Navini Networks, Inc. Ripwave Modem User Guide
Installing a USB
Modem
(See, also, Addendum 1)
The following instructions are for the installation of a Ripwave
Modem that has a USB connection. Please read all instructions
before attempting the installation. It is advisable to turn off the
computer and the Ripwave Modem before performing the
installation.
Step Action Illustration (using LED Modem)
1. Connect the USB cable
to the USB port on the
computer.
2. Connect the other end of
the USB cable to the
back of the Ripwave
Modem.
3. Connect the AC power
adapter cable to the back
of the Ripwave Modem.
Plug the other end of the
cable into a 110/220
VAC, 60/50 Hz outlet.
CAUTION! Only use
the AC power adapter
specifically supplied
with the Ripwave
Modem. Using any other
adapter may cause
damage to the Modem.
US
B P
o
r
t
AC Power
adapter cable
j
ack
Part #40-00097-00 Rev F v1.0 15
May 21, 2004
