4-9
Cisco WAN Modeling Tools Guide
OL-10426-01, Rev. A0
Chapter 4 Configuration Tables and Fields
Links Table
$/Mo 0 E Cost per month of trunk from Site 1 to
Site 2. If blank, NMT calculates cost
using the Dist field and the data in the
Line Cost Table (in the Maintenance
menu). If you enter a value here, use
zero in the Distance field.
COST_MO
Instl 0 O Installation cost of a trunk.
INSTALL
Fdr1ID 0 E Feeder 1 ID. Part ID for the IMATM
trunk on an MGX 8220 edge
concentrator.
FDR1ID
Fdr2ID 0 E Feeder 2 ID. Part ID for the IMATM
trunk on an MGX 8220 edge
concentrator.
FDR2ID
IMA_RD 0 O IMATM resiliency degree. Number of
T1/E1 lines of AIMUX port that are
allowed to fail before the AIMATM
trunk goes down.
IMA_RES
NTS_Q 0/0 O Queue Depth in Transmit/Receive
direction for Non Time Stamped
connection loads. When the entry is 0,
NMT will assume the default queue
depth.
NTS_QDS/
NTD_QDR
Voice_Q 0/0 O Queue Depth in Transmit/Receive
direction for Voice connection loads.
When the entry is 0, NMT will assume
the default queue depth.
DSI_QDS/
DSI_QDR
Cost 10 O The Least Cost Routing (LCR) weight.
WT
*
AR Y O Y/N flag indicating if the link is
Autoroute enabled.
AR
PNNI N O Y/N flag indicating if the link is PNNI
enabled.
PNNI
Heuristic used
for BPX nodes
AggToken 0 O The value used in the PNNI link
aggregation algorithm. At least one
link with a unique aggregation token
will always be known in the PNNI
logical topology.
AGG_TOK
Comment 0 Comment field used in NMT only.
COMMENT
Table 4-3 Link Table (continued)
Field Defaults Notes Description and Comments DBF CET TPI
