Card and Service Configuration 6-11
Adding Connections on a PXM in a Stand-Alone Node
Table 6-1 Policing Definitions According to Policing and Connection Type
Policing by
Connection Type
ATM Forum TM
spec. 4.0
conformance
definition
PCR Flow
(1st leaky
bucket)
CLP
tagging
(for PCR
flow)
SCR Flow
(2nd leaky
bucket)
CLP
tagging
(for SCR
flow)
CBR
polType=4
CBR.1
(PCR Policing only)
CLP(0+1) no off n/a
CBR
polType=5
When policing = 5 (off) off n/a off n/a
UBR
polType=3
UBR.1
when CLP setting = no
CLP(0+1) no off n/a
UBR
polType=4
UBR.2
when CLP setting = yes
CLP(0+1) no CLP(0) yes
UBR
polType=5
Policing is off off n/a off n/a
VBR
polType=1
VBR.1
1
CLP(0+1) no CLP(0+1) no
VBR
polType=2
VBR.2 CLP(0+1) no CLP(0) no
VBR
polType=3
VBR.3 CLP(0+1) no CLP(0) yes
VBR
polType=4
(when Policing = 4) CLP(0+1) no off n/a
VBR
polType=5
Policing is off off n/a off n/a
