Channels and Maximum Power Settings for Cisco Aironet Autonomous Access Points and Bridges
OL-11142-01
Chapter 5 Cisco Aironet 1250 Series Autonomous Access Point
Channels and Maximum Power Levels
Table 5-6 indicates the channel identifiers, channel center frequencies, and maximum power levels for
each channel allowed by the –P regulatory domain for a 2.4-GHz radio with up to 10-dBi antennas.
5 GHz Band (pre-n IEEE 802.11n)
An improper combination of power level and antenna gain can result in equivalent isotropic radiated
power (EIRP) above the amount allowed per regulatory domain.
Note Dynamic Frequency Selection (DFS) operation and operation from 5500 to 5700 MHz has not been
authorized as required by the rules of the Federal Communications Commission and is not supported in
the -A regulatory domain until authorization is obtained.
Table 5-6 Channels and Maximum Conducted Power for the 2.4-GHz Radio with up to 10-dBi Antennas
Maximum Conducted Power Levels (dBm) in the –P Regulatory Domain for the 2.4 GHz Radio with up to 10 dBi Antennas
Freq
(MHz)
Center
Channel
802.11b
Single Antenna
1 to 11 Mbps
802.11g
Single Antenna
6 to 54 Mbps
802.11g
Dual Antennas
6 to 54 Mbps
802.11g
Dual Antennas
with Beam
Forming
HT-20 MHz
Dual Antennas
M0 to M15
HT-40 MHz
Dual Antennas
M0 to M15
20
MHz
40
MHz
Tx
A
Tx
B
Total
Power
Tx
A
Tx
B
Total
Power
Tx
A
Tx
B
Total
Power
Tx
A
Tx
B
Total
Power
Tx
A
Tx
B
Total
Power
Tx
A
Tx
B
Total
Power
2412 1 3 14 OFF 14 17 OFF 17 14 14 17 11 11 14 14 14 17 17 17 20
2417 2 4 14 OFF 14 17 OFF 17 14 14 17 11 11 14 14 14 17 17 17 20
2422 3 5 14 OFF 14 17 OFF 17 14 14 17 11 11 14 14 14 17 17 17 20
2427 4 6 14 OFF 14 17 OFF 17 14 14 17 11 11 14 14 14 17 17 17 20
243253, 714OFF1417OFF17141417111114141417171720
243764, 814OFF1417OFF17141417111114141417171720
244275, 914OFF1417OFF17141417111114141417171720
2447 8 6 14 OFF 14 17 OFF 17 14 14 17 11 11 14 14 14 17 17 17 20
2452 9 7 14 OFF 14 17 OFF 17 14 14 17 11 11 14 14 14 17 17 17 20
245710814OFF1417OFF17141417111114141417171720
246211914OFF1417OFF17141417111114141417171720
246712–14OFF1417OFF17141417111114141417 –– –
247213–14OFF1417OFF17141417111114141417 –– –
248414–14OFF14–––––––––––––––
