Cisco MGX 8850 Installation and Configuration, Release 1.1.00, Part Number 78-6186-02
6-52
Table 6-6 Loopback Test for AX-FRSM-8T1, MGX-CESM-8T1, and MGX-FRSM-2CT3
Table 6-7 Pattern Test for AX-FRSM-8E1 and MGX-CESM-8E1
Table 6-8 Loopback Test for AX-FRSM-8E1 and MGX-CESM-8E1
Table 6-9 Pattern Test for MGX-AUSM-8T1
Table 6-10 Loopback Test for MGX-AUSM-8T1
Table 6-11 Pattern Test for MGX-AUSM-8E1
Table 6-12 Loopback Test for MGX-AUSM-8E1
Test Medium Medium Type Loopback
Port
Port with N timeslots (can also
submit to the DDS seek test)
far end or remote
Port with one 64-Kbps timeslot (can
also submit to the DDS seek test)
far end or remote
Port with one 56-Kbps timeslot (can
also submit to the DDS seek test)
far end or remote
Line n/a metallic, far end, or remote
Test Medium Medium Type Device to Loop BERT Pattern
Port any none all patterns
Line n/a metallic all patterns
Test Medium Medium Type Loopback
Port any remote loopback
Line n/a metallic or remote
Test Medium Medium Type Device to Loop BERT Pattern
Line n/a in-band/ESF all patterns
Test Medium Medium Type Loopback
Line n/a far end, remote, or metallic
Test Medium Medium Type Device to Loop BERT Pattern
Line n/a none all patterns
Test Medium Medium Type Loopback
Line n/a remote or metallic
