Cisco Aironet 1250 Series Access Point Hardware Installation Guide
OL-8247-01
Appendix C Access Point Specifications
Power output
802.11b 802.11g and 802.11n 802.11n
23 dBm
20 dBm
17 dBm
14 dBm)
11 dBm
8 dBm
5 dBm
2 dBm
-1 dBm
(Depending on the regulatory
domain in which the access
point is installed)
17 dBm
14 dBm
11 dBm
8 dBm
5 dBm
2 dBm
-1 dBm
(Depending on the regulatory
domain in which the access
point is installed)
50 mW (17 dBm)
25 mW (14 dBm)
12 mW (11 dBm)
6 mW (8 dBm)
3 mW (5 dBm)
2 mW (2 dBm)
1 mW (-1 dBm)
(Depending on the regulatory
domain in which the access point
is installed)
Note For the maximum power and the channels allowed in your regulatory domain, refer to the
Channels and Maximum Power Settings for Cisco Aironet Autonomous Access Points and
Bridges or the Channels and Maximum Power Settings for Cisco Aironet Lightweight Access
Points.
Antenna Three external antenna connectors on each radio module.
Frequency 2.400 to 2.497 GHz
(Depending on the regulatory domain in which the access point
is installed)
5.15 to 5.25 GHz
5.25 to 5.35 GHz
5.470 to 5.725 GHz
5.725 to 5.85 GHz
(Depending on the regulatory
domain in which the access point
is installed)
Typical indoor range
(across open office
environment)
105 ft (32 m) @ 54 Mbps
180 ft (55 m) @ 48 Mbps
260 ft (79 m) @ 36 Mbps
285 ft (87 m) @ 24 Mbps
330 ft (100 m) @ 18 Mbps
355 ft (108 m) @ 12 Mbps
365 ft (111 m) @ 11 Mbps
380 ft (116 m) @ 9 Mbps
410 ft (125 m) @ 6 Mbps
425 ft (130 m) @ 5.5 Mbps
445 ft (136 m) @ 2 Mbps
460 ft (140 m) @ 1 Mbps
Note Measured with a 2.2 dBi dipole antenna
85 ft (26 m) @ 54 Mbps
150 ft (46 m) @ 48 Mbps
210 ft (64 m) @ 36 Mbps
230 ft (70 m) @ 24 Mbps
260 ft (79 m) @ 18 Mbps
280 ft (85 m) @ 12 Mbps
310 ft (94 m) @ 9 Mbps
330 ft (100 m) @ 6 Mbps
Note Measured with 3.5 dBi
Omni-directional
antenna
Data Rates (Mbps) 802.11b 802.11g 802.11n 802.11n
1, 2, 5.5, and 11 6, 9, 12, 18,
24, 36, 48, and
54
6.5, 7.22, 13, 13.5, 14.44, 15, 19.5, 21.67, 26, 27,
28.89, 30, 39, 40.5, 43.33, 45, 52, 54, 57.78, 58.5,
60, 65, 72.22, 78, 81, 86.67, 90, 104, 108, 115.56,
117, 120, 121.5, 130, 135, 144.44, 157.5, 162,
180, 216, 180, 216, 240, 243, 270, and 300
Table C-1 Access Point Specifications (continued)
Category 2.4 GHz Radio Specifications 5 GHz Radio Specifications
