Chapter 4 Configuration Tables and Fields
Sites Table
IGX Y E Type of feeder node. Y—feeder
nodes should be IGX. N—feeder
nodes should be IPX.
This field applies only if NMT
needs to add a feeder node.
IGX
TF N E Tiered Feeder Flag.
Y- for feeder;
N- for router.
This field applies only to added
feeder nodes.
TF
BC T1 E/H Back card. Feeder link back card.
This field applies only to added
feeder nodes.
BC
FC NTM E/H Front card. Feeder link front
card.
This field applies only to added
feeder nodes.
FC
RLC N E Redundant link card. Specifies
whether link is redundant.
This field applies only to added
feeder nodes.
RDL
NPA NPA of the site location. Not
used in NMT but carried for
reference and used in WANDL.
NPA *
NXX NXX of the site location. Not
used in NMT but carried for
reference and used in WANDL.
NXX *
LON Longitude of site location. Not
used in NMT but carried for
reference and used in WANDL.
Several different formats are
available in the string field.
LON F: muxloc
LAT Latitude of site location. Not
used in NMT but carried for
reference and used in WANDL.
Several different formats are
available in the string field.
LAT F: muxloc
RA H 0 Routing algorithm version of
Autoroute. Use 'H' for minimum
hops, 'C' for Least Cost, and 'CD'
for least cost with delays.
RM
PNNI Blank 0 Y/N flag indicating whether the
node is capable of PNNI routing
or not.
PNNI *
Table 4-1 .Site Table (continued)
Field Defaults Notes Description and Comments DBF CET TPI
