4-12
Cisco WAN Modeling Tools Guide
OL-10426-01, Rev. A0
Chapter 4 Configuration Tables and Fields
Voice Table
Qty 1 M Quantity. Number of
connections of the specified
type.
CONNS *
Since slot and port are
included, this field is
always set to 1.
*
Type C32 M/H Type of voice connection.
TYPE *
Derived heuristically
prior to Release 8.5. T
connections shown as
P; FastPAD CELP8
and CELP48 conns
shown as ATC16.
*
E2E_TYPE SPVC M The end to end type of the
connection. PVC, SPVC,
XPVC, Hybred and 1Ended are
all valid.
E2E
Coded:
C - PVC
S- SPVC
H- Hybred
X - XPVC
E - Single ended
Sig CAS O Signalling type: channel
associated signalling (CAS), or
common channel signalling
(CCS), or clear (CLR).
SIG
PR 0 O Rerouting priority—0 to 15,
with 0 the highest rerouting
priority.
COS
Defaults used prior to
Release 8.5.
*
Ad – O/H Restriction type. Ad is short for
Avoid. Specify the media types
that should be avoided when
the connection is routed.
AV D
Red N P Redundancy. Specifies whether
connections are going to be
redundant. Applies to CDP
redundancy.
RED
%Util 40/40 E Trunk utilization, based on
minimum information rate
(MIR) percentage. (Default is
40% because studies have
shown that during
conversations, one end of the
line is unused 60% of the time.)
PCT_UTIL1 /
PCT_UTIL2
Defaults used prior to
Release 8.5 and for
FastPAD. The data
may be unreliable if it
changed after adding a
connection.
*/*
Table 4-6 Voice Table (continued)
Field Defaults Notes Description and Comments DBF CET TPI
