2-9
Cisco WAN Modeling Tools Guide
OL-10426-01, Rev. A0
Chapter 2 Installing the Cisco WAN Modeling Tools
Removing Sub-applications
Step 4 If you are going to use the tar file for your NMT data, copy tar.exe and SSIDOSKT.TAR to a DOS
working directory.
Step 5 Enter the command 'tar xvf SSIDOSKT.TAR to un-archive the data.
Removing Sub-applications
This section provides instructions for removing the following sub-applications on a UNIX platform:
• the Configuration Extraction Tool (CET)
• the Third Party Interface (TPI)
• the SpreadSheet Interface (SSI)
Remove individual applications by running the following commands:
• cetrel removes CET from your ID.
• tpirel removes TPI from your ID.
• ssirel removes SSI from your ID.
Note Enter the nmtrel command to remove all applications from your ID.
Troubleshooting NMT Installation
The table below describes a common NMT Installation problems and what can be done about them.
Symptom The command nmt fails, returns message:
xterm not found.
Probable Causes Unix is not configured for xterm.
Solution Have a UNIX administrator provide xterm support for your account.
Symptom Cannot write cnf files or reports.
Cannot update the map.
Probable Causes No write permission.
Solution Make sure your account has write permission to your working directory.
Symptom NMT fails and displays the following error message:
Error: Cannot open display <IP-ADDRESS:00>
Probable Causes No remote display permission. Site is unreachable.
Solution Check network connectivity. If you are using a dial-up line, remote GUI
display may be impossible.
