C-1
Cisco Aironet 1250 Series Access Point Hardware Installation Guide
OL-8247-01
APPENDIX
C
Access Point Specifications
Table C-1 lists the technical specifications for the Cisco Aironet 1250 Series Access Point.
Table C-1 Access Point Specifications
Category 2.4 GHz Radio Specifications 5 GHz Radio Specifications
Size 8.1 in W x 9.5 in D x 2.3 in H
20.6 cm W x 24.1 cm D x 5.8 cm H
Weight Base access point (without modules): 2.1 lbs (0.78 kg)
2.4- GHz radio module: 1.4 lbs (0.52 kg)
5-GHz radio module: 1.4 lbs (0.52 kg)
Blank radio module: 1.1 lbs (0.41 kg)
Indicators Three indicators on top of unit: Ethernet traffic, status, and radio traffic.
Connectors Base unit (bottom of access point):
DC power connector (for plug-in power module); RJ-45 connector for 10BASE-T or
100BASE-T or 1000BASE-T Ethernet connections; RJ-45 connector for serial console port
connections.
2.4 GHz radio module (left to right) RP-TNC antenna connectors:
Left (A-Tx/Rx); middle (C-Rx), right (B-Tx/Rx).
5-GHz radio module (left to right):
Left (A-Tx/Rx); middle (C-Rx), right (B-Tx/Rx).
Input voltage 44 to 57 VDC (56 VDC nominal)
Input power 12.95 W (Up to 15.4 W with a 100 m CAT 5E Ethernet cable)—maximum
Operating temperature Access point, DC power module, and power injector:
–4 to 131
o
F (–20 to 55
o
C)
Storage temperature -40 to 158
o
F (-40 to 70
o
C)
Humidity 10 to 90% non-condensing
Operating altitude 10,000 ft (3048 m) maximum
