Channels and Maximum Power Settings for Cisco Aironet Autonomous Access Points and Bridges
OL-11142-01
Chapter 5 Cisco Aironet 1250 Series Autonomous Access Point
Channels and Maximum Power Levels
Table 5-10 indicates the channel identifiers, channel center frequencies, and maximum power levels for
each channel allowed by the –I regulatory domain for a 5-GHz radio with up to 6-dBi antenna.s
Table 5-10 Channels and Maximum Conducted Power in the –I Regulatory Domain with up to 6-dBi Antennas
Maximum Conducted Power Levels (dBm) in the –I Regulatory Domain for a 5-GHz Radio with up to 6-dBi Antennas
Channel
ID
Freq
(MHz)
802.11a
Single Antenna
6 to 54 Mbps
802.11a
Dual Antennas
6 to 54 Mbps
802.11a
Dual Antennas with
Beam Forming
HT-20 MHz
Dual Antennas
M0 to M15
Duplicate
(2x20 MHz)
Dual Antennas
6 Mbps
HT-40 MHz
Dual Antennas
M0 to M15
Tx
A
Tx
B
Total
Power
Tx
A
Tx
B
Total
Power
Tx
A
Tx
B
Total
Power
Tx
A
Tx
B
Total
Power
Tx
A
Tx
B
Total
Power
Tx
A
Tx
B
Total
Power
UNII-1 (5150-5250 MHz)
36 5180
17OFF17141417111114141417141417141417
40 5200
17OFF17141417111114141417141417141417
44 5220
17OFF17141417111114141417141417141417
48 5240
17OFF17141417111114141417141417141417
5250 to 5350 MHz
52 5260
17OFF17141417111114141417141417141417
56 5280
17OFF17141417111114141417141417141417
60 5300
17OFF17141417111114141417141417141417
64 5320
17OFF17141417111114141417141417141417
5470 to 5725 MHz
100 5500
––––––––––––––––––
104 5520
––––––––––––––––––
108 5540
––––––––––––––––––
112 5560
––––––––––––––––––
116 5580
––––––––––––––––––
120 5600
––––––––––––––––––
124 5620
––––––––––––––––––
128 5640
––––––––––––––––––
132 5660
––––––––––––––––––
136 5680
––––––––––––––––––
140 5700
––––––––––––––––––
5725 to 5850 MHz
149 5745
––––––––––––––––––
153 5765
––––––––––––––––––
157 5785
––––––––––––––––––
161 5805
––––––––––––––––––
165 5825
––––––––––––––––––
