx
A
Tx
B
Total
Power
Tx
A
Tx
B
Total
Power
Tx
A
Tx
B
Total
Power
Tx
A
Tx
B
Total
Power
Tx
A
Tx
B
Total
Power
Tx
A
Tx
B
Total
Power
2412 1 3 11 OFF 11 11 OFF 11 8 8 11 5 5 8 8 8 11 8 8 11
2417 2 4 11 OFF 11 11 OFF 11 8 8 11 5 5 8 8 8 11 8 8 11
2422 3 5 11 OFF 11 11 OFF 11 8 8 11 5 5 8 8 8 11 8 8 11
2427 4 6 11 OFF 11 11 OFF 11 8 8 11 5 5 8 8 8 11 8 8 11
2432 5 3, 7 11 OFF 11 11 OFF 11 8 8 11 5 5 8 8 8 11 8 8 11
2437 6 4, 8 11 OFF 11 11 OFF 11 8 8 11 5 5 8 8 8 11 8 8 11
2442 7 5, 9 11 OFF 11 11 OFF 11 8 8 11 5 5 8 8 8 11 8 8 11
2447 8 6 11 OFF 11 11 OFF 11 8 8 11 5 5 8 8 8 11 8 8 11
2452 9 7 11 OFF 11 11 OFF 11 8 8 11 5 5 8 8 8 11 8 8 11
2457 10 8 11 OFF 11 11 OFF 11 8 8 11 5 5 8 8 8 11 8 8 11
2462 11 9 11 OFF 11 11 OFF 11 8 8 11 5 5 8 8 8 11 8 8 11
2467 12 – 11 OFF 11 11 OFF 11 8 8 11 5 5 8 8 8 11 – – –
2472 13 – 11 OFF 11 11 OFF 11 8 8 11 5 5 8 8 8 11 – – –
2484––––––––––––––––––––
