Chapter 4 Configuration Tables and Fields
Sites Table
PNNI_PG N 0 name of the PNNI group, as
defined in the PNNI Domains
table. If the name in this table is
not in the PNNI Domain table,
then it is just represents a logical
grouping that the user can define
any way they wish.
PNNI_PG
PGL_PR 0 0 The Peer Group Leader Election
Priority is a numeric value
determining which site will be
the peer group leader. The
highest value in the peer group
will be the leader.
PGL_PRI * *
Xrstr N 0 Y/N flag for transit restriction. If
Y, the PNNI node cannot be used
for transit calls (via connections).
XR
MAPV Map vertical coordinate. Can be
loaded and unloaded from the
NMT map process.
VER *
Only available if
CWM or SV+ map
has been
configured.
*
If no NMT
longitude/latitude
fields, use this to
create latitude in
table muxloc
Also written to
graphcoord file.
MAPH Map horizontal coordinate. Can
be loaded and unloaded from the
NMT map process.
HOR *
Only available if
CWM or SV+ map
has been
configured.
*
If no NMT
longitude/latitude
fields, use this to
create longitude in
table muxloc
Also written to
graphcoord file.
CT Blank 0 Country code. A two digit
country code carried but not used
by NMT. Used in WANDL for
tariff lookups.
CT *
Weight 0 0 User defined weight that can be
used for generating links and/or
connections using the MESH
commands in the
CONFIG/UTILITIES menu.
WEIGHT nodeweight file
Network 0 The network domain name this
site is assigned to.
NET_NAME *
DOMAIN in the
muxloc file.
Table 4-1 .Site Table (continued)
Field Defaults Notes Description and Comments DBF CET TPI
