Cisco Unified IP Phone 7970 Series for Cisco Unified Communications Manager 6.1 13
Understanding Feature Buttons and Menus
Press a feature button to open or close a feature menu.
If you want to... Then...
Open or close a feature
menu
Press a feature button:
Messages
Services
Help
Directories
Settings
Scroll through a list or
menu
Press the Navigation button.
Go back one level in a
feature menu
Press Exit. Pressing Exit from the top level of a menu closes the menu.
Switch between open
feature menus
Press a feature tab on your touchscreen. Each feature menu has a
corresponding tab. The tab is visible when the feature menu is open.
Accessing the Help System on Your Phone
Your phone provides a comprehensive online help system. Help topics appear on the touchscreen.
If you want to... Then...
View the main menu Press on your phone and wait a few seconds for the menu to display.
Main menu topics include:
• About Your Cisco Unified IP Phone—Details about your phone
• How do I...?—Procedures for common phone tasks
• Calling Features—Descriptions and procedures for calling features
Learn about a softkey
or button
Press , then quickly press a softkey or button.
Learn about a menu item Press , then quickly press the menu item on the touchscreen. Or, press
twice quickly with the menu item highlighted.
Get help using Help Press . After a second or two, press again, or choose Help from
the main menu.
