9-3
Cisco WAN Modeling Tools Guide
OL-10426-01, Rev. A0
Chapter 9 Configuration Extraction Tool
Using the CET
Step 4 This step is optional.
If manual corrections are required on the output CNF file, you can make them once, and then
automatically make them again with the 'adj2nmt' command. The command only updates fields that are
missing from CWM or are not that reliable. The site names, and slot port information is used to match
links and connections. Messages are generated for every change.
adj2nmt <in-file> <reference-file> <out-file> {[options]}
in-file
is the most recent extraction file.
reference-file
is the extraction with the manual changes applied
out-file
in the input file with the same parameters changed on the output file.
Options:
•
-add
—Add links and connections that are in the reference file but missing from the input file.
•
-diffrep
—Write no output file, but generate a report about the differences of the two files.
Note The field update functionality and the topology compare functionality can now be called directly
from the NMT menu under FILES/READ 2ND CNF.
This process is illustrated in Figure 9-1.
