Channels and Maximum Power Settings for Cisco Aironet Autonomous Access Points and Bridges
OL-11142-01
Chapter 5 Cisco Aironet 1250 Series Autonomous Access Point
Channels and Maximum Power Levels
Table 5-7 indicates the channel identifiers, channel center frequencies, and maximum power levels for
each channel allowed by the –A regulatory domain for a 5-GHz radio with up to 6-dBi antennas.
Table 5-7 Channels and Maximum Conducted Power in the –A Regulatory Domain with up to 6-dBi Antennas
Maximum Conducted Power Levels (dBm) in the –A Regulatory Domain for the 5-GHz Radio with up to 6-dBi Antennas
Channel
ID
Freq
(MHz)
802.11a
Single Antenna
6 to 54 Mbps
802.11a
Dual Antennas
6 to 54 Mbps
802.11a
Dual Antennas with
Beam Forming
HT-20 MHz
Dual Antennas
M0 to M15
Duplicate
(2x20 MHz)
Dual Antennas
6 Mbps
HT-40 MHz
Dual Antennas
M0 to M15
Tx
A
Tx
B
Total
Power
Tx
A
Tx
B
Total
Power
Tx
A
Tx
B
Total
Power
Tx
A
Tx
B
Total
Power
Tx
A
Tx
B
Total
Power
Tx
A
Tx
B
Total
Power
5150-5250 MHz
36 5180
14OFF14111114 88 11111114111114111114
40 5200
14OFF14111114 88 11111114111114111114
44 5220
14OFF14111114 88 11111114111114111114
48 5240
14OFF14111114 88 11111114111114111114
5250 to 5350 MHz
52 5260
17OFF17171720141417171720171720171720
56 5280
17OFF17171720141417171720171720171720
60 5300
17OFF17171720141417171720111114111114
64 5320
17OFF17171720141417171720111114 111114
5470 to 5725 MHz
100 5500
17 OFF 17 17 OFF 20 14 14 17 17 17 20 14 14 17 14 14 17
104 5520
17 OFF 17 17 OFF 20 14 14 17 17 17 20 14 14 17 14 14 17
108 5540
17 OFF 17 17 OFF 20 14 14 17 17 17 20 17 17 20 17 17 20
112 5560
17 OFF 17 17 OFF 20 14 14 17 17 17 20 17 17 20 17 17 20
116 5580
17 OFF 17 17 OFF 20 14 14 17 17 17 20 17 17 20 17 17 20
120 5600
––––––––––––––––––
124 5620
––––––––––––––––––
128 5640
––––––––––––––––––
132 5660
17OFF17171720141417171720171720171720
136 5680
17OFF17171720141417171720171720171720
140 5700
17OFF17171720141417171720 –– – –– –
5725 to 5850 MHz
149 5745
17OFF17171720171720171720171720171720
153 5765
17OFF17171720171720171720171720171720
157 5785
17OFF17171720171720171720171720171720
161 5805
17OFF17171720171720171720171720171720
165 5825
17OFF17171720171720171720 –– – –– –
